Stober PK - Page 92

n
2N
M
2N
M
2,0
a
th
S Type M
2acc
M
2NOT
i i
exakt
M
1Bstat
M
Bstat
n
1maxDB
n
1maxZB
J
1
C
2
m
EL1,2,3,4 EL5,6
[rpm] [Nm] [Nm] [Nm] [Nm] [Nm] [Nm] [rpm] [rpm] [rpm] [kgcm²] [Nm/ [kg]
arcmin]
C2 (n
1N
= 3000 rpm, M
2acc,max
= 230 Nm)
591 23 26 2.0 5.0 C202_0051 MB23 EZ402U 79 310 5.072 350/69 12 8.0 3700 3500 4000 10 6.0 31
591 23 26 2.0 5.0 C202_0051 MB23 EZ402U 79 310 5.072 350/69 16 8.0 3700 3500 4000 10 6.0 31
591 34 42 2.9 3.4 C202_0051 MB23 EZ404U 143 310 5.072 350/69 8.0 8.0 3700 3500 4000 11 6.0 33
591 34 42 2.9 3.4 C202_0051 MB23 EZ404U 143 310 5.072 350/69 12 8.0 3700 3500 4000 11 6.0 33
591 34 42 2.9 3.4 C202_0051 MB23 EZ404U 143 310 5.072 350/69 16 8.0 3700 3500 4000 11 6.0 33
591 36 39 3.1 3.1 C202_0051 MB23 EZ502U 153 310 5.072 350/69 8.0 8.0 3700 3500 4000 14 6.0 33
591 36 39 3.1 3.1 C202_0051 MB23 EZ502U 153 310 5.072 350/69 12 8.0 3700 3500 4000 14 6.0 33
591 36 39 3.1 3.1 C202_0051 MB23 EZ502U 153 310 5.072 350/69 16 8.0 3700 3500 4000 14 6.0 33
591 36 41 3.1 3.1 C202_0051 MB33 EZ701U 98 350 5.072 350/69 16 15 3700 3500 4000 39 6.0 42
591 36 41 3.1 3.1 C202_0051 MB33 EZ701U 98 350 5.072 350/69 24 15 3700 3500 4000 39 6.0 42
591 48 55 4.1 2.4 C202_0051 MB23 EZ503U 184 310 5.072 350/69 8.0 15 3700 3500 4000 17 6.0 35
591 48 55 4.1 2.4 C202_0051 MB23 EZ503U 184 310 5.072 350/69 12 15 3700 3500 4000 17 6.0 35
591 59 71 5.0 1.9 C202_0051 MB33 EZ702U 200 350 5.072 350/69 16 15 3700 3500 4000 44 6.0 45
591 59 71 5.0 1.9 C202_0051 MB33 EZ702U 200 350 5.072 350/69 24 15 3700 3500 4000 44 6.0 45
591 66 79 5.7 1.7 C202_0051 MB23 EZ505U 184 310 5.072 350/69 8.0 15 3700 3500 4000 22 6.0 38
591 66 79 5.7 1.7 C202_0051 MB23 EZ505U 184 310 5.072 350/69 12 15 3700 3500 4000 22 6.0 38
643 31 39 2.9 3.6 C202_0047 MB23 EZ404U 131 285 4.667 14/3 8.0 8.0 3700 3500 4000 11 6.0 33
643 31 39 2.9 3.6 C202_0047 MB23 EZ404U 131 285 4.667 14/3 12 8.0 3700 3500 4000 11 6.0 33
643 31 39 2.9 3.6 C202_0047 MB23 EZ404U 131 285 4.667 14/3 16 8.0 3700 3500 4000 11 6.0 33
643 34 36 3.1 3.3 C202_0047 MB23 EZ502U 140 285 4.667 14/3 8.0 8.0 3700 3500 4000 14 6.0 33
643 34 36 3.1 3.3 C202_0047 MB23 EZ502U 140 285 4.667 14/3 12 8.0 3700 3500 4000 14 6.0 33
643 34 36 3.1 3.3 C202_0047 MB23 EZ502U 140 285 4.667 14/3 16 8.0 3700 3500 4000 14 6.0 33
643 34 38 3.1 3.3 C202_0047 MB33 EZ701U 91 350 4.667 14/3 16 15 3700 3500 4000 39 6.0 42
643 34 38 3.1 3.3 C202_0047 MB33 EZ701U 91 350 4.667 14/3 24 15 3700 3500 4000 39 6.0 42
643 44 50 4.0 2.5 C202_0047 MB23 EZ503U 170 285 4.667 14/3 8.0 15 3700 3500 4000 17 6.0 35
643 44 50 4.0 2.5 C202_0047 MB23 EZ503U 170 285 4.667 14/3 12 15 3700 3500 4000 17 6.0 35
643 54 65 5.0 2.1 C202_0047 MB33 EZ702U 186 350 4.667 14/3 16 15 3700 3500 4000 44 6.0 45
643 54 65 5.0 2.1 C202_0047 MB33 EZ702U 186 350 4.667 14/3 24 15 3700 3500 4000 44 6.0 45
643 61 72 5.6 1.8 C202_0047 MB23 EZ505U 170 285 4.667 14/3 8.0 15 3700 3500 4000 22 6.0 38
643 61 72 5.6 1.8 C202_0047 MB23 EZ505U 170 285 4.667 14/3 12 15 3700 3500 4000 22 6.0 38
710 28 35 2.8 3.8 C202_0042 MB23 EZ404U 119 258 4.226 486/115 8.0 8.0 3500 3100 4000 12 6.0 33
