Stober PK - Page 308

n
2N
M
2N
M
2,0
a
th
S Type M
2acc
M
2NOT
i i
exakt
M
1Bstat
M
Bstat
n
1maxDB
n
1maxZB
J
1
C
2
m
EL1,2 EL3,4,5,6
[rpm] [Nm] [Nm] [Nm] [Nm] [Nm] [Nm] [rpm] [rpm] [rpm] [kgcm²] [Nm/ [kg]
arcmin]
K4 (n
1N
= 3000 rpm, M
2acc,max
= 600 Nm)
129 97 106 6.3 4.5 K402_0230 MB23 EZ501U 361 1100 23.29 559/24 16 8.0 3600 3300 4000 11 31 52
129 106 117 6.9 4.1 K402_0230 MB23 EZ402U 361 1100 23.29 559/24 8.0 8.0 3600 3300 4000 9.9 31 52
129 106 117 6.9 4.1 K402_0230 MB23 EZ402U 361 1100 23.29 559/24 12 8.0 3600 3300 4000 9.9 31 52
129 106 117 6.9 4.1 K402_0230 MB23 EZ402U 361 1100 23.29 559/24 16 8.0 3600 3300 4000 9.9 31 52
129 156 194 10 2.8 K402_0230 MB23 EZ404U 600 1100 23.29 559/24 8.0 8.0 3600 3300 4000 11 31 54
129 156 194 10 2.8 K402_0230 MB23 EZ404U 600 1100 23.29 559/24 12 8.0 3600 3300 4000 11 31 54
129 156 194 10 2.8 K402_0230 MB23 EZ404U 600 1100 23.29 559/24 16 8.0 3600 3300 4000 11 31 54
129 167 181 11 2.6 K402_0230 MB23 EZ502U 600 1100 23.29 559/24 8.0 8.0 3600 3300 4000 13 31 54
129 167 181 11 2.6 K402_0230 MB23 EZ502U 600 1100 23.29 559/24 12 8.0 3600 3300 4000 13 31 54
129 167 181 11 2.6 K402_0230 MB23 EZ502U 600 1100 23.29 559/24 16 8.0 3600 3300 4000 13 31 54
129 219 251 14 2.0 K402_0230 MB23 EZ503U 600 1100 23.29 559/24 8.0 15 3600 3300 4000 17 31 56
129 219 251 14 2.0 K402_0230 MB23 EZ503U 600 1100 23.29 559/24 12 15 3600 3300 4000 17 31 56
149 84 92 6.4 4.9 K402_0200 MB23 EZ501U 313 1100 20.20 1333/66 8.0 8.0 3600 3300 4000 11 31 52
149 84 92 6.4 4.9 K402_0200 MB23 EZ501U 313 1100 20.20 1333/66 12 8.0 3600 3300 4000 11 31 52
149 84 92 6.4 4.9 K402_0200 MB23 EZ501U 313 1100 20.20 1333/66 16 8.0 3600 3300 4000 11 31 52
149 92 102 7.0 4.5 K402_0200 MB23 EZ402U 313 1100 20.20 1333/66 8.0 8.0 3600 3300 4000 9.7 31 52
149 92 102 7.0 4.5 K402_0200 MB23 EZ402U 313 1100 20.20 1333/66 12 8.0 3600 3300 4000 9.7 31 52
149 92 102 7.0 4.5 K402_0200 MB23 EZ402U 313 1100 20.20 1333/66 16 8.0 3600 3300 4000 9.7 31 52
149 135 168 10 3.1 K402_0200 MB23 EZ404U 568 1100 20.20 1333/66 8.0 8.0 3600 3300 4000 11 31 54
149 135 168 10 3.1 K402_0200 MB23 EZ404U 568 1100 20.20 1333/66 12 8.0 3600 3300 4000 11 31 54
149 135 168 10 3.1 K402_0200 MB23 EZ404U 568 1100 20.20 1333/66 16 8.0 3600 3300 4000 11 31 54
149 145 157 11 2.9 K402_0200 MB23 EZ502U 600 1100 20.20 1333/66 8.0 8.0 3600 3300 4000 13 31 54
149 145 157 11 2.9 K402_0200 MB23 EZ502U 600 1100 20.20 1333/66 12 8.0 3600 3300 4000 13 31 54
149 145 157 11 2.9 K402_0200 MB23 EZ502U 600 1100 20.20 1333/66 16 8.0 3600 3300 4000 13 31 54
149 145 163 11 2.9 K402_0200 MB33 EZ701U 392 1100 20.20 1333/66 16 15 3600 3300 4000 38 31 63
149 190 217 14 2.2 K402_0200 MB23 EZ503U 600 1100 20.20 1333/66 8.0 15 3600 3300 4000 17 31 56
149 190 217 14 2.2 K402_0200 MB23 EZ503U 600 1100 20.20 1333/66 12 15 3600 3300 4000 17 31 56
149 235 282 18 1.8 K402_0200 MB33 EZ702U 600 1100 20.20 1333/66 16 15 3600 3300 4000 43 31 66
149 264 313 20 1.6 K402_0200 MB23 EZ505U 600 1100 20.20 1333/66 8.0 15 3600 3300 4000 21 31 58
149 264 313 20 1.6 K402_0200 MB23 EZ505U 600 1100 20.20 1333/66 12 15 3600 3300 4000 21 31 58
172 79 88 7.1 5.0 K402_0175 MB23 EZ402U 270 1064 17.41 731/42 8.0 8.0 3400 3000 4000 10 31 52
