Stober PK - Page 314

n
2N
M
2N
M
2,0
a
th
S Type M
2acc
M
2NOT
i i
exakt
M
1Bstat
M
Bstat
n
1maxDB
n
1maxZB
J
1
C
2
m
EL1,2 EL3,4,5,6
[rpm] [Nm] [Nm] [Nm] [Nm] [Nm] [Nm] [rpm] [rpm] [rpm] [kgcm²] [Nm/ [kg]
arcmin]
K5 (n
1N
= 3000 rpm, M
2acc,max
= 1000 Nm)
234 261 370 26 2.5 K513_0130 MB33 EZ705U 1000 1800 12.81 1537/120 45 32 2300 2200 3600 74 50 80
259 133 159 15 4.8 K513_0115 MB33 EZ702U 453 1800 11.57 10759/930 16 15 2300 2200 3600 51 50 71
259 133 159 15 4.8 K513_0115 MB33 EZ702U 453 1800 11.57 10759/930 24 15 2300 2200 3600 51 50 71
259 133 159 15 4.8 K513_0115 MB33 EZ702U 453 1800 11.57 10759/930 32 15 2300 2200 3600 51 50 71
259 133 159 15 4.8 K513_0115 MB33 EZ702U 453 1800 11.57 10759/930 45 15 2300 2200 3600 51 50 71
259 182 230 21 3.5 K513_0115 MB33 EZ703U 719 1800 11.57 10759/930 16 32 2300 2200 3600 63 50 74
259 182 230 21 3.5 K513_0115 MB33 EZ703U 719 1800 11.57 10759/930 24 32 2300 2200 3600 63 50 74
259 182 230 21 3.5 K513_0115 MB33 EZ703U 719 1800 11.57 10759/930 32 32 2300 2200 3600 63 50 74
259 182 230 21 3.5 K513_0115 MB33 EZ703U 719 1800 11.57 10759/930 45 32 2300 2200 3600 63 50 74
259 236 334 26 2.7 K513_0115 MB33 EZ705U 1000 1800 11.57 10759/930 16 32 2300 2200 3600 75 50 80
259 236 334 26 2.7 K513_0115 MB33 EZ705U 1000 1800 11.57 10759/930 24 32 2300 2200 3600 75 50 80
259 236 334 26 2.7 K513_0115 MB33 EZ705U 1000 1800 11.57 10759/930 32 32 2300 2200 3600 75 50 80
259 236 334 26 2.7 K513_0115 MB33 EZ705U 1000 1800 11.57 10759/930 45 32 2300 2200 3600 75 50 80
296 160 202 21 3.8 K513_0100 MB33 EZ703U 631 1800 10.15 203/20 16 32 1900 1800 3200 65 50 74
296 160 202 21 3.8 K513_0100 MB33 EZ703U 631 1800 10.15 203/20 24 32 1900 1800 3200 65 50 74
296 160 202 21 3.8 K513_0100 MB33 EZ703U 631 1800 10.15 203/20 32 32 1900 1800 3200 65 50 74
296 160 202 21 3.8 K513_0100 MB33 EZ703U 631 1800 10.15 203/20 45 32 1900 1800 3200 65 50 74
296 207 293 27 3.0 K513_0100 MB33 EZ705U 970 1800 10.15 203/20 16 32 1900 1800 3200 77 50 80
296 207 293 27 3.0 K513_0100 MB33 EZ705U 970 1800 10.15 203/20 24 32 1900 1800 3200 77 50 80
296 207 293 27 3.0 K513_0100 MB33 EZ705U 970 1800 10.15 203/20 32 32 1900 1800 3200 77 50 80
296 207 293 27 3.0 K513_0100 MB33 EZ705U 970 1800 10.15 203/20 45 32 1900 1800 3200 77 50 80
296 258 468 33 2.4 K513_0100 MB43 EZ803U 1000 1800 10.15 203/20 50 65 1900 1800 3000 185 50 111
327 145 182 21 4.1 K513_0092 MB33 EZ703U 570 1657 9.168 1421/155 16 32 1900 1800 3200 66 50 74
327 145 182 21 4.1 K513_0092 MB33 EZ703U 570 1657 9.168 1421/155 24 32 1900 1800 3200 66 50 74
327 145 182 21 4.1 K513_0092 MB33 EZ703U 570 1657 9.168 1421/155 32 32 1900 1800 3200 66 50 74
327 145 182 21 4.1 K513_0092 MB33 EZ703U 570 1657 9.168 1421/155 45 32 1900 1800 3200 66 50 74
327 187 265 27 3.2 K513_0092 MB33 EZ705U 876 1657 9.168 1421/155 16 32 1900 1800 3200 78 50 80
327 187 265 27 3.2 K513_0092 MB33 EZ705U 876 1657 9.168 1421/155 24 32 1900 1800 3200 78 50 80
327 187 265 27 3.2 K513_0092 MB33 EZ705U 876 1657 9.168 1421/155 32 32 1900 1800 3200 78 50 80
327 187 265 27 3.2 K513_0092 MB33 EZ705U 876 1657 9.168 1421/155 45 32 1900 1800 3200 78 50 80
327 233 422 33 2.5 K513_0092 MB43 EZ803U 1000 1800 9.168 1421/155 50 65 1900 1800 3000 186 50 111
