Stober PK - Page 303

n
2N
M
2N
M
2,0
a
th
S Type M
2acc
M
2NOT
i i
exakt
M
1Bstat
M
Bstat
n
1maxDB
n
1maxZB
J
1
C
2
m
EL1,2 EL3,4,5,6
[rpm] [Nm] [Nm] [Nm] [Nm] [Nm] [Nm] [rpm] [rpm] [rpm] [kgcm²] [Nm/ [kg]
arcmin]
K2 (n
1N
= 3000 rpm, M
2acc,max
= 220 Nm)
500 43 48 27 2.5 K202_0060 MB33 EZ701U 116 400 6.000 6/1 24 15 3000 2600 4000 39 11 45
500 56 65 35 1.9 K202_0060 MB23 EZ503U 200 367 6.000 6/1 8.0 15 3000 2600 4000 18 11 37
500 56 65 35 1.9 K202_0060 MB23 EZ503U 200 367 6.000 6/1 12 15 3000 2600 4000 18 11 37
500 70 84 43 1.5 K202_0060 MB33 EZ702U 200 400 6.000 6/1 16 15 3000 2600 4000 44 11 47
500 70 84 43 1.5 K202_0060 MB33 EZ702U 200 400 6.000 6/1 24 15 3000 2600 4000 44 11 47
579 22 24 16 4.7 K202_0052 MB23 EZ501U 80 316 5.177 2107/407 8.0 8.0 3000 2600 4000 12 11 34
579 22 24 16 4.7 K202_0052 MB23 EZ501U 80 316 5.177 2107/407 12 8.0 3000 2600 4000 12 11 34
579 22 24 16 4.7 K202_0052 MB23 EZ501U 80 316 5.177 2107/407 16 8.0 3000 2600 4000 12 11 34
579 24 26 17 4.3 K202_0052 MB23 EZ402U 80 316 5.177 2107/407 8.0 8.0 3000 2600 4000 11 11 33
579 24 26 17 4.3 K202_0052 MB23 EZ402U 80 316 5.177 2107/407 12 8.0 3000 2600 4000 11 11 33
579 24 26 17 4.3 K202_0052 MB23 EZ402U 80 316 5.177 2107/407 16 8.0 3000 2600 4000 11 11 33
579 35 43 25 2.9 K202_0052 MB23 EZ404U 146 316 5.177 2107/407 8.0 8.0 3000 2600 4000 12 11 36
579 35 43 25 2.9 K202_0052 MB23 EZ404U 146 316 5.177 2107/407 12 8.0 3000 2600 4000 12 11 36
579 35 43 25 2.9 K202_0052 MB23 EZ404U 146 316 5.177 2107/407 16 8.0 3000 2600 4000 12 11 36
579 37 40 27 2.7 K202_0052 MB23 EZ502U 156 316 5.177 2107/407 8.0 8.0 3000 2600 4000 14 11 35
579 37 40 27 2.7 K202_0052 MB23 EZ502U 156 316 5.177 2107/407 12 8.0 3000 2600 4000 14 11 35
579 37 40 27 2.7 K202_0052 MB23 EZ502U 156 316 5.177 2107/407 16 8.0 3000 2600 4000 14 11 35
579 37 42 27 2.7 K202_0052 MB33 EZ701U 100 400 5.177 2107/407 16 15 3000 2600 4000 39 11 45
579 37 42 27 2.7 K202_0052 MB33 EZ701U 100 400 5.177 2107/407 24 15 3000 2600 4000 39 11 45
579 49 56 35 2.1 K202_0052 MB23 EZ503U 188 316 5.177 2107/407 8.0 15 3000 2600 4000 18 11 37
579 49 56 35 2.1 K202_0052 MB23 EZ503U 188 316 5.177 2107/407 12 15 3000 2600 4000 18 11 37
579 60 72 44 1.7 K202_0052 MB33 EZ702U 190 400 5.177 2107/407 16 15 3000 2600 4000 44 11 47
579 60 72 44 1.7 K202_0052 MB33 EZ702U 190 400 5.177 2107/407 24 15 3000 2600 4000 44 11 47
687 20 22 17 4.8 K202_0044 MB23 EZ402U 68 267 4.364 48/11 8.0 8.0 3000 2600 4000 11 11 33
687 20 22 17 4.8 K202_0044 MB23 EZ402U 68 267 4.364 48/11 12 8.0 3000 2600 4000 11 11 33
687 20 22 17 4.8 K202_0044 MB23 EZ402U 68 267 4.364 48/11 16 8.0 3000 2600 4000 11 11 33
687 29 36 25 3.3 K202_0044 MB23 EZ404U 123 267 4.364 48/11 8.0 8.0 3000 2600 4000 12 11 36
687 29 36 25 3.3 K202_0044 MB23 EZ404U 123 267 4.364 48/11 12 8.0 3000 2600 4000 12 11 36
687 29 36 25 3.3 K202_0044 MB23 EZ404U 123 267 4.364 48/11 16 8.0 3000 2600 4000 12 11 36
687 31 34 27 3.0 K202_0044 MB23 EZ502U 131 267 4.364 48/11 8.0 8.0 3000 2600 4000 15 11 35
