n
2N
M
2N
M
2,0
a
th
S Type M
2acc
M
2NOT
i i
exakt
M
1Bstat
M
Bstat
n
1maxDB
n
1maxZB
J
1
C
2
m
EL1,2 EL3,4,5,6
[rpm] [Nm] [Nm] [Nm] [Nm] [Nm] [Nm] [rpm] [rpm] [rpm] [kgcm²] [Nm/ [kg]
arcmin]
K3 (n
1N
= 3000 rpm, M
2acc,max
= 390 Nm)
129 167 181 15 1.7 K302_0230 MB23 EZ502U 385 700 23.29 559/24 8.0 8.0 3800 3500 4000 13 16 40
148 85 92 8.8 3.3 K302_0200 MB23 EZ501U 315 700 20.28 3569/176 8.0 8.0 3800 3500 4000 11 16 39
148 92 102 9.6 3.0 K302_0200 MB23 EZ402U 315 700 20.28 3569/176 8.0 8.0 3800 3500 4000 9.4 16 38
148 136 169 14 2.0 K302_0200 MB23 EZ404U 385 700 20.28 3569/176 8.0 8.0 3800 3500 4000 11 16 41
148 146 157 15 1.9 K302_0200 MB23 EZ502U 385 700 20.28 3569/176 8.0 8.0 3800 3500 4000 13 16 40
173 72 79 8.9 3.7 K302_0175 MB23 EZ501U 268 700 17.29 1591/92 8.0 8.0 3500 3100 4000 11 16 39
173 72 79 8.9 3.7 K302_0175 MB23 EZ501U 268 700 17.29 1591/92 12 8.0 3500 3100 4000 11 16 39
173 79 87 9.7 3.3 K302_0175 MB23 EZ402U 268 700 17.29 1591/92 8.0 8.0 3500 3100 4000 9.7 16 38
173 79 87 9.7 3.3 K302_0175 MB23 EZ402U 268 700 17.29 1591/92 12 8.0 3500 3100 4000 9.7 16 38
173 116 144 14 2.3 K302_0175 MB23 EZ404U 385 700 17.29 1591/92 8.0 8.0 3500 3100 4000 11 16 41
173 116 144 14 2.3 K302_0175 MB23 EZ404U 385 700 17.29 1591/92 12 8.0 3500 3100 4000 11 16 41
173 124 134 15 2.1 K302_0175 MB23 EZ502U 385 700 17.29 1591/92 8.0 8.0 3500 3100 4000 13 16 40
173 124 134 15 2.1 K302_0175 MB23 EZ502U 385 700 17.29 1591/92 12 8.0 3500 3100 4000 13 16 40
173 163 186 20 1.6 K302_0175 MB23 EZ503U 385 700 17.29 1591/92 8.0 15 3500 3100 4000 17 16 42
177 71 77 8.9 3.7 K302_0170 MB23 EZ501U 263 700 16.94 559/33 8.0 8.0 3800 3500 4000 11 16 39
177 71 77 8.9 3.7 K302_0170 MB23 EZ501U 263 700 16.94 559/33 12 8.0 3800 3500 4000 11 16 39
177 77 85 9.7 3.4 K302_0170 MB23 EZ402U 263 700 16.94 559/33 8.0 8.0 3800 3500 4000 9.5 16 38
177 77 85 9.7 3.4 K302_0170 MB23 EZ402U 263 700 16.94 559/33 12 8.0 3800 3500 4000 9.5 16 38
177 113 141 14 2.3 K302_0170 MB23 EZ404U 385 700 16.94 559/33 8.0 8.0 3800 3500 4000 11 16 41
177 113 141 14 2.3 K302_0170 MB23 EZ404U 385 700 16.94 559/33 12 8.0 3800 3500 4000 11 16 41
177 122 131 15 2.2 K302_0170 MB23 EZ502U 385 700 16.94 559/33 8.0 8.0 3800 3500 4000 13 16 40
177 122 131 15 2.2 K302_0170 MB23 EZ502U 385 700 16.94 559/33 12 8.0 3800 3500 4000 13 16 40
177 159 182 20 1.6 K302_0170 MB23 EZ503U 385 700 16.94 559/33 8.0 15 3800 3500 4000 17 16 42
215 58 64 9.0 4.2 K302_0140 MB23 EZ501U 216 700 13.94 1505/108 8.0 8.0 3500 3100 4000 11 16 39
215 58 64 9.0 4.2 K302_0140 MB23 EZ501U 216 700 13.94 1505/108 12 8.0 3500 3100 4000 11 16 39
215 58 64 9.0 4.2 K302_0140 MB23 EZ501U 216 700 13.94 1505/108 16 8.0 3500 3100 4000 11 16 39
215 64 70 9.9 3.9 K302_0140 MB23 EZ402U 216 700 13.94 1505/108 8.0 8.0 3500 3100 4000 10 16 38
215 64 70 9.9 3.9 K302_0140 MB23 EZ402U 216 700 13.94 1505/108 12 8.0 3500 3100 4000 10 16 38
215 64 70 9.9 3.9 K302_0140 MB23 EZ402U 216 700 13.94 1505/108 16 8.0 3500 3100 4000 10 16 38
215 93 116 15 2.6 K302_0140 MB23 EZ404U 385 700 13.94 1505/108 8.0 8.0 3500 3100 4000 11 16 41
215 93 116 15 2.6 K302_0140 MB23 EZ404U 385 700 13.94 1505/108 12 8.0 3500 3100 4000 11 16 41
