Stober PK - Page 95

n
2N
M
2N
M
2,0
a
th
S Type M
2acc
M
2NOT
i i
exakt
M
1Bstat
M
Bstat
n
1maxDB
n
1maxZB
J
1
C
2
m
EL1,2,3,4 EL5,6
[rpm] [Nm] [Nm] [Nm] [Nm] [Nm] [Nm] [rpm] [rpm] [rpm] [kgcm²] [Nm/ [kg]
arcmin]
C3 (n
1N
= 3000 rpm, M
2acc,max
= 400 Nm)
193 104 130 1.9 3.2 C302_0155 MB23 EZ404U 400 700 15.54 544/35 12 8.0 3500 3100 4000 11 8.7 38
193 104 130 1.9 3.2 C302_0155 MB23 EZ404U 400 700 15.54 544/35 16 8.0 3500 3100 4000 11 8.7 38
193 112 121 2.1 2.9 C302_0155 MB23 EZ502U 400 700 15.54 544/35 8.0 8.0 3500 3100 4000 14 8.7 38
193 112 121 2.1 2.9 C302_0155 MB23 EZ502U 400 700 15.54 544/35 12 8.0 3500 3100 4000 14 8.7 38
193 112 121 2.1 2.9 C302_0155 MB23 EZ502U 400 700 15.54 544/35 16 8.0 3500 3100 4000 14 8.7 38
193 146 167 2.7 2.2 C302_0155 MB23 EZ503U 400 700 15.54 544/35 8.0 15 3500 3100 4000 17 8.7 40
193 204 241 3.8 1.6 C302_0155 MB23 EZ505U 400 700 15.54 544/35 8.0 15 3500 3100 4000 22 8.7 43
214 64 71 1.3 5.0 C302_0140 MB23 EZ402U 217 700 13.99 2015/144 8.0 8.0 3500 3100 4000 10 8.7 36
214 64 71 1.3 5.0 C302_0140 MB23 EZ402U 217 700 13.99 2015/144 12 8.0 3500 3100 4000 10 8.7 36
214 64 71 1.3 5.0 C302_0140 MB23 EZ402U 217 700 13.99 2015/144 16 8.0 3500 3100 4000 10 8.7 36
214 94 117 1.9 3.4 C302_0140 MB23 EZ404U 350 700 13.99 2015/144 8.0 8.0 3500 3100 4000 12 8.7 38
214 94 117 1.9 3.4 C302_0140 MB23 EZ404U 350 700 13.99 2015/144 12 8.0 3500 3100 4000 12 8.7 38
214 94 117 1.9 3.4 C302_0140 MB23 EZ404U 350 700 13.99 2015/144 16 8.0 3500 3100 4000 12 8.7 38
214 100 109 2.0 3.2 C302_0140 MB23 EZ502U 350 700 13.99 2015/144 8.0 8.0 3500 3100 4000 14 8.7 38
214 100 109 2.0 3.2 C302_0140 MB23 EZ502U 350 700 13.99 2015/144 12 8.0 3500 3100 4000 14 8.7 38
214 100 109 2.0 3.2 C302_0140 MB23 EZ502U 350 700 13.99 2015/144 16 8.0 3500 3100 4000 14 8.7 38
214 132 151 2.7 2.4 C302_0140 MB23 EZ503U 350 700 13.99 2015/144 8.0 15 3500 3100 4000 18 8.7 40
214 132 151 2.7 2.4 C302_0140 MB23 EZ503U 350 700 13.99 2015/144 12 15 3500 3100 4000 18 8.7 40
214 183 217 3.7 1.7 C302_0140 MB23 EZ505U 350 700 13.99 2015/144 8.0 15 3500 3100 4000 22 8.7 43
214 183 217 3.7 1.7 C302_0140 MB23 EZ505U 350 700 13.99 2015/144 12 15 3500 3100 4000 22 8.7 43
242 83 103 1.9 3.7 C302_0125 MB23 EZ404U 349 700 12.40 62/5 8.0 8.0 3500 3100 4000 12 8.7 38
242 83 103 1.9 3.7 C302_0125 MB23 EZ404U 349 700 12.40 62/5 12 8.0 3500 3100 4000 12 8.7 38
242 83 103 1.9 3.7 C302_0125 MB23 EZ404U 349 700 12.40 62/5 16 8.0 3500 3100 4000 12 8.7 38
242 89 96 2.0 3.4 C302_0125 MB23 EZ502U 373 700 12.40 62/5 8.0 8.0 3500 3100 4000 14 8.7 38
242 89 96 2.0 3.4 C302_0125 MB23 EZ502U 373 700 12.40 62/5 12 8.0 3500 3100 4000 14 8.7 38
242 89 96 2.0 3.4 C302_0125 MB23 EZ502U 373 700 12.40 62/5 16 8.0 3500 3100 4000 14 8.7 38
242 89 100 2.0 3.4 C302_0125 MB33 EZ701U 241 700 12.40 62/5 16 15 3500 3100 4000 39 8.7 47
242 117 134 2.6 2.6 C302_0125 MB23 EZ503U 400 700 12.40 62/5 8.0 15 3500 3100 4000 18 8.7 40
242 117 134 2.6 2.6 C302_0125 MB23 EZ503U 400 700 12.40 62/5 12 15 3500 3100 4000 18 8.7 40
242 144 173 3.2 2.1 C302_0125 MB33 EZ702U 400 700 12.40 62/5 16 15 3500 3100 4000 44 8.7 50
