n
2N
M
2N
M
2,0
a
th
S Type M
2acc
M
2NOT
i i
exakt
M
1Bstat
M
Bstat
n
1maxDB
n
1maxZB
J
1
C
2
m
EL1,2 EL3,4,5,6
[rpm] [Nm] [Nm] [Nm] [Nm] [Nm] [Nm] [rpm] [rpm] [rpm] [kgcm²] [Nm/ [kg]
arcmin]
K3 (n
1N
= 3000 rpm, M
2acc,max
= 390 Nm)
406 70 80 22 2.9 K302_0074 MB23 EZ503U 269 452 7.391 473/64 12 15 2700 2300 4000 19 16 42
406 86 103 27 2.3 K302_0074 MB33 EZ702U 294 700 7.391 473/64 16 15 2700 2300 4000 45 16 52
406 86 103 27 2.3 K302_0074 MB33 EZ702U 294 700 7.391 473/64 24 15 2700 2300 4000 45 16 52
406 86 103 27 2.3 K302_0074 MB33 EZ702U 294 700 7.391 473/64 32 15 2700 2300 4000 45 16 52
406 97 115 30 2.1 K302_0074 MB23 EZ505U 269 452 7.391 473/64 8.0 15 2700 2300 4000 23 16 45
406 97 115 30 2.1 K302_0074 MB23 EZ505U 269 452 7.391 473/64 12 15 2700 2300 4000 23 16 45
406 118 149 37 1.7 K302_0074 MB33 EZ703U 375 700 7.391 473/64 16 32 2700 2300 4000 57 16 55
445 45 56 15 4.3 K302_0067 MB23 EZ404U 190 412 6.740 2150/319 8.0 8.0 3200 2800 4000 13 16 41
445 45 56 15 4.3 K302_0067 MB23 EZ404U 190 412 6.740 2150/319 12 8.0 3200 2800 4000 13 16 41
445 45 56 15 4.3 K302_0067 MB23 EZ404U 190 412 6.740 2150/319 16 8.0 3200 2800 4000 13 16 41
445 48 52 17 4.0 K302_0067 MB23 EZ502U 203 412 6.740 2150/319 8.0 8.0 3200 2800 4000 15 16 40
445 48 52 17 4.0 K302_0067 MB23 EZ502U 203 412 6.740 2150/319 12 8.0 3200 2800 4000 15 16 40
445 48 52 17 4.0 K302_0067 MB23 EZ502U 203 412 6.740 2150/319 16 8.0 3200 2800 4000 15 16 40
445 48 54 17 4.0 K302_0067 MB33 EZ701U 131 700 6.740 2150/319 16 15 3200 2800 4000 40 16 50
445 48 54 17 4.0 K302_0067 MB33 EZ701U 131 700 6.740 2150/319 24 15 3200 2800 4000 40 16 50
445 48 54 17 4.0 K302_0067 MB33 EZ701U 131 700 6.740 2150/319 32 15 3200 2800 4000 40 16 50
445 48 54 17 4.0 K302_0067 MB33 EZ701U 131 700 6.740 2150/319 45 15 3200 2800 4000 40 16 50
445 63 73 22 3.0 K302_0067 MB23 EZ503U 245 412 6.740 2150/319 8.0 15 3200 2800 4000 18 16 42
445 63 73 22 3.0 K302_0067 MB23 EZ503U 245 412 6.740 2150/319 12 15 3200 2800 4000 18 16 42
445 78 94 27 2.5 K302_0067 MB33 EZ702U 268 700 6.740 2150/319 16 15 3200 2800 4000 45 16 52
445 78 94 27 2.5 K302_0067 MB33 EZ702U 268 700 6.740 2150/319 24 15 3200 2800 4000 45 16 52
445 78 94 27 2.5 K302_0067 MB33 EZ702U 268 700 6.740 2150/319 32 15 3200 2800 4000 45 16 52
445 78 94 27 2.5 K302_0067 MB33 EZ702U 268 700 6.740 2150/319 45 15 3200 2800 4000 45 16 52
445 88 105 30 2.2 K302_0067 MB23 EZ505U 245 412 6.740 2150/319 8.0 15 3200 2800 4000 23 16 45
445 88 105 30 2.2 K302_0067 MB23 EZ505U 245 412 6.740 2150/319 12 15 3200 2800 4000 23 16 45
445 108 136 37 1.8 K302_0067 MB33 EZ703U 364 700 6.740 2150/319 16 32 3200 2800 4000 57 16 55
445 108 136 37 1.8 K302_0067 MB33 EZ703U 364 700 6.740 2150/319 24 32 3200 2800 4000 57 16 55
500 40 50 16 4.6 K302_0060 MB23 EZ404U 169 367 6.000 6/1 8.0 8.0 2700 2300 4000 14 16 41
500 40 50 16 4.6 K302_0060 MB23 EZ404U 169 367 6.000 6/1 12 8.0 2700 2300 4000 14 16 41
500 40 50 16 4.6 K302_0060 MB23 EZ404U 169 367 6.000 6/1 16 8.0 2700 2300 4000 14 16 41
