Stober PK - Page 96

n
2N
M
2N
M
2,0
a
th
S Type M
2acc
M
2NOT
i i
exakt
M
1Bstat
M
Bstat
n
1maxDB
n
1maxZB
J
1
C
2
m
EL1,2,3,4 EL5,6
[rpm] [Nm] [Nm] [Nm] [Nm] [Nm] [Nm] [rpm] [rpm] [rpm] [kgcm²] [Nm/ [kg]
arcmin]
C3 (n
1N
= 3000 rpm, M
2acc,max
= 400 Nm)
322 67 75 1.9 4.1 C302_0093 MB33 EZ701U 181 700 9.310 3575/384 16 15 3200 2800 4000 40 8.7 47
322 67 75 1.9 4.1 C302_0093 MB33 EZ701U 181 700 9.310 3575/384 24 15 3200 2800 4000 40 8.7 47
322 88 100 2.5 3.2 C302_0093 MB23 EZ503U 339 569 9.310 3575/384 8.0 15 3200 2800 4000 19 8.7 40
322 88 100 2.5 3.2 C302_0093 MB23 EZ503U 339 569 9.310 3575/384 12 15 3200 2800 4000 19 8.7 40
322 108 130 3.1 2.6 C302_0093 MB33 EZ702U 350 700 9.310 3575/384 16 15 3200 2800 4000 45 8.7 50
322 108 130 3.1 2.6 C302_0093 MB33 EZ702U 350 700 9.310 3575/384 24 15 3200 2800 4000 45 8.7 50
322 122 144 3.5 2.3 C302_0093 MB23 EZ505U 339 569 9.310 3575/384 8.0 15 3200 2800 4000 23 8.7 43
322 122 144 3.5 2.3 C302_0093 MB23 EZ505U 339 569 9.310 3575/384 12 15 3200 2800 4000 23 8.7 43
364 55 69 1.7 4.8 C302_0083 MB23 EZ404U 232 504 8.250 33/4 8.0 8.0 3200 2800 4000 13 8.7 38
364 55 69 1.7 4.8 C302_0083 MB23 EZ404U 232 504 8.250 33/4 12 8.0 3200 2800 4000 13 8.7 38
364 55 69 1.7 4.8 C302_0083 MB23 EZ404U 232 504 8.250 33/4 16 8.0 3200 2800 4000 13 8.7 38
364 59 64 1.9 4.5 C302_0083 MB23 EZ502U 248 504 8.250 33/4 8.0 8.0 3200 2800 4000 15 8.7 38
364 59 64 1.9 4.5 C302_0083 MB23 EZ502U 248 504 8.250 33/4 12 8.0 3200 2800 4000 15 8.7 38
364 59 64 1.9 4.5 C302_0083 MB23 EZ502U 248 504 8.250 33/4 16 8.0 3200 2800 4000 15 8.7 38
364 59 66 1.9 4.5 C302_0083 MB33 EZ701U 160 700 8.250 33/4 16 15 3200 2800 4000 40 8.7 47
364 59 66 1.9 4.5 C302_0083 MB33 EZ701U 160 700 8.250 33/4 24 15 3200 2800 4000 40 8.7 47
364 59 66 1.9 4.5 C302_0083 MB33 EZ701U 160 700 8.250 33/4 32 15 3200 2800 4000 40 8.7 47
364 78 89 2.4 3.4 C302_0083 MB23 EZ503U 300 504 8.250 33/4 8.0 15 3200 2800 4000 19 8.7 40
364 78 89 2.4 3.4 C302_0083 MB23 EZ503U 300 504 8.250 33/4 12 15 3200 2800 4000 19 8.7 40
364 96 115 3.0 2.8 C302_0083 MB33 EZ702U 328 700 8.250 33/4 16 15 3200 2800 4000 45 8.7 50
364 96 115 3.0 2.8 C302_0083 MB33 EZ702U 328 700 8.250 33/4 24 15 3200 2800 4000 45 8.7 50
364 96 115 3.0 2.8 C302_0083 MB33 EZ702U 328 700 8.250 33/4 32 15 3200 2800 4000 45 8.7 50
364 108 128 3.4 2.5 C302_0083 MB23 EZ505U 300 504 8.250 33/4 8.0 15 3200 2800 4000 23 8.7 43
364 108 128 3.4 2.5 C302_0083 MB23 EZ505U 300 504 8.250 33/4 12 15 3200 2800 4000 23 8.7 43
383 52 65 2.1 4.1 C302_0078 MB23 EZ404U 221 479 7.841 494/63 8.0 8.0 3800 3500 4000 11 7.1 38
383 52 65 2.1 4.1 C302_0078 MB23 EZ404U 221 479 7.841 494/63 12 8.0 3800 3500 4000 11 7.1 38
383 52 65 2.1 4.1 C302_0078 MB23 EZ404U 221 479 7.841 494/63 16 8.0 3800 3500 4000 11 7.1 38
383 56 61 2.2 3.9 C302_0078 MB23 EZ502U 236 479 7.841 494/63 8.0 8.0 3800 3500 4000 13 7.1 38
383 56 61 2.2 3.9 C302_0078 MB23 EZ502U 236 479 7.841 494/63 12 8.0 3800 3500 4000 13 7.1 38
383 56 61 2.2 3.9 C302_0078 MB23 EZ502U 236 479 7.841 494/63 16 8.0 3800 3500 4000 13 7.1 38