215 93 116 15 2.6 K302_0140 MB23 EZ404U 385 700 13.94 1505/108 16 8.0 3500 3100 4000 11 16 41
215 100 108 16 2.5 K302_0140 MB23 EZ502U 385 700 13.94 1505/108 8.0 8.0 3500 3100 4000 14 16 40
215 100 108 16 2.5 K302_0140 MB23 EZ502U 385 700 13.94 1505/108 12 8.0 3500 3100 4000 14 16 40
215 100 108 16 2.5 K302_0140 MB23 EZ502U 385 700 13.94 1505/108 16 8.0 3500 3100 4000 14 16 40
215 131 150 20 1.9 K302_0140 MB23 EZ503U 385 700 13.94 1505/108 8.0 15 3500 3100 4000 17 16 42
215 131 150 20 1.9 K302_0140 MB23 EZ503U 385 700 13.94 1505/108 12 15 3500 3100 4000 17 16 42
239 52 57 9.1 4.5 K302_0125 MB23 EZ501U 195 700 12.58 3182/253 8.0 8.0 3500 3100 4000 11 16 39
239 52 57 9.1 4.5 K302_0125 MB23 EZ501U 195 700 12.58 3182/253 12 8.0 3500 3100 4000 11 16 39
239 52 57 9.1 4.5 K302_0125 MB23 EZ501U 195 700 12.58 3182/253 16 8.0 3500 3100 4000 11 16 39
239 57 63 10 4.1 K302_0125 MB23 EZ402U 195 700 12.58 3182/253 8.0 8.0 3500 3100 4000 9.8 16 38
239 57 63 10 4.1 K302_0125 MB23 EZ402U 195 700 12.58 3182/253 12 8.0 3500 3100 4000 9.8 16 38
239 57 63 10 4.1 K302_0125 MB23 EZ402U 195 700 12.58 3182/253 16 8.0 3500 3100 4000 9.8 16 38
239 84 105 15 2.8 K302_0125 MB23 EZ404U 354 700 12.58 3182/253 8.0 8.0 3500 3100 4000 11 16 41
239 84 105 15 2.8 K302_0125 MB23 EZ404U 354 700 12.58 3182/253 12 8.0 3500 3100 4000 11 16 41
239 84 105 15 2.8 K302_0125 MB23 EZ404U 354 700 12.58 3182/253 16 8.0 3500 3100 4000 11 16 41
239 90 98 16 2.6 K302_0125 MB23 EZ502U 378 700 12.58 3182/253 8.0 8.0 3500 3100 4000 13 16 40
239 90 98 16 2.6 K302_0125 MB23 EZ502U 378 700 12.58 3182/253 12 8.0 3500 3100 4000 13 16 40
239 90 98 16 2.6 K302_0125 MB23 EZ502U 378 700 12.58 3182/253 16 8.0 3500 3100 4000 13 16 40
239 90 101 16 2.6 K302_0125 MB33 EZ701U 244 700 12.58 3182/253 16 15 3500 3100 4000 38 16 50
239 118 135 21 2.0 K302_0125 MB23 EZ503U 385 700 12.58 3182/253 8.0 15 3500 3100 4000 17 16 42
239 118 135 21 2.0 K302_0125 MB23 EZ503U 385 700 12.58 3182/253 12 15 3500 3100 4000 17 16 42
239 146 176 25 1.6 K302_0125 MB33 EZ702U 385 700 12.58 3182/253 16 15 3500 3100 4000 44 16 52
258 48 53 9.2 4.8 K302_0115 MB23 EZ501U 180 700 11.61 1161/100 8.0 8.0 3200 2800 4000 12 16 39
258 48 53 9.2 4.8 K302_0115 MB23 EZ501U 180 700 11.61 1161/100 12 8.0 3200 2800 4000 12 16 39
258 48 53 9.2 4.8 K302_0115 MB23 EZ501U 180 700 11.61 1161/100 16 8.0 3200 2800 4000 12 16 39
258 53 59 10 4.4 K302_0115 MB23 EZ402U 180 700 11.61 1161/100 8.0 8.0 3200 2800 4000 10 16 38
258 53 59 10 4.4 K302_0115 MB23 EZ402U 180 700 11.61 1161/100 12 8.0 3200 2800 4000 10 16 38
258 53 59 10 4.4 K302_0115 MB23 EZ402U 180 700 11.61 1161/100 16 8.0 3200 2800 4000 10 16 38
258 78 97 15 3.0 K302_0115 MB23 EZ404U 327 700 11.61 1161/100 8.0 8.0 3200 2800 4000 12 16 41
258 78 97 15 3.0 K302_0115 MB23 EZ404U 327 700 11.61 1161/100 12 8.0 3200 2800 4000 12 16 41
258 78 97 15 3.0 K302_0115 MB23 EZ404U 327 700 11.61 1161/100 16 8.0 3200 2800 4000 12 16 41
258 83 90 16 2.8 K302_0115 MB23 EZ502U 349 700 11.61 1161/100 8.0 8.0 3200 2800 4000 14 16 40
258 83 90 16 2.8 K302_0115 MB23 EZ502U 349 700 11.61 1161/100 12 8.0 3200 2800 4000 14 16 40
10.2 Selection tables 10 Khelical bevel geared motors
304
