n
2N
M
2N
M
2,0
a
th
S Type M
2acc
M
2NOT
i i
exakt
M
1Bstat
M
Bstat
n
1maxDB
n
1maxZB
J
1
C
2
m
EL1,2 EL3,4,5,6
[rpm] [Nm] [Nm] [Nm] [Nm] [Nm] [Nm] [rpm] [rpm] [rpm] [kgcm²] [Nm/ [kg]
arcmin]
K3 (n
1N
= 3000 rpm, M
2acc,max
= 390 Nm)
558 70 83 31 2.5 K302_0054 MB23 EZ505U 196 328 5.375 43/8 8.0 15 2700 2300 4000 24 16 45
558 70 83 31 2.5 K302_0054 MB23 EZ505U 196 328 5.375 43/8 12 15 2700 2300 4000 24 16 45
558 86 108 38 2.1 K302_0054 MB33 EZ703U 337 603 5.375 43/8 16 32 2700 2300 4000 58 16 55
558 86 108 38 2.1 K302_0054 MB33 EZ703U 337 603 5.375 43/8 24 32 2700 2300 4000 58 16 55
558 111 157 48 1.6 K302_0054 MB33 EZ705U 337 603 5.375 43/8 16 32 2700 2300 4000 70 16 60
558 111 157 48 1.6 K302_0054 MB33 EZ705U 337 603 5.375 43/8 24 32 2700 2300 4000 70 16 60
687 41 47 24 3.9 K302_0044 MB23 EZ503U 159 267 4.364 48/11 8.0 15 2700 2300 4000 20 16 42
687 41 47 24 3.9 K302_0044 MB23 EZ503U 159 267 4.364 48/11 12 15 2700 2300 4000 20 16 42
687 51 61 28 3.3 K302_0044 MB33 EZ702U 174 700 4.364 48/11 16 15 2700 2300 4000 47 16 52
687 51 61 28 3.3 K302_0044 MB33 EZ702U 174 700 4.364 48/11 24 15 2700 2300 4000 47 16 52
687 51 61 28 3.3 K302_0044 MB33 EZ702U 174 700 4.364 48/11 32 15 2700 2300 4000 47 16 52
687 51 61 28 3.3 K302_0044 MB33 EZ702U 174 700 4.364 48/11 45 15 2700 2300 4000 47 16 52
687 57 68 33 2.8 K302_0044 MB23 EZ505U 159 267 4.364 48/11 8.0 15 2700 2300 4000 25 16 45
687 57 68 33 2.8 K302_0044 MB23 EZ505U 159 267 4.364 48/11 12 15 2700 2300 4000 25 16 45
687 70 88 38 2.4 K302_0044 MB33 EZ703U 275 700 4.364 48/11 16 32 2700 2300 4000 59 16 55
687 70 88 38 2.4 K302_0044 MB33 EZ703U 275 700 4.364 48/11 24 32 2700 2300 4000 59 16 55
687 70 88 38 2.4 K302_0044 MB33 EZ703U 275 700 4.364 48/11 32 32 2700 2300 4000 59 16 55
687 70 88 38 2.4 K302_0044 MB33 EZ703U 275 700 4.364 48/11 45 32 2700 2300 4000 59 16 55
687 90 128 49 1.8 K302_0044 MB33 EZ705U 315 700 4.364 48/11 16 32 2700 2300 4000 71 16 60
687 90 128 49 1.8 K302_0044 MB33 EZ705U 315 700 4.364 48/11 24 32 2700 2300 4000 71 16 60
687 90 128 49 1.8 K302_0044 MB33 EZ705U 315 700 4.364 48/11 32 32 2700 2300 4000 71 16 60
687 90 128 49 1.8 K302_0044 MB33 EZ705U 315 700 4.364 48/11 45 32 2700 2300 4000 71 16 60
750 38 43 25 3.9 K302_0040 MB23 EZ503U 146 244 4.000 4/1 8.0 15 2700 2300 4000 21 16 42
750 38 43 25 3.9 K302_0040 MB23 EZ503U 146 244 4.000 4/1 12 15 2700 2300 4000 21 16 42
750 47 56 28 3.5 K302_0040 MB33 EZ702U 159 700 4.000 4/1 16 15 2700 2300 4000 48 16 52
750 47 56 28 3.5 K302_0040 MB33 EZ702U 159 700 4.000 4/1 24 15 2700 2300 4000 48 16 52
750 47 56 28 3.5 K302_0040 MB33 EZ702U 159 700 4.000 4/1 32 15 2700 2300 4000 48 16 52
750 47 56 28 3.5 K302_0040 MB33 EZ702U 159 700 4.000 4/1 45 15 2700 2300 4000 48 16 52
750 52 62 35 2.8 K302_0040 MB23 EZ505U 146 244 4.000 4/1 8.0 15 2700 2300 4000 26 16 45
750 52 62 35 2.8 K302_0040 MB23 EZ505U 146 244 4.000 4/1 12 15 2700 2300 4000 26 16 45
750 64 81 38 2.5 K302_0040 MB33 EZ703U 252 700 4.000 4/1 16 32 2700 2300 4000 60 16 55
