Stober PK - Page 309

n
2N
M
2N
M
2,0
a
th
S Type M
2acc
M
2NOT
i i
exakt
M
1Bstat
M
Bstat
n
1maxDB
n
1maxZB
J
1
C
2
m
EL1,2 EL3,4,5,6
[rpm] [Nm] [Nm] [Nm] [Nm] [Nm] [Nm] [rpm] [rpm] [rpm] [kgcm²] [Nm/ [kg]
arcmin]
K4 (n
1N
= 3000 rpm, M
2acc,max
= 600 Nm)
216 100 112 11 3.7 K402_0140 MB33 EZ701U 269 1100 13.89 1333/96 24 15 3400 3000 4000 39 31 63
216 100 112 11 3.7 K402_0140 MB33 EZ701U 269 1100 13.89 1333/96 32 15 3400 3000 4000 39 31 63
216 131 150 15 2.8 K402_0140 MB23 EZ503U 505 849 13.89 1333/96 8.0 15 3400 3000 4000 18 31 56
216 131 150 15 2.8 K402_0140 MB23 EZ503U 505 849 13.89 1333/96 12 15 3400 3000 4000 18 31 56
216 162 194 18 2.3 K402_0140 MB33 EZ702U 552 1100 13.89 1333/96 16 15 3400 3000 4000 45 31 66
216 162 194 18 2.3 K402_0140 MB33 EZ702U 552 1100 13.89 1333/96 24 15 3400 3000 4000 45 31 66
216 162 194 18 2.3 K402_0140 MB33 EZ702U 552 1100 13.89 1333/96 32 15 3400 3000 4000 45 31 66
216 182 215 21 2.0 K402_0140 MB23 EZ505U 505 849 13.89 1333/96 8.0 15 3400 3000 4000 23 31 58
216 182 215 21 2.0 K402_0140 MB23 EZ505U 505 849 13.89 1333/96 12 15 3400 3000 4000 23 31 58
237 85 106 11 4.2 K402_0125 MB23 EZ404U 356 774 12.66 2924/231 8.0 8.0 3400 3000 4000 12 31 54
237 85 106 11 4.2 K402_0125 MB23 EZ404U 356 774 12.66 2924/231 12 8.0 3400 3000 4000 12 31 54
237 85 106 11 4.2 K402_0125 MB23 EZ404U 356 774 12.66 2924/231 16 8.0 3400 3000 4000 12 31 54
237 91 98 11 3.9 K402_0125 MB23 EZ502U 381 774 12.66 2924/231 8.0 8.0 3400 3000 4000 14 31 54
237 91 98 11 3.9 K402_0125 MB23 EZ502U 381 774 12.66 2924/231 12 8.0 3400 3000 4000 14 31 54
237 91 98 11 3.9 K402_0125 MB23 EZ502U 381 774 12.66 2924/231 16 8.0 3400 3000 4000 14 31 54
237 91 102 11 3.9 K402_0125 MB33 EZ701U 246 1100 12.66 2924/231 16 15 3400 3000 4000 39 31 63
237 91 102 11 3.9 K402_0125 MB33 EZ701U 246 1100 12.66 2924/231 24 15 3400 3000 4000 39 31 63
237 91 102 11 3.9 K402_0125 MB33 EZ701U 246 1100 12.66 2924/231 32 15 3400 3000 4000 39 31 63
237 119 136 15 3.0 K402_0125 MB23 EZ503U 460 774 12.66 2924/231 8.0 15 3400 3000 4000 18 31 56
237 119 136 15 3.0 K402_0125 MB23 EZ503U 460 774 12.66 2924/231 12 15 3400 3000 4000 18 31 56
237 147 177 18 2.4 K402_0125 MB33 EZ702U 503 1100 12.66 2924/231 16 15 3400 3000 4000 44 31 66
237 147 177 18 2.4 K402_0125 MB33 EZ702U 503 1100 12.66 2924/231 24 15 3400 3000 4000 44 31 66
237 147 177 18 2.4 K402_0125 MB33 EZ702U 503 1100 12.66 2924/231 32 15 3400 3000 4000 44 31 66
237 166 196 21 2.1 K402_0125 MB23 EZ505U 460 774 12.66 2924/231 8.0 15 3400 3000 4000 22 31 58
237 166 196 21 2.1 K402_0125 MB23 EZ505U 460 774 12.66 2924/231 12 15 3400 3000 4000 22 31 58
260 77 96 11 4.5 K402_0115 MB23 EZ404U 324 704 11.52 645/56 8.0 8.0 3000 2600 4000 13 31 54
260 77 96 11 4.5 K402_0115 MB23 EZ404U 324 704 11.52 645/56 12 8.0 3000 2600 4000 13 31 54
260 77 96 11 4.5 K402_0115 MB23 EZ404U 324 704 11.52 645/56 16 8.0 3000 2600 4000 13 31 54
260 83 89 11 4.2 K402_0115 MB23 EZ502U 346 704 11.52 645/56 8.0 8.0 3000 2600 4000 15 31 54
260 83 89 11 4.2 K402_0115 MB23 EZ502U 346 704 11.52 645/56 12 8.0 3000 2600 4000 15 31 54
260 83 89 11 4.2 K402_0115 MB23 EZ502U 346 704 11.52 645/56 16 8.0 3000 2600 4000 15 31 54