710 28 35 2.8 3.8 C202_0042 MB23 EZ404U 119 258 4.226 486/115 12 8.0 3500 3100 4000 12 6.0 33
710 28 35 2.8 3.8 C202_0042 MB23 EZ404U 119 258 4.226 486/115 16 8.0 3500 3100 4000 12 6.0 33
710 30 33 3.0 3.6 C202_0042 MB23 EZ502U 127 258 4.226 486/115 8.0 8.0 3500 3100 4000 14 6.0 33
710 30 33 3.0 3.6 C202_0042 MB23 EZ502U 127 258 4.226 486/115 12 8.0 3500 3100 4000 14 6.0 33
710 30 33 3.0 3.6 C202_0042 MB23 EZ502U 127 258 4.226 486/115 16 8.0 3500 3100 4000 14 6.0 33
710 30 34 3.0 3.6 C202_0042 MB33 EZ701U 82 350 4.226 486/115 16 15 3500 3100 4000 39 6.0 42
710 30 34 3.0 3.6 C202_0042 MB33 EZ701U 82 350 4.226 486/115 24 15 3500 3100 4000 39 6.0 42
710 30 34 3.0 3.6 C202_0042 MB33 EZ701U 82 350 4.226 486/115 32 15 3500 3100 4000 39 6.0 42
710 40 46 3.9 2.7 C202_0042 MB23 EZ503U 154 258 4.226 486/115 8.0 15 3500 3100 4000 18 6.0 35
710 40 46 3.9 2.7 C202_0042 MB23 EZ503U 154 258 4.226 486/115 12 15 3500 3100 4000 18 6.0 35
710 49 59 4.9 2.2 C202_0042 MB33 EZ702U 168 350 4.226 486/115 16 15 3500 3100 4000 44 6.0 45
710 49 59 4.9 2.2 C202_0042 MB33 EZ702U 168 350 4.226 486/115 24 15 3500 3100 4000 44 6.0 45
710 49 59 4.9 2.2 C202_0042 MB33 EZ702U 168 350 4.226 486/115 32 15 3500 3100 4000 44 6.0 45
710 55 66 5.5 1.9 C202_0042 MB23 EZ505U 154 258 4.226 486/115 8.0 15 3500 3100 4000 22 6.0 38
710 55 66 5.5 1.9 C202_0042 MB23 EZ505U 154 258 4.226 486/115 12 15 3500 3100 4000 22 6.0 38
772 26 32 2.8 4.0 C202_0039 MB23 EZ404U 109 238 3.888 486/125 8.0 8.0 3500 3100 4000 12 6.0 33
772 26 32 2.8 4.0 C202_0039 MB23 EZ404U 109 238 3.888 486/125 12 8.0 3500 3100 4000 12 6.0 33
772 26 32 2.8 4.0 C202_0039 MB23 EZ404U 109 238 3.888 486/125 16 8.0 3500 3100 4000 12 6.0 33
772 28 30 3.0 3.8 C202_0039 MB23 EZ502U 117 238 3.888 486/125 8.0 8.0 3500 3100 4000 14 6.0 33
772 28 30 3.0 3.8 C202_0039 MB23 EZ502U 117 238 3.888 486/125 12 8.0 3500 3100 4000 14 6.0 33
772 28 30 3.0 3.8 C202_0039 MB23 EZ502U 117 238 3.888 486/125 16 8.0 3500 3100 4000 14 6.0 33
772 28 31 3.0 3.8 C202_0039 MB33 EZ701U 75 350 3.888 486/125 16 15 3500 3100 4000 39 6.0 42
772 28 31 3.0 3.8 C202_0039 MB33 EZ701U 75 350 3.888 486/125 24 15 3500 3100 4000 39 6.0 42
772 28 31 3.0 3.8 C202_0039 MB33 EZ701U 75 350 3.888 486/125 32 15 3500 3100 4000 39 6.0 42
772 37 42 3.9 2.9 C202_0039 MB23 EZ503U 141 238 3.888 486/125 8.0 15 3500 3100 4000 18 6.0 35
772 37 42 3.9 2.9 C202_0039 MB23 EZ503U 141 238 3.888 486/125 12 15 3500 3100 4000 18 6.0 35
772 45 54 4.8 2.3 C202_0039 MB33 EZ702U 155 350 3.888 486/125 16 15 3500 3100 4000 44 6.0 45
772 45 54 4.8 2.3 C202_0039 MB33 EZ702U 155 350 3.888 486/125 24 15 3500 3100 4000 44 6.0 45
772 45 54 4.8 2.3 C202_0039 MB33 EZ702U 155 350 3.888 486/125 32 15 3500 3100 4000 44 6.0 45
772 51 60 5.4 2.1 C202_0039 MB23 EZ505U 141 238 3.888 486/125 8.0 15 3500 3100 4000 22 6.0 38
772 51 60 5.4 2.1 C202_0039 MB23 EZ505U 141 238 3.888 486/125 12 15 3500 3100 4000 22 6.0 38
772 62 78 6.6 1.7 C202_0039 MB33 EZ703U 198 350 3.888 486/125 16 32 3500 3100 4000 56 6.0 48
889 23 28 2.7 4.4 C202_0034 MB23 EZ404U 95 206 3.373 2250/667 8.0 8.0 3500 3100 4000 12 6.0 33
