n
2N
M
2N
M
2,0
a
th
S Type M
2acc
M
2NOT
i i
exakt
M
1Bstat
M
Bstat
n
1maxDB
n
1maxZB
J
1
C
2
m
EL1,2 EL3,4,5,6
[rpm] [Nm] [Nm] [Nm] [Nm] [Nm] [Nm] [rpm] [rpm] [rpm] [kgcm²] [Nm/ [kg]
arcmin]
K5 (n
1N
= 3000 rpm, M
2acc,max
= 1000 Nm)
123 314 372 16 2.6 K513_0240 MB23 EZ505U 873 1466 24.35 11687/480 12 15 2800 2500 4000 24 50 64
136 204 233 12 3.9 K513_0220 MB23 EZ503U 788 1325 21.99 2639/120 8.0 15 2800 2500 4000 19 50 61
136 204 233 12 3.9 K513_0220 MB23 EZ503U 788 1325 21.99 2639/120 12 15 2800 2500 4000 19 50 61
136 252 303 15 3.1 K513_0220 MB33 EZ702U 862 1800 21.99 2639/120 16 15 2800 2500 4000 46 50 71
136 252 303 15 3.1 K513_0220 MB33 EZ702U 862 1800 21.99 2639/120 24 15 2800 2500 4000 46 50 71
136 252 303 15 3.1 K513_0220 MB33 EZ702U 862 1800 21.99 2639/120 32 15 2800 2500 4000 46 50 71
136 284 336 17 2.8 K513_0220 MB23 EZ505U 788 1325 21.99 2639/120 8.0 15 2800 2500 4000 24 50 64
136 284 336 17 2.8 K513_0220 MB23 EZ505U 788 1325 21.99 2639/120 12 15 2800 2500 4000 24 50 64
155 179 205 13 3.9 K513_0195 MB23 EZ503U 694 1166 19.35 27869/1440 8.0 15 2800 2500 4000 20 50 61
155 179 205 13 3.9 K513_0195 MB23 EZ503U 694 1166 19.35 27869/1440 12 15 2800 2500 4000 20 50 61
155 222 266 15 3.4 K513_0195 MB33 EZ702U 759 1800 19.35 27869/1440 16 15 2800 2500 4000 47 50 71
155 222 266 15 3.4 K513_0195 MB33 EZ702U 759 1800 19.35 27869/1440 24 15 2800 2500 4000 47 50 71
155 222 266 15 3.4 K513_0195 MB33 EZ702U 759 1800 19.35 27869/1440 32 15 2800 2500 4000 47 50 71
155 250 296 18 2.8 K513_0195 MB23 EZ505U 694 1166 19.35 27869/1440 8.0 15 2800 2500 4000 25 50 64
155 250 296 18 2.8 K513_0195 MB23 EZ505U 694 1166 19.35 27869/1440 12 15 2800 2500 4000 25 50 64
155 305 385 20 2.5 K513_0195 MB33 EZ703U 1000 1800 19.35 27869/1440 16 32 2800 2500 4000 59 50 74
155 394 559 26 1.9 K513_0195 MB33 EZ705U 1000 1800 19.35 27869/1440 16 32 2800 2500 4000 71 50 80
172 162 186 14 3.9 K513_0175 MB23 EZ503U 627 1053 17.48 6293/360 8.0 15 2800 2500 4000 20 50 61
172 162 186 14 3.9 K513_0175 MB23 EZ503U 627 1053 17.48 6293/360 12 15 2800 2500 4000 20 50 61
172 201 241 15 3.7 K513_0175 MB33 EZ702U 685 1800 17.48 6293/360 16 15 2800 2500 4000 47 50 71
172 201 241 15 3.7 K513_0175 MB33 EZ702U 685 1800 17.48 6293/360 24 15 2800 2500 4000 47 50 71
172 201 241 15 3.7 K513_0175 MB33 EZ702U 685 1800 17.48 6293/360 32 15 2800 2500 4000 47 50 71
172 201 241 15 3.7 K513_0175 MB33 EZ702U 685 1800 17.48 6293/360 45 15 2800 2500 4000 47 50 71
172 226 267 19 2.8 K513_0175 MB23 EZ505U 627 1053 17.48 6293/360 8.0 15 2800 2500 4000 25 50 64
172 226 267 19 2.8 K513_0175 MB23 EZ505U 627 1053 17.48 6293/360 12 15 2800 2500 4000 25 50 64
172 276 348 20 2.7 K513_0175 MB33 EZ703U 1000 1800 17.48 6293/360 16 32 2800 2500 4000 59 50 74
172 356 505 26 2.1 K513_0175 MB33 EZ705U 1000 1800 17.48 6293/360 16 32 2800 2500 4000 71 50 80
186 149 171 15 3.9 K513_0160 MB23 EZ503U 577 969 16.09 26071/1620 8.0 15 2300 2200 3600 21 50 61
186 149 171 15 3.9 K513_0160 MB23 EZ503U 577 969 16.09 26071/1620 12 15 2300 2200 3600 21 50 61
186 185 222 15 3.9 K513_0160 MB33 EZ702U 631 1800 16.09 26071/1620 16 15 2300 2200 3600 48 50 71
186 185 222 15 3.9 K513_0160 MB33 EZ702U 631 1800 16.09 26071/1620 24 15 2300 2200 3600 48 50 71