260 83 93 11 4.2 K402_0115 MB33 EZ701U 223 1100 11.52 645/56 16 15 3000 2600 4000 40 31 63
260 83 93 11 4.2 K402_0115 MB33 EZ701U 223 1100 11.52 645/56 24 15 3000 2600 4000 40 31 63
260 83 93 11 4.2 K402_0115 MB33 EZ701U 223 1100 11.52 645/56 32 15 3000 2600 4000 40 31 63
260 108 124 15 3.2 K402_0115 MB23 EZ503U 419 704 11.52 645/56 8.0 15 3000 2600 4000 19 31 56
260 108 124 15 3.2 K402_0115 MB23 EZ503U 419 704 11.52 645/56 12 15 3000 2600 4000 19 31 56
260 134 161 19 2.6 K402_0115 MB33 EZ702U 458 1100 11.52 645/56 16 15 3000 2600 4000 45 31 66
260 134 161 19 2.6 K402_0115 MB33 EZ702U 458 1100 11.52 645/56 24 15 3000 2600 4000 45 31 66
260 134 161 19 2.6 K402_0115 MB33 EZ702U 458 1100 11.52 645/56 32 15 3000 2600 4000 45 31 66
260 151 179 21 2.3 K402_0115 MB23 EZ505U 419 704 11.52 645/56 8.0 15 3000 2600 4000 23 31 58
260 151 179 21 2.3 K402_0115 MB23 EZ505U 419 704 11.52 645/56 12 15 3000 2600 4000 23 31 58
260 184 232 26 1.9 K402_0115 MB33 EZ703U 600 1100 11.52 645/56 16 32 3000 2600 4000 57 31 68
297 68 84 11 4.9 K402_0100 MB23 EZ404U 284 617 10.10 1333/132 8.0 8.0 3400 3000 4000 13 31 54
297 68 84 11 4.9 K402_0100 MB23 EZ404U 284 617 10.10 1333/132 12 8.0 3400 3000 4000 13 31 54
297 68 84 11 4.9 K402_0100 MB23 EZ404U 284 617 10.10 1333/132 16 8.0 3400 3000 4000 13 31 54
297 72 78 12 4.6 K402_0100 MB23 EZ502U 304 617 10.10 1333/132 8.0 8.0 3400 3000 4000 15 31 54
297 72 78 12 4.6 K402_0100 MB23 EZ502U 304 617 10.10 1333/132 12 8.0 3400 3000 4000 15 31 54
297 72 78 12 4.6 K402_0100 MB23 EZ502U 304 617 10.10 1333/132 16 8.0 3400 3000 4000 15 31 54
297 72 81 12 4.6 K402_0100 MB33 EZ701U 196 1100 10.10 1333/132 16 15 3400 3000 4000 40 31 63
297 72 81 12 4.6 K402_0100 MB33 EZ701U 196 1100 10.10 1333/132 24 15 3400 3000 4000 40 31 63
297 72 81 12 4.6 K402_0100 MB33 EZ701U 196 1100 10.10 1333/132 32 15 3400 3000 4000 40 31 63
297 72 81 12 4.6 K402_0100 MB33 EZ701U 196 1100 10.10 1333/132 45 15 3400 3000 4000 40 31 63
297 95 109 15 3.5 K402_0100 MB23 EZ503U 367 617 10.10 1333/132 8.0 15 3400 3000 4000 18 31 56
297 95 109 15 3.5 K402_0100 MB23 EZ503U 367 617 10.10 1333/132 12 15 3400 3000 4000 18 31 56
297 118 141 19 2.8 K402_0100 MB33 EZ702U 402 1100 10.10 1333/132 16 15 3400 3000 4000 45 31 66
297 118 141 19 2.8 K402_0100 MB33 EZ702U 402 1100 10.10 1333/132 24 15 3400 3000 4000 45 31 66
297 118 141 19 2.8 K402_0100 MB33 EZ702U 402 1100 10.10 1333/132 32 15 3400 3000 4000 45 31 66
297 118 141 19 2.8 K402_0100 MB33 EZ702U 402 1100 10.10 1333/132 45 15 3400 3000 4000 45 31 66
297 132 157 21 2.5 K402_0100 MB23 EZ505U 367 617 10.10 1333/132 8.0 15 3400 3000 4000 23 31 58
297 132 157 21 2.5 K402_0100 MB23 EZ505U 367 617 10.10 1333/132 12 15 3400 3000 4000 23 31 58
297 162 204 26 2.0 K402_0100 MB33 EZ703U 600 1100 10.10 1333/132 16 32 3400 3000 4000 57 31 68
297 162 204 26 2.0 K402_0100 MB33 EZ703U 600 1100 10.10 1333/132 24 32 3400 3000 4000 57 31 68
297 209 296 33 1.6 K402_0100 MB33 EZ705U 600 1100 10.10 1333/132 16 32 3400 3000 4000 69 31 74
297 209 296 33 1.6 K402_0100 MB33 EZ705U 600 1100 10.10 1333/132 24 32 3400 3000 4000 69 31 74
10 Khelical bevel geared motors 10.2 Selection tables