687 31 34 27 3.0 K202_0044 MB23 EZ502U 131 267 4.364 48/11 12 8.0 3000 2600 4000 15 11 35
687 31 34 27 3.0 K202_0044 MB23 EZ502U 131 267 4.364 48/11 16 8.0 3000 2600 4000 15 11 35
687 31 35 27 3.0 K202_0044 MB33 EZ701U 85 400 4.364 48/11 16 15 3000 2600 4000 40 11 45
687 31 35 27 3.0 K202_0044 MB33 EZ701U 85 400 4.364 48/11 24 15 3000 2600 4000 40 11 45
687 31 35 27 3.0 K202_0044 MB33 EZ701U 85 400 4.364 48/11 32 15 3000 2600 4000 40 11 45
687 41 47 36 2.3 K202_0044 MB23 EZ503U 159 267 4.364 48/11 8.0 15 3000 2600 4000 18 11 37
687 41 47 36 2.3 K202_0044 MB23 EZ503U 159 267 4.364 48/11 12 15 3000 2600 4000 18 11 37
687 51 61 44 1.9 K202_0044 MB33 EZ702U 174 400 4.364 48/11 16 15 3000 2600 4000 45 11 47
687 51 61 44 1.9 K202_0044 MB33 EZ702U 174 400 4.364 48/11 24 15 3000 2600 4000 45 11 47
687 51 61 44 1.9 K202_0044 MB33 EZ702U 174 400 4.364 48/11 32 15 3000 2600 4000 45 11 47
687 57 68 50 1.7 K202_0044 MB23 EZ505U 159 267 4.364 48/11 8.0 15 3000 2600 4000 23 11 40
687 57 68 50 1.7 K202_0044 MB23 EZ505U 159 267 4.364 48/11 12 15 3000 2600 4000 23 11 40
750 27 33 26 3.4 K202_0040 MB23 EZ404U 113 244 4.000 4/1 8.0 8.0 3000 2600 4000 13 11 36
750 27 33 26 3.4 K202_0040 MB23 EZ404U 113 244 4.000 4/1 12 8.0 3000 2600 4000 13 11 36
750 27 33 26 3.4 K202_0040 MB23 EZ404U 113 244 4.000 4/1 16 8.0 3000 2600 4000 13 11 36
750 29 31 27 3.2 K202_0040 MB23 EZ502U 120 244 4.000 4/1 8.0 8.0 3000 2600 4000 15 11 35
750 29 31 27 3.2 K202_0040 MB23 EZ502U 120 244 4.000 4/1 12 8.0 3000 2600 4000 15 11 35
750 29 31 27 3.2 K202_0040 MB23 EZ502U 120 244 4.000 4/1 16 8.0 3000 2600 4000 15 11 35
750 29 32 27 3.2 K202_0040 MB33 EZ701U 78 400 4.000 4/1 16 15 3000 2600 4000 40 11 45
750 29 32 27 3.2 K202_0040 MB33 EZ701U 78 400 4.000 4/1 24 15 3000 2600 4000 40 11 45
750 29 32 27 3.2 K202_0040 MB33 EZ701U 78 400 4.000 4/1 32 15 3000 2600 4000 40 11 45
750 29 32 27 3.2 K202_0040 MB33 EZ701U 78 400 4.000 4/1 45 15 3000 2600 4000 40 11 45
750 38 43 36 2.5 K202_0040 MB23 EZ503U 146 244 4.000 4/1 8.0 15 3000 2600 4000 19 11 37
750 38 43 36 2.5 K202_0040 MB23 EZ503U 146 244 4.000 4/1 12 15 3000 2600 4000 19 11 37
750 47 56 45 2.0 K202_0040 MB33 EZ702U 159 400 4.000 4/1 16 15 3000 2600 4000 45 11 47
750 47 56 45 2.0 K202_0040 MB33 EZ702U 159 400 4.000 4/1 24 15 3000 2600 4000 45 11 47
750 47 56 45 2.0 K202_0040 MB33 EZ702U 159 400 4.000 4/1 32 15 3000 2600 4000 45 11 47
750 47 56 45 2.0 K202_0040 MB33 EZ702U 159 400 4.000 4/1 45 15 3000 2600 4000 45 11 47
750 52 62 50 1.8 K202_0040 MB23 EZ505U 146 244 4.000 4/1 8.0 15 3000 2600 4000 23 11 40
750 52 62 50 1.8 K202_0040 MB23 EZ505U 146 244 4.000 4/1 12 15 3000 2600 4000 23 11 40
K3 (n
1N
= 3000 rpm, M
2acc,max
= 390 Nm)
129 97 106 8.7 3.0 K302_0230 MB23 EZ501U 361 700 23.29 559/24 8.0 8.0 3800 3500 4000 11 16 39
129 106 117 9.5 2.7 K302_0230 MB23 EZ402U 361 700 23.29 559/24 8.0 8.0 3800 3500 4000 9.5 16 38
129 156 194 14 1.9 K302_0230 MB23 EZ404U 385 700 23.29 559/24 8.0 8.0 3800 3500 4000 11 16 41