172 79 88 7.1 5.0 K402_0175 MB23 EZ402U 270 1064 17.41 731/42 12 8.0 3400 3000 4000 10 31 52
172 79 88 7.1 5.0 K402_0175 MB23 EZ402U 270 1064 17.41 731/42 16 8.0 3400 3000 4000 10 31 52
172 116 145 10 3.4 K402_0175 MB23 EZ404U 490 1064 17.41 731/42 8.0 8.0 3400 3000 4000 12 31 54
172 116 145 10 3.4 K402_0175 MB23 EZ404U 490 1064 17.41 731/42 12 8.0 3400 3000 4000 12 31 54
172 116 145 10 3.4 K402_0175 MB23 EZ404U 490 1064 17.41 731/42 16 8.0 3400 3000 4000 12 31 54
172 125 135 11 3.2 K402_0175 MB23 EZ502U 523 1064 17.41 731/42 8.0 8.0 3400 3000 4000 14 31 54
172 125 135 11 3.2 K402_0175 MB23 EZ502U 523 1064 17.41 731/42 12 8.0 3400 3000 4000 14 31 54
172 125 135 11 3.2 K402_0175 MB23 EZ502U 523 1064 17.41 731/42 16 8.0 3400 3000 4000 14 31 54
172 125 140 11 3.2 K402_0175 MB33 EZ701U 338 1100 17.41 731/42 16 15 3400 3000 4000 39 31 63
172 164 187 15 2.4 K402_0175 MB23 EZ503U 600 1064 17.41 731/42 8.0 15 3400 3000 4000 17 31 56
172 164 187 15 2.4 K402_0175 MB23 EZ503U 600 1064 17.41 731/42 12 15 3400 3000 4000 17 31 56
172 203 243 18 2.0 K402_0175 MB33 EZ702U 600 1100 17.41 731/42 16 15 3400 3000 4000 44 31 66
172 228 270 20 1.7 K402_0175 MB23 EZ505U 600 1064 17.41 731/42 8.0 15 3400 3000 4000 22 31 58
172 228 270 20 1.7 K402_0175 MB23 EZ505U 600 1064 17.41 731/42 12 15 3400 3000 4000 22 31 58
177 113 141 10 3.5 K402_0170 MB23 EZ404U 476 1035 16.94 559/33 8.0 8.0 3600 3300 4000 11 31 54
177 113 141 10 3.5 K402_0170 MB23 EZ404U 476 1035 16.94 559/33 12 8.0 3600 3300 4000 11 31 54
177 113 141 10 3.5 K402_0170 MB23 EZ404U 476 1035 16.94 559/33 16 8.0 3600 3300 4000 11 31 54
177 122 131 11 3.2 K402_0170 MB23 EZ502U 509 1035 16.94 559/33 8.0 8.0 3600 3300 4000 14 31 54
177 122 131 11 3.2 K402_0170 MB23 EZ502U 509 1035 16.94 559/33 12 8.0 3600 3300 4000 14 31 54
177 122 131 11 3.2 K402_0170 MB23 EZ502U 509 1035 16.94 559/33 16 8.0 3600 3300 4000 14 31 54
177 122 136 11 3.2 K402_0170 MB33 EZ701U 329 1100 16.94 559/33 16 15 3600 3300 4000 39 31 63
177 159 182 15 2.5 K402_0170 MB23 EZ503U 600 1035 16.94 559/33 8.0 15 3600 3300 4000 17 31 56
177 159 182 15 2.5 K402_0170 MB23 EZ503U 600 1035 16.94 559/33 12 15 3600 3300 4000 17 31 56
177 197 237 18 2.0 K402_0170 MB33 EZ702U 600 1100 16.94 559/33 16 15 3600 3300 4000 44 31 66
177 222 263 20 1.8 K402_0170 MB23 EZ505U 600 1035 16.94 559/33 8.0 15 3600 3300 4000 22 31 58
177 222 263 20 1.8 K402_0170 MB23 EZ505U 600 1035 16.94 559/33 12 15 3600 3300 4000 22 31 58
216 93 116 11 4.0 K402_0140 MB23 EZ404U 391 849 13.89 1333/96 8.0 8.0 3400 3000 4000 12 31 54
216 93 116 11 4.0 K402_0140 MB23 EZ404U 391 849 13.89 1333/96 12 8.0 3400 3000 4000 12 31 54
216 93 116 11 4.0 K402_0140 MB23 EZ404U 391 849 13.89 1333/96 16 8.0 3400 3000 4000 12 31 54
216 100 108 11 3.7 K402_0140 MB23 EZ502U 418 849 13.89 1333/96 8.0 8.0 3400 3000 4000 15 31 54
216 100 108 11 3.7 K402_0140 MB23 EZ502U 418 849 13.89 1333/96 12 8.0 3400 3000 4000 15 31 54
216 100 108 11 3.7 K402_0140 MB23 EZ502U 418 849 13.89 1333/96 16 8.0 3400 3000 4000 15 31 54
216 100 112 11 3.7 K402_0140 MB33 EZ701U 269 1100 13.89 1333/96 16 15 3400 3000 4000 39 31 63
10.2 Selection tables 10 Khelical bevel geared motors
