Stober PK - Page 312

n
2N
M
2N
M
2,0
a
th
S Type M
2acc
M
2NOT
i i
exakt
M
1Bstat
M
Bstat
n
1maxDB
n
1maxZB
J
1
C
2
m
EL1,2 EL3,4,5,6
[rpm] [Nm] [Nm] [Nm] [Nm] [Nm] [Nm] [rpm] [rpm] [rpm] [kgcm²] [Nm/ [kg]
arcmin]
K5 (n
1N
= 3000 rpm, M
2acc,max
= 1000 Nm)
62 318 396 9.4 2.8 K513_0480 MB23 EZ404U 1000 1800 48.16 2697/56 8.0 8.0 3400 3000 4000 11 50 60
62 318 396 9.4 2.8 K513_0480 MB23 EZ404U 1000 1800 48.16 2697/56 12 8.0 3400 3000 4000 11 50 60
62 341 368 10 2.6 K513_0480 MB23 EZ502U 1000 1800 48.16 2697/56 8.0 8.0 3400 3000 4000 14 50 59
62 341 368 10 2.6 K513_0480 MB23 EZ502U 1000 1800 48.16 2697/56 12 8.0 3400 3000 4000 14 50 59
69 195 216 6.2 4.6 K513_0440 MB23 EZ402U 665 1800 43.50 87/2 8.0 8.0 3400 3000 4000 10 50 58
69 195 216 6.2 4.6 K513_0440 MB23 EZ402U 665 1800 43.50 87/2 12 8.0 3400 3000 4000 10 50 58
69 287 358 9.1 3.1 K513_0440 MB23 EZ404U 1000 1800 43.50 87/2 8.0 8.0 3400 3000 4000 11 50 60
69 287 358 9.1 3.1 K513_0440 MB23 EZ404U 1000 1800 43.50 87/2 12 8.0 3400 3000 4000 11 50 60
69 308 333 9.8 2.9 K513_0440 MB23 EZ502U 1000 1800 43.50 87/2 8.0 8.0 3400 3000 4000 14 50 59
69 308 333 9.8 2.9 K513_0440 MB23 EZ502U 1000 1800 43.50 87/2 12 8.0 3400 3000 4000 14 50 59
69 403 462 13 2.2 K513_0440 MB23 EZ503U 1000 1800 43.50 87/2 8.0 15 3400 3000 4000 17 50 61
69 561 665 18 1.6 K513_0440 MB23 EZ505U 1000 1800 43.50 87/2 8.0 15 3400 3000 4000 22 50 64
78 254 317 8.8 3.5 K513_0390 MB23 EZ404U 1000 1800 38.53 2697/70 8.0 8.0 3400 3000 4000 12 50 60
78 254 317 8.8 3.5 K513_0390 MB23 EZ404U 1000 1800 38.53 2697/70 12 8.0 3400 3000 4000 12 50 60
78 254 317 8.8 3.5 K513_0390 MB23 EZ404U 1000 1800 38.53 2697/70 16 8.0 3400 3000 4000 12 50 60
78 273 295 9.4 3.3 K513_0390 MB23 EZ502U 1000 1800 38.53 2697/70 8.0 8.0 3400 3000 4000 14 50 59
78 273 295 9.4 3.3 K513_0390 MB23 EZ502U 1000 1800 38.53 2697/70 12 8.0 3400 3000 4000 14 50 59
78 273 295 9.4 3.3 K513_0390 MB23 EZ502U 1000 1800 38.53 2697/70 16 8.0 3400 3000 4000 14 50 59
78 357 409 12 2.5 K513_0390 MB23 EZ503U 1000 1800 38.53 2697/70 8.0 15 3400 3000 4000 18 50 61
78 497 589 17 1.8 K513_0390 MB23 EZ505U 1000 1800 38.53 2697/70 8.0 15 3400 3000 4000 22 50 64
86 230 286 8.5 3.9 K513_0350 MB23 EZ404U 965 1800 34.80 174/5 8.0 8.0 3400 3000 4000 12 50 60
86 230 286 8.5 3.9 K513_0350 MB23 EZ404U 965 1800 34.80 174/5 12 8.0 3400 3000 4000 12 50 60
86 230 286 8.5 3.9 K513_0350 MB23 EZ404U 965 1800 34.80 174/5 16 8.0 3400 3000 4000 12 50 60
86 246 266 9.1 3.7 K513_0350 MB23 EZ502U 1000 1800 34.80 174/5 8.0 8.0 3400 3000 4000 14 50 59
86 246 266 9.1 3.7 K513_0350 MB23 EZ502U 1000 1800 34.80 174/5 12 8.0 3400 3000 4000 14 50 59
86 246 266 9.1 3.7 K513_0350 MB23 EZ502U 1000 1800 34.80 174/5 16 8.0 3400 3000 4000 14 50 59
86 323 369 12 2.8 K513_0350 MB23 EZ503U 1000 1800 34.80 174/5 8.0 15 3400 3000 4000 18 50 61
86 323 369 12 2.8 K513_0350 MB23 EZ503U 1000 1800 34.80 174/5 12 15 3400 3000 4000 18 50 61
86 449 532 17 2.0 K513_0350 MB23 EZ505U 1000 1800 34.80 174/5 8.0 15 3400 3000 4000 22 50 64
86 449 532 17 2.0 K513_0350 MB23 EZ505U 1000 1800 34.80 174/5 12 15 3400 3000 4000 22 50 64
93 213 266 8.3 4.2 K513_0320 MB23 EZ404U 896 1800 32.31 20677/640 8.0 8.0 3400 3000 4000 12 50 60
