n
2N
M
2N
M
2,0
a
th
S Type M
2acc
M
2NOT
i i
exakt
M
1Bstat
M
Bstat
n
1maxDB
n
1maxZB
J
1
C
2
m
EL1,2 EL3,4,5,6
[rpm] [Nm] [Nm] [Nm] [Nm] [Nm] [Nm] [rpm] [rpm] [rpm] [kgcm²] [Nm/ [kg]
arcmin]
K3 (n
1N
= 3000 rpm, M
2acc,max
= 390 Nm)
258 83 90 16 2.8 K302_0115 MB23 EZ502U 349 700 11.61 1161/100 16 8.0 3200 2800 4000 14 16 40
258 83 93 16 2.8 K302_0115 MB33 EZ701U 225 700 11.61 1161/100 16 15 3200 2800 4000 39 16 50
258 109 125 21 2.1 K302_0115 MB23 EZ503U 385 700 11.61 1161/100 8.0 15 3200 2800 4000 17 16 42
258 109 125 21 2.1 K302_0115 MB23 EZ503U 385 700 11.61 1161/100 12 15 3200 2800 4000 17 16 42
258 135 162 26 1.7 K302_0115 MB33 EZ702U 385 700 11.61 1161/100 16 15 3200 2800 4000 44 16 52
258 152 180 29 1.5 K302_0115 MB23 EZ505U 385 700 11.61 1161/100 8.0 15 3200 2800 4000 22 16 45
258 152 180 29 1.5 K302_0115 MB23 EZ505U 385 700 11.61 1161/100 12 15 3200 2800 4000 22 16 45
296 46 51 10 4.8 K302_0100 MB23 EZ402U 157 619 10.14 3010/297 8.0 8.0 3500 3100 4000 10 16 38
296 46 51 10 4.8 K302_0100 MB23 EZ402U 157 619 10.14 3010/297 12 8.0 3500 3100 4000 10 16 38
296 46 51 10 4.8 K302_0100 MB23 EZ402U 157 619 10.14 3010/297 16 8.0 3500 3100 4000 10 16 38
296 68 85 15 3.3 K302_0100 MB23 EZ404U 285 619 10.14 3010/297 8.0 8.0 3500 3100 4000 12 16 41
296 68 85 15 3.3 K302_0100 MB23 EZ404U 285 619 10.14 3010/297 12 8.0 3500 3100 4000 12 16 41
296 68 85 15 3.3 K302_0100 MB23 EZ404U 285 619 10.14 3010/297 16 8.0 3500 3100 4000 12 16 41
296 73 79 16 3.0 K302_0100 MB23 EZ502U 305 619 10.14 3010/297 8.0 8.0 3500 3100 4000 14 16 40
296 73 79 16 3.0 K302_0100 MB23 EZ502U 305 619 10.14 3010/297 12 8.0 3500 3100 4000 14 16 40
296 73 79 16 3.0 K302_0100 MB23 EZ502U 305 619 10.14 3010/297 16 8.0 3500 3100 4000 14 16 40
296 73 82 16 3.0 K302_0100 MB33 EZ701U 197 700 10.14 3010/297 16 15 3500 3100 4000 39 16 50
296 73 82 16 3.0 K302_0100 MB33 EZ701U 197 700 10.14 3010/297 24 15 3500 3100 4000 39 16 50
296 95 109 21 2.3 K302_0100 MB23 EZ503U 369 619 10.14 3010/297 8.0 15 3500 3100 4000 17 16 42
296 95 109 21 2.3 K302_0100 MB23 EZ503U 369 619 10.14 3010/297 12 15 3500 3100 4000 17 16 42
296 118 142 26 1.9 K302_0100 MB33 EZ702U 385 700 10.14 3010/297 16 15 3500 3100 4000 44 16 52
296 118 142 26 1.9 K302_0100 MB33 EZ702U 385 700 10.14 3010/297 24 15 3500 3100 4000 44 16 52
296 133 157 29 1.7 K302_0100 MB23 EZ505U 369 619 10.14 3010/297 8.0 15 3500 3100 4000 22 16 45
296 133 157 29 1.7 K302_0100 MB23 EZ505U 369 619 10.14 3010/297 12 15 3500 3100 4000 22 16 45
324 62 77 15 3.5 K302_0093 MB23 EZ404U 261 566 9.267 1075/116 8.0 8.0 3200 2800 4000 12 16 41
324 62 77 15 3.5 K302_0093 MB23 EZ404U 261 566 9.267 1075/116 12 8.0 3200 2800 4000 12 16 41
324 62 77 15 3.5 K302_0093 MB23 EZ404U 261 566 9.267 1075/116 16 8.0 3200 2800 4000 12 16 41
324 67 72 16 3.2 K302_0093 MB23 EZ502U 279 566 9.267 1075/116 8.0 8.0 3200 2800 4000 14 16 40
324 67 72 16 3.2 K302_0093 MB23 EZ502U 279 566 9.267 1075/116 12 8.0 3200 2800 4000 14 16 40
324 67 72 16 3.2 K302_0093 MB23 EZ502U 279 566 9.267 1075/116 16 8.0 3200 2800 4000 14 16 40
324 67 75 16 3.2 K302_0093 MB33 EZ701U 180 700 9.267 1075/116 16 15 3200 2800 4000 39 16 50
