n
2N
M
2N
M
2,0
a
th
S Type M
2acc
M
2NOT
i i
exakt
M
1Bstat
M
Bstat
n
1maxDB
n
1maxZB
J
1
C
2
m
EL1,2 EL3,4,5,6
[rpm] [Nm] [Nm] [Nm] [Nm] [Nm] [Nm] [rpm] [rpm] [rpm] [kgcm²] [Nm/ [kg]
arcmin]
K4 (n
1N
= 3000 rpm, M
2acc,max
= 600 Nm)
500 70 84 20 4.0 K402_0060 MB33 EZ702U 239 1100 6.000 6/1 16 15 2600 2200 3800 50 31 66
500 70 84 20 4.0 K402_0060 MB33 EZ702U 239 1100 6.000 6/1 24 15 2600 2200 3800 50 31 66
500 70 84 20 4.0 K402_0060 MB33 EZ702U 239 1100 6.000 6/1 32 15 2600 2200 3800 50 31 66
500 70 84 20 4.0 K402_0060 MB33 EZ702U 239 1100 6.000 6/1 45 15 2600 2200 3800 50 31 66
500 96 121 27 2.9 K402_0060 MB33 EZ703U 378 1100 6.000 6/1 16 32 2600 2200 3800 61 31 68
500 96 121 27 2.9 K402_0060 MB33 EZ703U 378 1100 6.000 6/1 24 32 2600 2200 3800 61 31 68
500 96 121 27 2.9 K402_0060 MB33 EZ703U 378 1100 6.000 6/1 32 32 2600 2200 3800 61 31 68
500 96 121 27 2.9 K402_0060 MB33 EZ703U 378 1100 6.000 6/1 45 32 2600 2200 3800 61 31 68
500 124 176 35 2.2 K402_0060 MB33 EZ705U 525 1100 6.000 6/1 16 32 2600 2200 3800 74 31 74
500 124 176 35 2.2 K402_0060 MB33 EZ705U 525 1100 6.000 6/1 24 32 2600 2200 3800 74 31 74
500 124 176 35 2.2 K402_0060 MB33 EZ705U 525 1100 6.000 6/1 32 32 2600 2200 3800 74 31 74
500 124 176 35 2.2 K402_0060 MB33 EZ705U 525 1100 6.000 6/1 45 32 2600 2200 3800 74 31 74
500 155 281 44 1.8 K402_0060 MB43 EZ803U 525 1100 6.000 6/1 50 65 2600 2200 3000 182 31 105
553 63 76 20 4.3 K402_0054 MB33 EZ702U 216 994 5.422 1849/341 16 15 2600 2200 3800 49 31 66
553 63 76 20 4.3 K402_0054 MB33 EZ702U 216 994 5.422 1849/341 24 15 2600 2200 3800 49 31 66
553 63 76 20 4.3 K402_0054 MB33 EZ702U 216 994 5.422 1849/341 32 15 2600 2200 3800 49 31 66
553 63 76 20 4.3 K402_0054 MB33 EZ702U 216 994 5.422 1849/341 45 15 2600 2200 3800 49 31 66
553 87 109 27 3.1 K402_0054 MB33 EZ703U 342 994 5.422 1849/341 16 32 2600 2200 3800 61 31 68
553 87 109 27 3.1 K402_0054 MB33 EZ703U 342 994 5.422 1849/341 24 32 2600 2200 3800 61 31 68
553 87 109 27 3.1 K402_0054 MB33 EZ703U 342 994 5.422 1849/341 32 32 2600 2200 3800 61 31 68
553 87 109 27 3.1 K402_0054 MB33 EZ703U 342 994 5.422 1849/341 45 32 2600 2200 3800 61 31 68
553 112 159 35 2.4 K402_0054 MB33 EZ705U 508 994 5.422 1849/341 16 32 2600 2200 3800 73 31 74
553 112 159 35 2.4 K402_0054 MB33 EZ705U 508 994 5.422 1849/341 24 32 2600 2200 3800 73 31 74
553 112 159 35 2.4 K402_0054 MB33 EZ705U 508 994 5.422 1849/341 32 32 2600 2200 3800 73 31 74
553 112 159 35 2.4 K402_0054 MB33 EZ705U 508 994 5.422 1849/341 45 32 2600 2200 3800 73 31 74
553 140 254 44 1.9 K402_0054 MB43 EZ803U 508 1078 5.422 1849/341 50 65 2600 2200 3000 181 31 105
553 140 254 44 1.9 K402_0054 MB43 EZ803U 508 1078 5.422 1849/341 72 65 2600 2200 3000 181 31 105
687 51 61 20 4.9 K402_0044 MB33 EZ702U 174 800 4.364 48/11 16 15 2600 2200 3800 51 31 66
687 51 61 20 4.9 K402_0044 MB33 EZ702U 174 800 4.364 48/11 24 15 2600 2200 3800 51 31 66
687 51 61 20 4.9 K402_0044 MB33 EZ702U 174 800 4.364 48/11 32 15 2600 2200 3800 51 31 66
687 51 61 20 4.9 K402_0044 MB33 EZ702U 174 800 4.364 48/11 45 15 2600 2200 3800 51 31 66