93 213 266 8.3 4.2 K513_0320 MB23 EZ404U 896 1800 32.31 20677/640 12 8.0 3400 3000 4000 12 50 60
93 213 266 8.3 4.2 K513_0320 MB23 EZ404U 896 1800 32.31 20677/640 16 8.0 3400 3000 4000 12 50 60
93 229 247 8.9 3.9 K513_0320 MB23 EZ502U 957 1800 32.31 20677/640 8.0 8.0 3400 3000 4000 14 50 59
93 229 247 8.9 3.9 K513_0320 MB23 EZ502U 957 1800 32.31 20677/640 12 8.0 3400 3000 4000 14 50 59
93 229 247 8.9 3.9 K513_0320 MB23 EZ502U 957 1800 32.31 20677/640 16 8.0 3400 3000 4000 14 50 59
93 229 256 8.9 3.9 K513_0320 MB33 EZ701U 618 1800 32.31 20677/640 16 15 3400 3000 4000 39 50 69
93 300 343 12 3.0 K513_0320 MB23 EZ503U 1000 1800 32.31 20677/640 8.0 15 3400 3000 4000 18 50 61
93 300 343 12 3.0 K513_0320 MB23 EZ503U 1000 1800 32.31 20677/640 12 15 3400 3000 4000 18 50 61
93 371 445 14 2.4 K513_0320 MB33 EZ702U 1000 1800 32.31 20677/640 16 15 3400 3000 4000 45 50 71
93 417 494 16 2.2 K513_0320 MB23 EZ505U 1000 1800 32.31 20677/640 8.0 15 3400 3000 4000 23 50 64
93 417 494 16 2.2 K513_0320 MB23 EZ505U 1000 1800 32.31 20677/640 12 15 3400 3000 4000 23 50 64
103 192 240 8.3 4.5 K513_0290 MB23 EZ404U 809 1758 29.18 4669/160 8.0 8.0 3400 3000 4000 12 50 60
103 192 240 8.3 4.5 K513_0290 MB23 EZ404U 809 1758 29.18 4669/160 12 8.0 3400 3000 4000 12 50 60
103 192 240 8.3 4.5 K513_0290 MB23 EZ404U 809 1758 29.18 4669/160 16 8.0 3400 3000 4000 12 50 60
103 206 223 8.9 4.2 K513_0290 MB23 EZ502U 865 1758 29.18 4669/160 8.0 8.0 3400 3000 4000 15 50 59
103 206 223 8.9 4.2 K513_0290 MB23 EZ502U 865 1758 29.18 4669/160 12 8.0 3400 3000 4000 15 50 59
103 206 223 8.9 4.2 K513_0290 MB23 EZ502U 865 1758 29.18 4669/160 16 8.0 3400 3000 4000 15 50 59
103 206 232 8.9 4.2 K513_0290 MB33 EZ701U 558 1800 29.18 4669/160 16 15 3400 3000 4000 40 50 69
103 271 310 12 3.2 K513_0290 MB23 EZ503U 1000 1758 29.18 4669/160 8.0 15 3400 3000 4000 18 50 61
103 271 310 12 3.2 K513_0290 MB23 EZ503U 1000 1758 29.18 4669/160 12 15 3400 3000 4000 18 50 61
103 335 402 14 2.6 K513_0290 MB33 EZ702U 1000 1800 29.18 4669/160 16 15 3400 3000 4000 45 50 71
103 377 446 16 2.3 K513_0290 MB23 EZ505U 1000 1758 29.18 4669/160 8.0 15 3400 3000 4000 23 50 64
103 377 446 16 2.3 K513_0290 MB23 EZ505U 1000 1758 29.18 4669/160 12 15 3400 3000 4000 23 50 64
123 172 186 9.0 4.8 K513_0240 MB23 EZ502U 722 1466 24.35 11687/480 8.0 8.0 2800 2500 4000 15 50 59
123 172 186 9.0 4.8 K513_0240 MB23 EZ502U 722 1466 24.35 11687/480 12 8.0 2800 2500 4000 15 50 59
123 172 186 9.0 4.8 K513_0240 MB23 EZ502U 722 1466 24.35 11687/480 16 8.0 2800 2500 4000 15 50 59
123 172 193 9.0 4.8 K513_0240 MB33 EZ701U 466 1800 24.35 11687/480 16 15 2800 2500 4000 40 50 69
123 172 193 9.0 4.8 K513_0240 MB33 EZ701U 466 1800 24.35 11687/480 24 15 2800 2500 4000 40 50 69
123 226 258 12 3.6 K513_0240 MB23 EZ503U 873 1466 24.35 11687/480 8.0 15 2800 2500 4000 19 50 61
123 226 258 12 3.6 K513_0240 MB23 EZ503U 873 1466 24.35 11687/480 12 15 2800 2500 4000 19 50 61
123 279 335 15 2.9 K513_0240 MB33 EZ702U 954 1800 24.35 11687/480 16 15 2800 2500 4000 46 50 71
123 279 335 15 2.9 K513_0240 MB33 EZ702U 954 1800 24.35 11687/480 24 15 2800 2500 4000 46 50 71
123 314 372 16 2.6 K513_0240 MB23 EZ505U 873 1466 24.35 11687/480 8.0 15 2800 2500 4000 24 50 64