324 67 75 16 3.2 K302_0093 MB33 EZ701U 180 700 9.267 1075/116 24 15 3200 2800 4000 39 16 50
324 87 100 21 2.5 K302_0093 MB23 EZ503U 337 566 9.267 1075/116 8.0 15 3200 2800 4000 18 16 42
324 87 100 21 2.5 K302_0093 MB23 EZ503U 337 566 9.267 1075/116 12 15 3200 2800 4000 18 16 42
324 108 129 26 2.0 K302_0093 MB33 EZ702U 369 700 9.267 1075/116 16 15 3200 2800 4000 45 16 52
324 108 129 26 2.0 K302_0093 MB33 EZ702U 369 700 9.267 1075/116 24 15 3200 2800 4000 45 16 52
324 121 144 29 1.8 K302_0093 MB23 EZ505U 337 566 9.267 1075/116 8.0 15 3200 2800 4000 23 16 45
324 121 144 29 1.8 K302_0093 MB23 EZ505U 337 566 9.267 1075/116 12 15 3200 2800 4000 23 16 45
355 57 70 15 3.7 K302_0084 MB23 EZ404U 238 516 8.444 2322/275 8.0 8.0 3200 2800 4000 12 16 41
355 57 70 15 3.7 K302_0084 MB23 EZ404U 238 516 8.444 2322/275 12 8.0 3200 2800 4000 12 16 41
355 57 70 15 3.7 K302_0084 MB23 EZ404U 238 516 8.444 2322/275 16 8.0 3200 2800 4000 12 16 41
355 61 66 16 3.4 K302_0084 MB23 EZ502U 254 516 8.444 2322/275 8.0 8.0 3200 2800 4000 14 16 40
355 61 66 16 3.4 K302_0084 MB23 EZ502U 254 516 8.444 2322/275 12 8.0 3200 2800 4000 14 16 40
355 61 66 16 3.4 K302_0084 MB23 EZ502U 254 516 8.444 2322/275 16 8.0 3200 2800 4000 14 16 40
355 61 68 16 3.4 K302_0084 MB33 EZ701U 164 700 8.444 2322/275 16 15 3200 2800 4000 39 16 50
355 61 68 16 3.4 K302_0084 MB33 EZ701U 164 700 8.444 2322/275 24 15 3200 2800 4000 39 16 50
355 61 68 16 3.4 K302_0084 MB33 EZ701U 164 700 8.444 2322/275 32 15 3200 2800 4000 39 16 50
355 79 91 21 2.6 K302_0084 MB23 EZ503U 307 516 8.444 2322/275 8.0 15 3200 2800 4000 18 16 42
355 79 91 21 2.6 K302_0084 MB23 EZ503U 307 516 8.444 2322/275 12 15 3200 2800 4000 18 16 42
355 98 118 26 2.1 K302_0084 MB33 EZ702U 336 700 8.444 2322/275 16 15 3200 2800 4000 44 16 52
355 98 118 26 2.1 K302_0084 MB33 EZ702U 336 700 8.444 2322/275 24 15 3200 2800 4000 44 16 52
355 98 118 26 2.1 K302_0084 MB33 EZ702U 336 700 8.444 2322/275 32 15 3200 2800 4000 44 16 52
355 111 131 30 1.9 K302_0084 MB23 EZ505U 307 516 8.444 2322/275 8.0 15 3200 2800 4000 22 16 45
355 111 131 30 1.9 K302_0084 MB23 EZ505U 307 516 8.444 2322/275 12 15 3200 2800 4000 22 16 45
406 49 62 15 4.0 K302_0074 MB23 EZ404U 208 452 7.391 473/64 8.0 8.0 2700 2300 4000 13 16 41
406 49 62 15 4.0 K302_0074 MB23 EZ404U 208 452 7.391 473/64 12 8.0 2700 2300 4000 13 16 41
406 49 62 15 4.0 K302_0074 MB23 EZ404U 208 452 7.391 473/64 16 8.0 2700 2300 4000 13 16 41
406 53 57 16 3.7 K302_0074 MB23 EZ502U 222 452 7.391 473/64 8.0 8.0 2700 2300 4000 15 16 40
406 53 57 16 3.7 K302_0074 MB23 EZ502U 222 452 7.391 473/64 12 8.0 2700 2300 4000 15 16 40
406 53 57 16 3.7 K302_0074 MB23 EZ502U 222 452 7.391 473/64 16 8.0 2700 2300 4000 15 16 40
406 53 60 16 3.7 K302_0074 MB33 EZ701U 143 700 7.391 473/64 16 15 2700 2300 4000 40 16 50
406 53 60 16 3.7 K302_0074 MB33 EZ701U 143 700 7.391 473/64 24 15 2700 2300 4000 40 16 50
406 53 60 16 3.7 K302_0074 MB33 EZ701U 143 700 7.391 473/64 32 15 2700 2300 4000 40 16 50
406 70 80 22 2.9 K302_0074 MB23 EZ503U 269 452 7.391 473/64 8.0 15 2700 2300 4000 19 16 42
10 Khelical bevel geared motors 10.2 Selection tables
