Stober PK - Page 91

n
2N
M
2N
M
2,0
a
th
S Type M
2acc
M
2NOT
i i
exakt
M
1Bstat
M
Bstat
n
1maxDB
n
1maxZB
J
1
C
2
m
EL1,2,3,4 EL5,6
[rpm] [Nm] [Nm] [Nm] [Nm] [Nm] [Nm] [rpm] [rpm] [rpm] [kgcm²] [Nm/ [kg]
arcmin]
C2 (n
1N
= 3000 rpm, M
2acc,max
= 230 Nm)
366 34 37 1.5 5.0 C202_0082 MB23 EZ501U 127 400 8.190 475/58 8.0 8.0 3500 3100 4000 12 8.3 31
366 34 37 1.5 5.0 C202_0082 MB23 EZ501U 127 400 8.190 475/58 12 8.0 3500 3100 4000 12 8.3 31
366 34 37 1.5 5.0 C202_0082 MB23 EZ501U 127 400 8.190 475/58 16 8.0 3500 3100 4000 12 8.3 31
366 37 41 1.7 4.6 C202_0082 MB23 EZ402U 127 400 8.190 475/58 8.0 8.0 3500 3100 4000 11 8.3 31
366 37 41 1.7 4.6 C202_0082 MB23 EZ402U 127 400 8.190 475/58 12 8.0 3500 3100 4000 11 8.3 31
366 37 41 1.7 4.6 C202_0082 MB23 EZ402U 127 400 8.190 475/58 16 8.0 3500 3100 4000 11 8.3 31
366 55 68 2.5 3.1 C202_0082 MB23 EZ404U 230 400 8.190 475/58 8.0 8.0 3500 3100 4000 12 8.3 33
366 55 68 2.5 3.1 C202_0082 MB23 EZ404U 230 400 8.190 475/58 12 8.0 3500 3100 4000 12 8.3 33
366 55 68 2.5 3.1 C202_0082 MB23 EZ404U 230 400 8.190 475/58 16 8.0 3500 3100 4000 12 8.3 33
366 59 64 2.6 2.9 C202_0082 MB23 EZ502U 230 400 8.190 475/58 8.0 8.0 3500 3100 4000 14 8.3 33
366 59 64 2.6 2.9 C202_0082 MB23 EZ502U 230 400 8.190 475/58 12 8.0 3500 3100 4000 14 8.3 33
366 59 64 2.6 2.9 C202_0082 MB23 EZ502U 230 400 8.190 475/58 16 8.0 3500 3100 4000 14 8.3 33
366 77 88 3.5 2.2 C202_0082 MB23 EZ503U 230 400 8.190 475/58 8.0 15 3500 3100 4000 18 8.3 35
366 77 88 3.5 2.2 C202_0082 MB23 EZ503U 230 400 8.190 475/58 12 15 3500 3100 4000 18 8.3 35
366 107 127 4.8 1.6 C202_0082 MB23 EZ505U 230 400 8.190 475/58 8.0 15 3500 3100 4000 22 8.3 38
366 107 127 4.8 1.6 C202_0082 MB23 EZ505U 230 400 8.190 475/58 12 15 3500 3100 4000 22 8.3 38
385 33 36 1.9 4.1 C202_0078 MB23 EZ501U 121 350 7.800 39/5 8.0 8.0 4000 3900 4000 11 6.0 31
385 33 36 1.9 4.1 C202_0078 MB23 EZ501U 121 350 7.800 39/5 12 8.0 4000 3900 4000 11 6.0 31
385 33 36 1.9 4.1 C202_0078 MB23 EZ501U 121 350 7.800 39/5 16 8.0 4000 3900 4000 11 6.0 31
385 36 39 2.1 3.7 C202_0078 MB23 EZ402U 121 350 7.800 39/5 8.0 8.0 4000 3900 4000 9.5 6.0 31
385 36 39 2.1 3.7 C202_0078 MB23 EZ402U 121 350 7.800 39/5 12 8.0 4000 3900 4000 9.5 6.0 31
385 36 39 2.1 3.7 C202_0078 MB23 EZ402U 121 350 7.800 39/5 16 8.0 4000 3900 4000 9.5 6.0 31
385 52 65 3.1 2.5 C202_0078 MB23 EZ404U 200 350 7.800 39/5 8.0 8.0 4000 3900 4000 11 6.0 33
385 52 65 3.1 2.5 C202_0078 MB23 EZ404U 200 350 7.800 39/5 12 8.0 4000 3900 4000 11 6.0 33
385 52 65 3.1 2.5 C202_0078 MB23 EZ404U 200 350 7.800 39/5 16 8.0 4000 3900 4000 11 6.0 33
385 56 61 3.3 2.4 C202_0078 MB23 EZ502U 200 350 7.800 39/5 8.0 8.0 4000 3900 4000 13 6.0 33
385 56 61 3.3 2.4 C202_0078 MB23 EZ502U 200 350 7.800 39/5 12 8.0 4000 3900 4000 13 6.0 33
385 56 61 3.3 2.4 C202_0078 MB23 EZ502U 200 350 7.800 39/5 16 8.0 4000 3900 4000 13 6.0 33
385 73 84 4.4 1.8 C202_0078 MB23 EZ503U 200 350 7.800 39/5 8.0 15 4000 3900 4000 17 6.0 35
477 26 29 1.9 4.7 C202_0063 MB23 EZ501U 98 350 6.295 3330/529 8.0 8.0 3700 3500 4000 11 6.0 31
477 26 29 1.9 4.7 C202_0063 MB23 EZ501U 98 350 6.295 3330/529 12 8.0 3700 3500 4000 11 6.0 31