500 43 47 17 4.3 K302_0060 MB23 EZ502U 180 367 6.000 6/1 8.0 8.0 2700 2300 4000 16 16 40
500 43 47 17 4.3 K302_0060 MB23 EZ502U 180 367 6.000 6/1 12 8.0 2700 2300 4000 16 16 40
500 43 47 17 4.3 K302_0060 MB23 EZ502U 180 367 6.000 6/1 16 8.0 2700 2300 4000 16 16 40
500 43 48 17 4.3 K302_0060 MB33 EZ701U 116 700 6.000 6/1 16 15 2700 2300 4000 41 16 50
500 43 48 17 4.3 K302_0060 MB33 EZ701U 116 700 6.000 6/1 24 15 2700 2300 4000 41 16 50
500 43 48 17 4.3 K302_0060 MB33 EZ701U 116 700 6.000 6/1 32 15 2700 2300 4000 41 16 50
500 43 48 17 4.3 K302_0060 MB33 EZ701U 116 700 6.000 6/1 45 15 2700 2300 4000 41 16 50
500 56 65 22 3.3 K302_0060 MB23 EZ503U 218 367 6.000 6/1 8.0 15 2700 2300 4000 20 16 42
500 56 65 22 3.3 K302_0060 MB23 EZ503U 218 367 6.000 6/1 12 15 2700 2300 4000 20 16 42
500 70 84 27 2.7 K302_0060 MB33 EZ702U 239 700 6.000 6/1 16 15 2700 2300 4000 46 16 52
500 70 84 27 2.7 K302_0060 MB33 EZ702U 239 700 6.000 6/1 24 15 2700 2300 4000 46 16 52
500 70 84 27 2.7 K302_0060 MB33 EZ702U 239 700 6.000 6/1 32 15 2700 2300 4000 46 16 52
500 70 84 27 2.7 K302_0060 MB33 EZ702U 239 700 6.000 6/1 45 15 2700 2300 4000 46 16 52
500 79 93 30 2.4 K302_0060 MB23 EZ505U 218 367 6.000 6/1 8.0 15 2700 2300 4000 24 16 45
500 79 93 30 2.4 K302_0060 MB23 EZ505U 218 367 6.000 6/1 12 15 2700 2300 4000 24 16 45
500 96 121 37 1.9 K302_0060 MB33 EZ703U 350 700 6.000 6/1 16 32 2700 2300 4000 58 16 55
500 96 121 37 1.9 K302_0060 MB33 EZ703U 350 700 6.000 6/1 24 32 2700 2300 4000 58 16 55
500 96 121 37 1.9 K302_0060 MB33 EZ703U 350 700 6.000 6/1 32 32 2700 2300 4000 58 16 55
558 36 45 16 5.0 K302_0054 MB23 EZ404U 151 328 5.375 43/8 8.0 8.0 2700 2300 4000 14 16 41
558 36 45 16 5.0 K302_0054 MB23 EZ404U 151 328 5.375 43/8 12 8.0 2700 2300 4000 14 16 41
558 36 45 16 5.0 K302_0054 MB23 EZ404U 151 328 5.375 43/8 16 8.0 2700 2300 4000 14 16 41
558 39 42 17 4.6 K302_0054 MB23 EZ502U 162 328 5.375 43/8 8.0 8.0 2700 2300 4000 16 16 40
558 39 42 17 4.6 K302_0054 MB23 EZ502U 162 328 5.375 43/8 12 8.0 2700 2300 4000 16 16 40
558 39 42 17 4.6 K302_0054 MB23 EZ502U 162 328 5.375 43/8 16 8.0 2700 2300 4000 16 16 40
558 39 43 17 4.6 K302_0054 MB33 EZ701U 104 603 5.375 43/8 16 15 2700 2300 4000 41 16 50
558 39 43 17 4.6 K302_0054 MB33 EZ701U 104 603 5.375 43/8 24 15 2700 2300 4000 41 16 50
558 39 43 17 4.6 K302_0054 MB33 EZ701U 104 603 5.375 43/8 32 15 2700 2300 4000 41 16 50
558 39 43 17 4.6 K302_0054 MB33 EZ701U 104 603 5.375 43/8 45 15 2700 2300 4000 41 16 50
558 51 58 22 3.5 K302_0054 MB23 EZ503U 196 328 5.375 43/8 8.0 15 2700 2300 4000 19 16 42
558 51 58 22 3.5 K302_0054 MB23 EZ503U 196 328 5.375 43/8 12 15 2700 2300 4000 19 16 42
558 63 75 27 2.9 K302_0054 MB33 EZ702U 214 603 5.375 43/8 16 15 2700 2300 4000 46 16 52
558 63 75 27 2.9 K302_0054 MB33 EZ702U 214 603 5.375 43/8 24 15 2700 2300 4000 46 16 52
558 63 75 27 2.9 K302_0054 MB33 EZ702U 214 603 5.375 43/8 32 15 2700 2300 4000 46 16 52
558 63 75 27 2.9 K302_0054 MB33 EZ702U 214 603 5.375 43/8 45 15 2700 2300 4000 46 16 52
10.2 Selection tables 10 Khelical bevel geared motors