687 70 88 28 3.6 K402_0044 MB33 EZ703U 275 800 4.364 48/11 16 32 2600 2200 3800 63 31 68
687 70 88 28 3.6 K402_0044 MB33 EZ703U 275 800 4.364 48/11 24 32 2600 2200 3800 63 31 68
687 70 88 28 3.6 K402_0044 MB33 EZ703U 275 800 4.364 48/11 32 32 2600 2200 3800 63 31 68
687 70 88 28 3.6 K402_0044 MB33 EZ703U 275 800 4.364 48/11 45 32 2600 2200 3800 63 31 68
687 90 128 36 2.8 K402_0044 MB33 EZ705U 423 800 4.364 48/11 16 32 2600 2200 3800 75 31 74
687 90 128 36 2.8 K402_0044 MB33 EZ705U 423 800 4.364 48/11 24 32 2600 2200 3800 75 31 74
687 90 128 36 2.8 K402_0044 MB33 EZ705U 423 800 4.364 48/11 32 32 2600 2200 3800 75 31 74
687 90 128 36 2.8 K402_0044 MB33 EZ705U 423 800 4.364 48/11 45 32 2600 2200 3800 75 31 74
687 113 204 45 2.2 K402_0044 MB43 EZ803U 472 1078 4.364 48/11 50 65 2600 2200 3000 183 31 105
687 113 204 45 2.2 K402_0044 MB43 EZ803U 472 1078 4.364 48/11 72 65 2600 2200 3000 183 31 105
687 113 204 45 2.2 K402_0044 MB43 EZ803U 472 1078 4.364 48/11 100 65 2600 2200 3000 183 31 105
750 64 81 28 3.8 K402_0040 MB33 EZ703U 252 733 4.000 4/1 16 32 2600 2200 3800 64 31 68
750 64 81 28 3.8 K402_0040 MB33 EZ703U 252 733 4.000 4/1 24 32 2600 2200 3800 64 31 68
750 64 81 28 3.8 K402_0040 MB33 EZ703U 252 733 4.000 4/1 32 32 2600 2200 3800 64 31 68
750 64 81 28 3.8 K402_0040 MB33 EZ703U 252 733 4.000 4/1 45 32 2600 2200 3800 64 31 68
750 83 117 36 2.9 K402_0040 MB33 EZ705U 388 733 4.000 4/1 16 32 2600 2200 3800 77 31 74
750 83 117 36 2.9 K402_0040 MB33 EZ705U 388 733 4.000 4/1 24 32 2600 2200 3800 77 31 74
750 83 117 36 2.9 K402_0040 MB33 EZ705U 388 733 4.000 4/1 32 32 2600 2200 3800 77 31 74
750 83 117 36 2.9 K402_0040 MB33 EZ705U 388 733 4.000 4/1 45 32 2600 2200 3800 77 31 74
750 103 187 45 2.4 K402_0040 MB43 EZ803U 459 1078 4.000 4/1 50 65 2600 2200 3000 184 31 105
750 103 187 45 2.4 K402_0040 MB43 EZ803U 459 1078 4.000 4/1 72 65 2600 2200 3000 184 31 105
750 103 187 45 2.4 K402_0040 MB43 EZ803U 459 1078 4.000 4/1 100 65 2600 2200 3000 184 31 105
K5 (n
1N
= 2000 rpm, M
2acc,max
= 1000 Nm)
272 307 464 48 2.1 K513_0073 MB43 EZ805U 1000 1800 7.347 551/75 50 115 1900 1800 3000 279 50 127
K5 (n
1N
= 3000 rpm, M
2acc,max
= 1000 Nm)
51 240 262 6.2 3.8 K513_0580 MB23 EZ501U 892 1800 58.30 11368/195 8.0 8.0 3400 3000 4000 11 50 58
51 262 290 6.8 3.4 K513_0580 MB23 EZ402U 892 1800 58.30 11368/195 8.0 8.0 3400 3000 4000 9.6 50 58
51 385 479 9.9 2.3 K513_0580 MB23 EZ404U 1000 1800 58.30 11368/195 8.0 8.0 3400 3000 4000 11 50 60
51 412 446 11 2.2 K513_0580 MB23 EZ502U 1000 1800 58.30 11368/195 8.0 8.0 3400 3000 4000 13 50 59
62 198 216 5.8 4.5 K513_0480 MB23 EZ501U 737 1800 48.16 2697/56 8.0 8.0 3400 3000 4000 11 50 58
62 198 216 5.8 4.5 K513_0480 MB23 EZ501U 737 1800 48.16 2697/56 12 8.0 3400 3000 4000 11 50 58
62 216 239 6.4 4.2 K513_0480 MB23 EZ402U 737 1800 48.16 2697/56 8.0 8.0 3400 3000 4000 10 50 58
62 216 239 6.4 4.2 K513_0480 MB23 EZ402U 737 1800 48.16 2697/56 12 8.0 3400 3000 4000 10 50 58
10 Khelical bevel geared motors 10.2 Selection tables
311