186 185 222 15 3.9 K513_0160 MB33 EZ702U 631 1800 16.09 26071/1620 32 15 2300 2200 3600 48 50 71
186 185 222 15 3.9 K513_0160 MB33 EZ702U 631 1800 16.09 26071/1620 45 15 2300 2200 3600 48 50 71
186 208 246 21 2.8 K513_0160 MB23 EZ505U 577 969 16.09 26071/1620 8.0 15 2300 2200 3600 26 50 64
186 208 246 21 2.8 K513_0160 MB23 EZ505U 577 969 16.09 26071/1620 12 15 2300 2200 3600 26 50 64
186 254 320 20 2.8 K513_0160 MB33 EZ703U 1000 1800 16.09 26071/1620 16 32 2300 2200 3600 60 50 74
186 254 320 20 2.8 K513_0160 MB33 EZ703U 1000 1800 16.09 26071/1620 24 32 2300 2200 3600 60 50 74
186 328 465 26 2.2 K513_0160 MB33 EZ705U 1000 1800 16.09 26071/1620 16 32 2300 2200 3600 72 50 80
186 328 465 26 2.2 K513_0160 MB33 EZ705U 1000 1800 16.09 26071/1620 24 32 2300 2200 3600 72 50 80
206 135 154 16 3.9 K513_0145 MB23 EZ503U 521 875 14.54 5887/405 8.0 15 2300 2200 3600 22 50 61
206 135 154 16 3.9 K513_0145 MB23 EZ503U 521 875 14.54 5887/405 12 15 2300 2200 3600 22 50 61
206 167 200 15 4.1 K513_0145 MB33 EZ702U 570 1800 14.54 5887/405 16 15 2300 2200 3600 48 50 71
206 167 200 15 4.1 K513_0145 MB33 EZ702U 570 1800 14.54 5887/405 24 15 2300 2200 3600 48 50 71
206 167 200 15 4.1 K513_0145 MB33 EZ702U 570 1800 14.54 5887/405 32 15 2300 2200 3600 48 50 71
206 167 200 15 4.1 K513_0145 MB33 EZ702U 570 1800 14.54 5887/405 45 15 2300 2200 3600 48 50 71
206 188 222 22 2.8 K513_0145 MB23 EZ505U 521 875 14.54 5887/405 8.0 15 2300 2200 3600 26 50 64
206 188 222 22 2.8 K513_0145 MB23 EZ505U 521 875 14.54 5887/405 12 15 2300 2200 3600 26 50 64
206 229 289 20 3.0 K513_0145 MB33 EZ703U 903 1800 14.54 5887/405 16 32 2300 2200 3600 60 50 74
206 229 289 20 3.0 K513_0145 MB33 EZ703U 903 1800 14.54 5887/405 24 32 2300 2200 3600 60 50 74
206 229 289 20 3.0 K513_0145 MB33 EZ703U 903 1800 14.54 5887/405 32 32 2300 2200 3600 60 50 74
206 296 420 26 2.3 K513_0145 MB33 EZ705U 1000 1800 14.54 5887/405 16 32 2300 2200 3600 73 50 80
206 296 420 26 2.3 K513_0145 MB33 EZ705U 1000 1800 14.54 5887/405 24 32 2300 2200 3600 73 50 80
206 296 420 26 2.3 K513_0145 MB33 EZ705U 1000 1800 14.54 5887/405 32 32 2300 2200 3600 73 50 80
234 147 176 15 4.5 K513_0130 MB33 EZ702U 502 1800 12.81 1537/120 16 15 2300 2200 3600 50 50 71
234 147 176 15 4.5 K513_0130 MB33 EZ702U 502 1800 12.81 1537/120 24 15 2300 2200 3600 50 50 71
234 147 176 15 4.5 K513_0130 MB33 EZ702U 502 1800 12.81 1537/120 32 15 2300 2200 3600 50 50 71
234 147 176 15 4.5 K513_0130 MB33 EZ702U 502 1800 12.81 1537/120 45 15 2300 2200 3600 50 50 71
234 202 255 20 3.3 K513_0130 MB33 EZ703U 796 1800 12.81 1537/120 16 32 2300 2200 3600 62 50 74
234 202 255 20 3.3 K513_0130 MB33 EZ703U 796 1800 12.81 1537/120 24 32 2300 2200 3600 62 50 74
234 202 255 20 3.3 K513_0130 MB33 EZ703U 796 1800 12.81 1537/120 32 32 2300 2200 3600 62 50 74
234 202 255 20 3.3 K513_0130 MB33 EZ703U 796 1800 12.81 1537/120 45 32 2300 2200 3600 62 50 74
234 261 370 26 2.5 K513_0130 MB33 EZ705U 1000 1800 12.81 1537/120 16 32 2300 2200 3600 74 50 80
234 261 370 26 2.5 K513_0130 MB33 EZ705U 1000 1800 12.81 1537/120 24 32 2300 2200 3600 74 50 80
234 261 370 26 2.5 K513_0130 MB33 EZ705U 1000 1800 12.81 1537/120 32 32 2300 2200 3600 74 50 80
10 Khelical bevel geared motors 10.2 Selection tables
313
