Stober PK - Page 274

n
2N
M
2N
M
2,0
a
th
S Type M
2acc
M
2accHT
M
2NOT
i i
exakt
M
1Bstat
M
Bstat
n
1maxDB
n
1maxZB
J
1
C
2
m
EL1,2 EL3,4,5,6
[rpm] [Nm] [Nm] [Nm] [Nm] [Nm] [Nm] [Nm] [rpm] [rpm] [rpm] [kgcm²] [Nm/ [kg]
arcmin]
PHQ1131K (n
1N
= 3000 rpm, M
2acc,max
= 22000 Nm)
11 4020 5068 11 3.2 PHQ1131_0060K813_0440 MB33 EZ703U 15838 – 44000 265.5 531/2 24 32 2800 2500 4000 64 2623 320
11 4020 5068 11 3.2 PHQ1131_0060K813_0440 MB33 EZ703U 15838 – 44000 265.5 531/2 32 32 2800 2500 4000 64 2623 320
11 4020 5068 11 3.2 PHQ1131_0060K813_0440 MB33 EZ703U 15838 – 44000 265.5 531/2 45 32 2800 2500 4000 64 2623 320
11 5190 7359 15 2.5 PHQ1131_0060K813_0440 MB33 EZ705U 22000 – 44000 265.5 531/2 16 32 2800 2500 4000 76 2623 326
11 5190 7359 15 2.5 PHQ1131_0060K813_0440 MB33 EZ705U 22000 – 44000 265.5 531/2 24 32 2800 2500 4000 76 2623 326
11 5190 7359 15 2.5 PHQ1131_0060K813_0440 MB33 EZ705U 22000 – 44000 265.5 531/2 32 32 2800 2500 4000 76 2623 326
11 5190 7359 15 2.5 PHQ1131_0060K813_0440 MB33 EZ705U 22000 – 44000 265.5 531/2 45 32 2800 2500 4000 76 2623 326
12 2644 3172 8.0 4.9 PHQ1131_0060K813_0400 MB33 EZ702U 9033 – 41639 240.1 38409/160 16 15 2800 2500 4000 55 2623 318
12 2644 3172 8.0 4.9 PHQ1131_0060K813_0400 MB33 EZ702U 9033 – 41639 240.1 38409/160 24 15 2800 2500 4000 55 2623 318
12 2644 3172 8.0 4.9 PHQ1131_0060K813_0400 MB33 EZ702U 9033 – 41639 240.1 38409/160 32 15 2800 2500 4000 55 2623 318
12 2644 3172 8.0 4.9 PHQ1131_0060K813_0400 MB33 EZ702U 9033 – 41639 240.1 38409/160 45 15 2800 2500 4000 55 2623 318
12 3635 4582 11 3.6 PHQ1131_0060K813_0400 MB33 EZ703U 14320 – 41639 240.1 38409/160 16 32 2800 2500 4000 67 2623 320
12 3635 4582 11 3.6 PHQ1131_0060K813_0400 MB33 EZ703U 14320 – 41639 240.1 38409/160 24 32 2800 2500 4000 67 2623 320
12 3635 4582 11 3.6 PHQ1131_0060K813_0400 MB33 EZ703U 14320 – 41639 240.1 38409/160 32 32 2800 2500 4000 67 2623 320
12 3635 4582 11 3.6 PHQ1131_0060K813_0400 MB33 EZ703U 14320 – 41639 240.1 38409/160 45 32 2800 2500 4000 67 2623 320
12 4693 6653 14 2.8 PHQ1131_0060K813_0400 MB33 EZ705U 22000 – 41639 240.1 38409/160 16 32 2800 2500 4000 79 2623 326
12 4693 6653 14 2.8 PHQ1131_0060K813_0400 MB33 EZ705U 22000 – 41639 240.1 38409/160 24 32 2800 2500 4000 79 2623 326
12 4693 6653 14 2.8 PHQ1131_0060K813_0400 MB33 EZ705U 22000 – 41639 240.1 38409/160 32 32 2800 2500 4000 79 2623 326
12 4693 6653 14 2.8 PHQ1131_0060K813_0400 MB33 EZ705U 22000 – 41639 240.1 38409/160 45 32 2800 2500 4000 79 2623 326
12 5860 10619 18 2.2 PHQ1131_0060K813_0400 MB43 EZ803U 22000 – 44000 240.1 38409/160 50 65 2800 2500 3000 187 2623 357