477 26 29 1.9 4.7 C202_0063 MB23 EZ501U 98 350 6.295 3330/529 16 8.0 3700 3500 4000 11 6.0 31
477 29 32 2.0 4.3 C202_0063 MB23 EZ402U 98 350 6.295 3330/529 8.0 8.0 3700 3500 4000 9.8 6.0 31
477 29 32 2.0 4.3 C202_0063 MB23 EZ402U 98 350 6.295 3330/529 12 8.0 3700 3500 4000 9.8 6.0 31
477 29 32 2.0 4.3 C202_0063 MB23 EZ402U 98 350 6.295 3330/529 16 8.0 3700 3500 4000 9.8 6.0 31
477 42 53 3.0 2.9 C202_0063 MB23 EZ404U 177 350 6.295 3330/529 8.0 8.0 3700 3500 4000 11 6.0 33
477 42 53 3.0 2.9 C202_0063 MB23 EZ404U 177 350 6.295 3330/529 12 8.0 3700 3500 4000 11 6.0 33
477 42 53 3.0 2.9 C202_0063 MB23 EZ404U 177 350 6.295 3330/529 16 8.0 3700 3500 4000 11 6.0 33
477 45 49 3.2 2.7 C202_0063 MB23 EZ502U 189 350 6.295 3330/529 8.0 8.0 3700 3500 4000 13 6.0 33
477 45 49 3.2 2.7 C202_0063 MB23 EZ502U 189 350 6.295 3330/529 12 8.0 3700 3500 4000 13 6.0 33
477 45 49 3.2 2.7 C202_0063 MB23 EZ502U 189 350 6.295 3330/529 16 8.0 3700 3500 4000 13 6.0 33
477 45 51 3.2 2.7 C202_0063 MB33 EZ701U 122 350 6.295 3330/529 16 15 3700 3500 4000 38 6.0 42
477 59 68 4.2 2.1 C202_0063 MB23 EZ503U 200 350 6.295 3330/529 8.0 15 3700 3500 4000 17 6.0 35
477 59 68 4.2 2.1 C202_0063 MB23 EZ503U 200 350 6.295 3330/529 12 15 3700 3500 4000 17 6.0 35
477 73 88 5.2 1.7 C202_0063 MB33 EZ702U 200 350 6.295 3330/529 16 15 3700 3500 4000 44 6.0 45
518 24 26 1.8 5.0 C202_0058 MB23 EZ501U 90 350 5.791 666/115 8.0 8.0 3700 3500 4000 11 6.0 31
518 24 26 1.8 5.0 C202_0058 MB23 EZ501U 90 350 5.791 666/115 12 8.0 3700 3500 4000 11 6.0 31
518 24 26 1.8 5.0 C202_0058 MB23 EZ501U 90 350 5.791 666/115 16 8.0 3700 3500 4000 11 6.0 31
518 26 29 2.0 4.5 C202_0058 MB23 EZ402U 90 350 5.791 666/115 8.0 8.0 3700 3500 4000 9.8 6.0 31
518 26 29 2.0 4.5 C202_0058 MB23 EZ402U 90 350 5.791 666/115 12 8.0 3700 3500 4000 9.8 6.0 31
518 26 29 2.0 4.5 C202_0058 MB23 EZ402U 90 350 5.791 666/115 16 8.0 3700 3500 4000 9.8 6.0 31
518 39 48 3.0 3.1 C202_0058 MB23 EZ404U 163 350 5.791 666/115 8.0 8.0 3700 3500 4000 11 6.0 33
518 39 48 3.0 3.1 C202_0058 MB23 EZ404U 163 350 5.791 666/115 12 8.0 3700 3500 4000 11 6.0 33
518 39 48 3.0 3.1 C202_0058 MB23 EZ404U 163 350 5.791 666/115 16 8.0 3700 3500 4000 11 6.0 33
518 42 45 3.2 2.9 C202_0058 MB23 EZ502U 174 350 5.791 666/115 8.0 8.0 3700 3500 4000 13 6.0 33
518 42 45 3.2 2.9 C202_0058 MB23 EZ502U 174 350 5.791 666/115 12 8.0 3700 3500 4000 13 6.0 33
518 42 45 3.2 2.9 C202_0058 MB23 EZ502U 174 350 5.791 666/115 16 8.0 3700 3500 4000 13 6.0 33
518 42 47 3.2 2.9 C202_0058 MB33 EZ701U 112 350 5.791 666/115 16 15 3700 3500 4000 38 6.0 42
518 54 62 4.2 2.2 C202_0058 MB23 EZ503U 200 350 5.791 666/115 8.0 15 3700 3500 4000 17 6.0 35
518 54 62 4.2 2.2 C202_0058 MB23 EZ503U 200 350 5.791 666/115 12 15 3700 3500 4000 17 6.0 35
518 67 81 5.1 1.8 C202_0058 MB33 EZ702U 200 350 5.791 666/115 16 15 3700 3500 4000 44 6.0 45
518 76 90 5.8 1.6 C202_0058 MB23 EZ505U 200 350 5.791 666/115 8.0 15 3700 3500 4000 21 6.0 38
518 76 90 5.8 1.6 C202_0058 MB23 EZ505U 200 350 5.791 666/115 12 15 3700 3500 4000 21 6.0 38
591 23 26 2.0 5.0 C202_0051 MB23 EZ402U 79 310 5.072 350/69 8.0 8.0 3700 3500 4000 10 6.0 31
5 Chelical geared motors 5.2 Selection tables