242 162 192 3.6 1.9 C302_0125 MB23 EZ505U 400 700 12.40 62/5 8.0 15 3500 3100 4000 22 8.7 43
242 162 192 3.6 1.9 C302_0125 MB23 EZ505U 400 700 12.40 62/5 12 15 3500 3100 4000 22 8.7 43
258 78 97 1.8 3.8 C302_0115 MB23 EZ404U 327 700 11.61 325/28 8.0 8.0 3200 2800 4000 12 8.7 38
258 78 97 1.8 3.8 C302_0115 MB23 EZ404U 327 700 11.61 325/28 12 8.0 3200 2800 4000 12 8.7 38
258 78 97 1.8 3.8 C302_0115 MB23 EZ404U 327 700 11.61 325/28 16 8.0 3200 2800 4000 12 8.7 38
258 83 90 2.0 3.6 C302_0115 MB23 EZ502U 349 700 11.61 325/28 8.0 8.0 3200 2800 4000 14 8.7 38
258 83 90 2.0 3.6 C302_0115 MB23 EZ502U 349 700 11.61 325/28 12 8.0 3200 2800 4000 14 8.7 38
258 83 90 2.0 3.6 C302_0115 MB23 EZ502U 349 700 11.61 325/28 16 8.0 3200 2800 4000 14 8.7 38
258 83 93 2.0 3.6 C302_0115 MB33 EZ701U 225 700 11.61 325/28 16 15 3200 2800 4000 39 8.7 47
258 109 125 2.6 2.7 C302_0115 MB23 EZ503U 350 700 11.61 325/28 8.0 15 3200 2800 4000 18 8.7 40
258 109 125 2.6 2.7 C302_0115 MB23 EZ503U 350 700 11.61 325/28 12 15 3200 2800 4000 18 8.7 40
258 135 162 3.2 2.2 C302_0115 MB33 EZ702U 350 700 11.61 325/28 16 15 3200 2800 4000 45 8.7 50
258 152 180 3.6 2.0 C302_0115 MB23 EZ505U 350 700 11.61 325/28 8.0 15 3200 2800 4000 23 8.7 43
258 152 180 3.6 2.0 C302_0115 MB23 EZ505U 350 700 11.61 325/28 12 15 3200 2800 4000 23 8.7 43
292 69 86 1.8 4.2 C302_0105 MB23 EZ404U 289 629 10.29 72/7 8.0 8.0 3200 2800 4000 12 8.7 38
292 69 86 1.8 4.2 C302_0105 MB23 EZ404U 289 629 10.29 72/7 12 8.0 3200 2800 4000 12 8.7 38
292 69 86 1.8 4.2 C302_0105 MB23 EZ404U 289 629 10.29 72/7 16 8.0 3200 2800 4000 12 8.7 38
292 74 80 1.9 3.9 C302_0105 MB23 EZ502U 309 629 10.29 72/7 8.0 8.0 3200 2800 4000 15 8.7 38
292 74 80 1.9 3.9 C302_0105 MB23 EZ502U 309 629 10.29 72/7 12 8.0 3200 2800 4000 15 8.7 38
292 74 80 1.9 3.9 C302_0105 MB23 EZ502U 309 629 10.29 72/7 16 8.0 3200 2800 4000 15 8.7 38
292 74 83 1.9 3.9 C302_0105 MB33 EZ701U 200 700 10.29 72/7 16 15 3200 2800 4000 39 8.7 47
292 74 83 1.9 3.9 C302_0105 MB33 EZ701U 200 700 10.29 72/7 24 15 3200 2800 4000 39 8.7 47
292 97 111 2.5 3.0 C302_0105 MB23 EZ503U 374 629 10.29 72/7 8.0 15 3200 2800 4000 18 8.7 40
292 97 111 2.5 3.0 C302_0105 MB23 EZ503U 374 629 10.29 72/7 12 15 3200 2800 4000 18 8.7 40
292 120 144 3.1 2.4 C302_0105 MB33 EZ702U 400 700 10.29 72/7 16 15 3200 2800 4000 45 8.7 50
292 120 144 3.1 2.4 C302_0105 MB33 EZ702U 400 700 10.29 72/7 24 15 3200 2800 4000 45 8.7 50
292 135 160 3.5 2.1 C302_0105 MB23 EZ505U 374 629 10.29 72/7 8.0 15 3200 2800 4000 23 8.7 43
292 135 160 3.5 2.1 C302_0105 MB23 EZ505U 374 629 10.29 72/7 12 15 3200 2800 4000 23 8.7 43
322 62 78 1.8 4.4 C302_0093 MB23 EZ404U 262 569 9.310 3575/384 8.0 8.0 3200 2800 4000 13 8.7 38
322 62 78 1.8 4.4 C302_0093 MB23 EZ404U 262 569 9.310 3575/384 12 8.0 3200 2800 4000 13 8.7 38
322 62 78 1.8 4.4 C302_0093 MB23 EZ404U 262 569 9.310 3575/384 16 8.0 3200 2800 4000 13 8.7 38
322 67 72 1.9 4.1 C302_0093 MB23 EZ502U 280 569 9.310 3575/384 8.0 8.0 3200 2800 4000 15 8.7 38
322 67 72 1.9 4.1 C302_0093 MB23 EZ502U 280 569 9.310 3575/384 12 8.0 3200 2800 4000 15 8.7 38
322 67 72 1.9 4.1 C302_0093 MB23 EZ502U 280 569 9.310 3575/384 16 8.0 3200 2800 4000 15 8.7 38