750 64 81 38 2.5 K302_0040 MB33 EZ703U 252 700 4.000 4/1 24 32 2700 2300 4000 60 16 55
750 64 81 38 2.5 K302_0040 MB33 EZ703U 252 700 4.000 4/1 32 32 2700 2300 4000 60 16 55
750 64 81 38 2.5 K302_0040 MB33 EZ703U 252 700 4.000 4/1 45 32 2700 2300 4000 60 16 55
750 83 117 50 2.0 K302_0040 MB33 EZ705U 306 700 4.000 4/1 16 32 2700 2300 4000 72 16 60
750 83 117 50 2.0 K302_0040 MB33 EZ705U 306 700 4.000 4/1 24 32 2700 2300 4000 72 16 60
750 83 117 50 2.0 K302_0040 MB33 EZ705U 306 700 4.000 4/1 32 32 2700 2300 4000 72 16 60
750 83 117 50 2.0 K302_0040 MB33 EZ705U 306 700 4.000 4/1 45 32 2700 2300 4000 72 16 60
K4 (n
1N
= 2000 rpm, M
2acc,max
= 470 Nm)
458 185 280 64 1.5 K402_0044 MB43 EZ805U 472 1078 4.364 48/11 50 115 2600 2200 3000 271 31 121
500 170 256 65 1.6 K402_0040 MB43 EZ805U 459 1078 4.000 4/1 50 115 2600 2200 3000 273 31 121
K4 (n
1N
= 3000 rpm, M
2acc,max
= 600 Nm)
86 145 158 6.1 3.4 K402_0350 MB23 EZ501U 539 1100 34.76 4171/120 8.0 8.0 3600 3300 4000 11 31 52
86 158 175 6.7 3.1 K402_0350 MB23 EZ402U 539 1100 34.76 4171/120 8.0 8.0 3600 3300 4000 9.4 31 52
86 233 290 9.8 2.1 K402_0350 MB23 EZ404U 600 1100 34.76 4171/120 8.0 8.0 3600 3300 4000 11 31 54
86 249 270 10 2.0 K402_0350 MB23 EZ502U 600 1100 34.76 4171/120 8.0 8.0 3600 3300 4000 13 31 54
108 116 127 6.2 4.0 K402_0280 MB23 EZ501U 431 1100 27.77 1333/48 8.0 8.0 3600 3300 4000 11 31 52
108 116 127 6.2 4.0 K402_0280 MB23 EZ501U 431 1100 27.77 1333/48 12 8.0 3600 3300 4000 11 31 52
108 127 140 6.8 3.7 K402_0280 MB23 EZ402U 431 1100 27.77 1333/48 8.0 8.0 3600 3300 4000 9.6 31 52
108 127 140 6.8 3.7 K402_0280 MB23 EZ402U 431 1100 27.77 1333/48 12 8.0 3600 3300 4000 9.6 31 52
108 186 232 10 2.5 K402_0280 MB23 EZ404U 600 1100 27.77 1333/48 8.0 8.0 3600 3300 4000 11 31 54
108 186 232 10 2.5 K402_0280 MB23 EZ404U 600 1100 27.77 1333/48 12 8.0 3600 3300 4000 11 31 54
108 199 216 11 2.3 K402_0280 MB23 EZ502U 600 1100 27.77 1333/48 8.0 8.0 3600 3300 4000 13 31 54
108 199 216 11 2.3 K402_0280 MB23 EZ502U 600 1100 27.77 1333/48 12 8.0 3600 3300 4000 13 31 54
119 105 115 6.3 4.3 K402_0250 MB23 EZ501U 392 1001 25.28 4171/165 8.0 8.0 3600 3300 4000 11 31 52
119 105 115 6.3 4.3 K402_0250 MB23 EZ501U 392 1001 25.28 4171/165 12 8.0 3600 3300 4000 11 31 52
119 115 128 6.8 3.9 K402_0250 MB23 EZ402U 392 1001 25.28 4171/165 8.0 8.0 3600 3300 4000 9.5 31 52
119 115 128 6.8 3.9 K402_0250 MB23 EZ402U 392 1001 25.28 4171/165 12 8.0 3600 3300 4000 9.5 31 52
119 169 211 10 2.7 K402_0250 MB23 EZ404U 600 1001 25.28 4171/165 8.0 8.0 3600 3300 4000 11 31 54
119 169 211 10 2.7 K402_0250 MB23 EZ404U 600 1001 25.28 4171/165 12 8.0 3600 3300 4000 11 31 54
119 181 196 11 2.5 K402_0250 MB23 EZ502U 600 1001 25.28 4171/165 8.0 8.0 3600 3300 4000 13 31 54
119 181 196 11 2.5 K402_0250 MB23 EZ502U 600 1001 25.28 4171/165 12 8.0 3600 3300 4000 13 31 54
129 97 106 6.3 4.5 K402_0230 MB23 EZ501U 361 1100 23.29 559/24 8.0 8.0 3600 3300 4000 11 31 52
129 97 106 6.3 4.5 K402_0230 MB23 EZ501U 361 1100 23.29 559/24 12 8.0 3600 3300 4000 11 31 52