14 3283 4139 11 4.0 PHQ1131_0060K813_0360 MB33 EZ703U 12935 – 37610 216.8 8673/40 16 32 2800 2500 4000 68 2623 320
14 3283 4139 11 4.0 PHQ1131_0060K813_0360 MB33 EZ703U 12935 – 37610 216.8 8673/40 24 32 2800 2500 4000 68 2623 320
14 3283 4139 11 4.0 PHQ1131_0060K813_0360 MB33 EZ703U 12935 – 37610 216.8 8673/40 32 32 2800 2500 4000 68 2623 320
14 3283 4139 11 4.0 PHQ1131_0060K813_0360 MB33 EZ703U 12935 – 37610 216.8 8673/40 45 32 2800 2500 4000 68 2623 320
14 4239 6010 14 3.1 PHQ1131_0060K813_0360 MB33 EZ705U 19900 – 37610 216.8 8673/40 16 32 2800 2500 4000 80 2623 326
14 4239 6010 14 3.1 PHQ1131_0060K813_0360 MB33 EZ705U 19900 – 37610 216.8 8673/40 24 32 2800 2500 4000 80 2623 326
14 4239 6010 14 3.1 PHQ1131_0060K813_0360 MB33 EZ705U 19900 – 37610 216.8 8673/40 32 32 2800 2500 4000 80 2623 326
14 4239 6010 14 3.1 PHQ1131_0060K813_0360 MB33 EZ705U 19900 – 37610 216.8 8673/40 45 32 2800 2500 4000 80 2623 326
14 5293 9592 17 2.5 PHQ1131_0060K813_0360 MB43 EZ803U 22000 – 44000 216.8 8673/40 50 65 2800 2500 3000 188 2623 357
15 2943 3710 10 4.4 PHQ1131_0060K813_0320 MB33 EZ703U 11593 – 33709 194.3 31093/160 16 32 2800 2500 4000 72 2623 320
15 2943 3710 10 4.4 PHQ1131_0060K813_0320 MB33 EZ703U 11593 – 33709 194.3 31093/160 24 32 2800 2500 4000 72 2623 320
15 2943 3710 10 4.4 PHQ1131_0060K813_0320 MB33 EZ703U 11593 – 33709 194.3 31093/160 32 32 2800 2500 4000 72 2623 320
15 2943 3710 10 4.4 PHQ1131_0060K813_0320 MB33 EZ703U 11593 – 33709 194.3 31093/160 45 32 2800 2500 4000 72 2623 320
15 3799 5386 13 3.4 PHQ1131_0060K813_0320 MB33 EZ705U 17835 – 33709 194.3 31093/160 16 32 2800 2500 4000 84 2623 326
15 3799 5386 13 3.4 PHQ1131_0060K813_0320 MB33 EZ705U 17835 – 33709 194.3 31093/160 24 32 2800 2500 4000 84 2623 326
15 3799 5386 13 3.4 PHQ1131_0060K813_0320 MB33 EZ705U 17835 – 33709 194.3 31093/160 32 32 2800 2500 4000 84 2623 326
15 3799 5386 13 3.4 PHQ1131_0060K813_0320 MB33 EZ705U 17835 – 33709 194.3 31093/160 45 32 2800 2500 4000 84 2623 326
15 4744 8597 17 2.7 PHQ1131_0060K813_0320 MB43 EZ803U 22000 – 44000 194.3 31093/160 50 65 2800 2500 3000 192 2623 357
15 4744 8597 17 2.7 PHQ1131_0060K813_0320 MB43 EZ803U 22000 – 44000 194.3 31093/160 72 65 2800 2500 3000 192 2623 357
17 2658 3351 10 4.9 PHQ1131_0060K813_0290 MB33 EZ703U 10471 – 30446 175.5 7021/40 16 32 2800 2500 4000 73 2623 320
17 2658 3351 10 4.9 PHQ1131_0060K813_0290 MB33 EZ703U 10471 – 30446 175.5 7021/40 24 32 2800 2500 4000 73 2623 320
17 2658 3351 10 4.9 PHQ1131_0060K813_0290 MB33 EZ703U 10471 – 30446 175.5 7021/40 32 32 2800 2500 4000 73 2623 320