369 128 162 21 4.4 K513_0081 MB33 EZ703U 505 1470 8.134 17081/2100 16 32 1900 1800 3200 69 50 74
369 128 162 21 4.4 K513_0081 MB33 EZ703U 505 1470 8.134 17081/2100 24 32 1900 1800 3200 69 50 74
369 128 162 21 4.4 K513_0081 MB33 EZ703U 505 1470 8.134 17081/2100 32 32 1900 1800 3200 69 50 74
369 128 162 21 4.4 K513_0081 MB33 EZ703U 505 1470 8.134 17081/2100 45 32 1900 1800 3200 69 50 74
369 166 235 27 3.4 K513_0081 MB33 EZ705U 778 1470 8.134 17081/2100 16 32 1900 1800 3200 81 50 80
369 166 235 27 3.4 K513_0081 MB33 EZ705U 778 1470 8.134 17081/2100 24 32 1900 1800 3200 81 50 80
369 166 235 27 3.4 K513_0081 MB33 EZ705U 778 1470 8.134 17081/2100 32 32 1900 1800 3200 81 50 80
369 166 235 27 3.4 K513_0081 MB33 EZ705U 778 1470 8.134 17081/2100 45 32 1900 1800 3200 81 50 80
369 207 375 33 2.8 K513_0081 MB43 EZ803U 1000 1800 8.134 17081/2100 50 65 1900 1800 3000 189 50 111
369 207 375 33 2.8 K513_0081 MB43 EZ803U 1000 1800 8.134 17081/2100 72 65 1900 1800 3000 189 50 111
408 116 146 21 4.8 K513_0073 MB33 EZ703U 457 1327 7.347 551/75 16 32 1900 1800 3200 70 50 74
408 116 146 21 4.8 K513_0073 MB33 EZ703U 457 1327 7.347 551/75 24 32 1900 1800 3200 70 50 74
408 116 146 21 4.8 K513_0073 MB33 EZ703U 457 1327 7.347 551/75 32 32 1900 1800 3200 70 50 74
408 116 146 21 4.8 K513_0073 MB33 EZ703U 457 1327 7.347 551/75 45 32 1900 1800 3200 70 50 74
408 150 212 27 3.7 K513_0073 MB33 EZ705U 702 1327 7.347 551/75 16 32 1900 1800 3200 83 50 80
408 150 212 27 3.7 K513_0073 MB33 EZ705U 702 1327 7.347 551/75 24 32 1900 1800 3200 83 50 80
408 150 212 27 3.7 K513_0073 MB33 EZ705U 702 1327 7.347 551/75 32 32 1900 1800 3200 83 50 80
408 150 212 27 3.7 K513_0073 MB33 EZ705U 702 1327 7.347 551/75 45 32 1900 1800 3200 83 50 80
408 187 339 34 3.0 K513_0073 MB43 EZ803U 1000 1800 7.347 551/75 50 65 1900 1800 3000 191 50 111
408 187 339 34 3.0 K513_0073 MB43 EZ803U 1000 1800 7.347 551/75 72 65 1900 1800 3000 191 50 111
408 187 339 34 3.0 K513_0073 MB43 EZ803U 1000 1800 7.347 551/75 100 65 1900 1800 3000 191 50 111
K6 (n
1N
= 2000 rpm, M
2acc,max
= 1590 Nm)
175 477 721 40 2.0 K613_0115 MB43 EZ805U 1594 2900 11.41 22631/1984 50 115 2200 2000 3000 278 83 148
247 339 512 40 2.5 K613_0081 MB43 EZ805U 1422 2604 8.107 85095/10496 50 115 1800 1700 3000 290 83 148
273 306 463 40 2.7 K613_0073 MB43 EZ805U 1375 2352 7.323 19215/2624 50 115 1800 1700 3000 292 83 148
K6 (n
1N
= 3000 rpm, M
2acc,max
= 1600 Nm)
39 313 342 4.7 4.5 K613_0760 MB23 EZ501U 1165 2900 76.14 126697/1664 8.0 8.0 3100 2800 4000 11 83 79
39 313 342 4.7 4.5 K613_0760 MB23 EZ501U 1165 2900 76.14 126697/1664 12 8.0 3100 2800 4000 11 83 79
39 342 379 5.1 4.2 K613_0760 MB23 EZ402U 1165 2900 76.14 126697/1664 8.0 8.0 3100 2800 4000 9.8 83 79
39 342 379 5.1 4.2 K613_0760 MB23 EZ402U 1165 2900 76.14 126697/1664 12 8.0 3100 2800 4000 9.8 83 79
39 502 626 7.5 2.8 K613_0760 MB23 EZ404U 1600 2900 76.14 126697/1664 8.0 8.0 3100 2800 4000 11 83 81
39 502 626 7.5 2.8 K613_0760 MB23 EZ404U 1600 2900 76.14 126697/1664 12 8.0 3100 2800 4000 11 83 81
39 539 582 8.0 2.6 K613_0760 MB23 EZ502U 1600 2900 76.14 126697/1664 8.0 8.0 3100 2800 4000 13 83 81
10.2 Selection tables 10 Khelical bevel geared motors
314