17 2658 3351 10 4.9 PHQ1131_0060K813_0290 MB33 EZ703U 10471 – 30446 175.5 7021/40 45 32 2800 2500 4000 73 2623 320
17 3431 4865 13 3.8 PHQ1131_0060K813_0290 MB33 EZ705U 16109 – 30446 175.5 7021/40 16 32 2800 2500 4000 85 2623 326
17 3431 4865 13 3.8 PHQ1131_0060K813_0290 MB33 EZ705U 16109 – 30446 175.5 7021/40 24 32 2800 2500 4000 85 2623 326
17 3431 4865 13 3.8 PHQ1131_0060K813_0290 MB33 EZ705U 16109 – 30446 175.5 7021/40 32 32 2800 2500 4000 85 2623 326
17 3431 4865 13 3.8 PHQ1131_0060K813_0290 MB33 EZ705U 16109 – 30446 175.5 7021/40 45 32 2800 2500 4000 85 2623 326
17 4285 7764 16 3.0 PHQ1131_0060K813_0290 MB43 EZ803U 22000 – 44000 175.5 7021/40 50 65 2800 2500 3000 193 2623 357
17 4285 7764 16 3.0 PHQ1131_0060K813_0290 MB43 EZ803U 22000 – 44000 175.5 7021/40 72 65 2800 2500 3000 193 2623 357
20 2992 4243 12 4.3 PHQ1131_0060K813_0260 MB33 EZ705U 14049 – 26552 153.1 140833/920 16 32 2300 2100 3500 92 2623 326
20 2992 4243 12 4.3 PHQ1131_0060K813_0260 MB33 EZ705U 14049 – 26552 153.1 140833/920 24 32 2300 2100 3500 92 2623 326
20 2992 4243 12 4.3 PHQ1131_0060K813_0260 MB33 EZ705U 14049 – 26552 153.1 140833/920 32 32 2300 2100 3500 92 2623 326
20 2992 4243 12 4.3 PHQ1131_0060K813_0260 MB33 EZ705U 14049 – 26552 153.1 140833/920 45 32 2300 2100 3500 92 2623 326
20 3737 6772 15 3.5 PHQ1131_0060K813_0260 MB43 EZ803U 20371 – 44000 153.1 140833/920 50 65 2300 2100 3000 200 2623 357
20 3737 6772 15 3.5 PHQ1131_0060K813_0260 MB43 EZ803U 20371 – 44000 153.1 140833/920 72 65 2300 2100 3000 200 2623 357
20 3737 6772 15 3.5 PHQ1131_0060K813_0260 MB43 EZ803U 20371 – 44000 153.1 140833/920 100 65 2300 2100 3000 200 2623 357
22 2703 3832 12 4.7 PHQ1131_0060K813_0230 MB33 EZ705U 12689 – 23983 138.3 31801/230 16 32 2300 2100 3500 94 2623 326
22 2703 3832 12 4.7 PHQ1131_0060K813_0230 MB33 EZ705U 12689 – 23983 138.3 31801/230 24 32 2300 2100 3500 94 2623 326
22 2703 3832 12 4.7 PHQ1131_0060K813_0230 MB33 EZ705U 12689 – 23983 138.3 31801/230 32 32 2300 2100 3500 94 2623 326
22 2703 3832 12 4.7 PHQ1131_0060K813_0230 MB33 EZ705U 12689 – 23983 138.3 31801/230 45 32 2300 2100 3500 94 2623 326
22 3375 6116 15 3.9 PHQ1131_0060K813_0230 MB43 EZ803U 18400 – 42636 138.3 31801/230 50 65 2300 2100 3000 202 2623 357
22 3375 6116 15 3.9 PHQ1131_0060K813_0230 MB43 EZ803U 18400 – 42636 138.3 31801/230 72 65 2300 2100 3000 202 2623 357
22 3375 6116 15 3.9 PHQ1131_0060K813_0230 MB43 EZ803U 18400 – 42636 138.3 31801/230 100 65 2300 2100 3000 202 2623 357
26 2250 3190 14 4.7 PHQ1131_0060K813_0190 MB33 EZ705U 10563 – 19965 115.1 133517/1160 16 32 2300 2100 3500 105 2623 326
9.2 Selection tables 9 PHQKright-angle planetary geared motors
274