383 56 63 2.2 3.9 C302_0078 MB33 EZ701U 152 550 7.841 494/63 16 15 3800 3500 4000 38 7.1 47
383 56 63 2.2 3.9 C302_0078 MB33 EZ701U 152 550 7.841 494/63 24 15 3800 3500 4000 38 7.1 47
383 74 84 2.9 2.9 C302_0078 MB23 EZ503U 285 479 7.841 494/63 8.0 15 3800 3500 4000 17 7.1 40
383 74 84 2.9 2.9 C302_0078 MB23 EZ503U 285 479 7.841 494/63 12 15 3800 3500 4000 17 7.1 40
383 91 110 3.6 2.4 C302_0078 MB33 EZ702U 312 550 7.841 494/63 16 15 3800 3500 4000 44 7.1 50
383 91 110 3.6 2.4 C302_0078 MB33 EZ702U 312 550 7.841 494/63 24 15 3800 3500 4000 44 7.1 50
383 103 122 4.1 2.1 C302_0078 MB23 EZ505U 285 479 7.841 494/63 8.0 15 3800 3500 4000 22 7.1 43
383 103 122 4.1 2.1 C302_0078 MB23 EZ505U 285 479 7.841 494/63 12 15 3800 3500 4000 22 7.1 43
475 42 53 2.0 4.8 C302_0063 MB23 EZ404U 178 386 6.314 221/35 8.0 8.0 3500 3100 4000 12 7.1 38
475 42 53 2.0 4.8 C302_0063 MB23 EZ404U 178 386 6.314 221/35 12 8.0 3500 3100 4000 12 7.1 38
475 42 53 2.0 4.8 C302_0063 MB23 EZ404U 178 386 6.314 221/35 16 8.0 3500 3100 4000 12 7.1 38
475 45 49 2.1 4.5 C302_0063 MB23 EZ502U 190 386 6.314 221/35 8.0 8.0 3500 3100 4000 14 7.1 38
475 45 49 2.1 4.5 C302_0063 MB23 EZ502U 190 386 6.314 221/35 12 8.0 3500 3100 4000 14 7.1 38
475 45 49 2.1 4.5 C302_0063 MB23 EZ502U 190 386 6.314 221/35 16 8.0 3500 3100 4000 14 7.1 38
475 45 51 2.1 4.5 C302_0063 MB33 EZ701U 122 550 6.314 221/35 16 15 3500 3100 4000 39 7.1 47
475 45 51 2.1 4.5 C302_0063 MB33 EZ701U 122 550 6.314 221/35 24 15 3500 3100 4000 39 7.1 47
475 45 51 2.1 4.5 C302_0063 MB33 EZ701U 122 550 6.314 221/35 32 15 3500 3100 4000 39 7.1 47
475 59 68 2.8 3.4 C302_0063 MB23 EZ503U 230 386 6.314 221/35 8.0 15 3500 3100 4000 17 7.1 40
475 59 68 2.8 3.4 C302_0063 MB23 EZ503U 230 386 6.314 221/35 12 15 3500 3100 4000 17 7.1 40
475 73 88 3.5 2.7 C302_0063 MB33 EZ702U 251 550 6.314 221/35 16 15 3500 3100 4000 44 7.1 50
475 73 88 3.5 2.7 C302_0063 MB33 EZ702U 251 550 6.314 221/35 24 15 3500 3100 4000 44 7.1 50
475 73 88 3.5 2.7 C302_0063 MB33 EZ702U 251 550 6.314 221/35 32 15 3500 3100 4000 44 7.1 50
475 83 98 3.9 2.4 C302_0063 MB23 EZ505U 230 386 6.314 221/35 8.0 15 3500 3100 4000 22 7.1 43
475 83 98 3.9 2.4 C302_0063 MB23 EZ505U 230 386 6.314 221/35 12 15 3500 3100 4000 22 7.1 43
512 42 45 2.1 4.7 C302_0059 MB23 EZ502U 176 358 5.859 2584/441 8.0 8.0 3500 3100 4000 14 7.1 38
512 42 45 2.1 4.7 C302_0059 MB23 EZ502U 176 358 5.859 2584/441 12 8.0 3500 3100 4000 14 7.1 38
512 42 45 2.1 4.7 C302_0059 MB23 EZ502U 176 358 5.859 2584/441 16 8.0 3500 3100 4000 14 7.1 38
512 42 47 2.1 4.7 C302_0059 MB33 EZ701U 114 550 5.859 2584/441 16 15 3500 3100 4000 39 7.1 47
512 42 47 2.1 4.7 C302_0059 MB33 EZ701U 114 550 5.859 2584/441 24 15 3500 3100 4000 39 7.1 47
512 42 47 2.1 4.7 C302_0059 MB33 EZ701U 114 550 5.859 2584/441 32 15 3500 3100 4000 39 7.1 47
512 55 63 2.8 3.6 C302_0059 MB23 EZ503U 213 358 5.859 2584/441 8.0 15 3500 3100 4000 18 7.1 40
512 55 63 2.8 3.6 C302_0059 MB23 EZ503U 213 358 5.859 2584/441 12 15 3500 3100 4000 18 7.1 40
512 68 82 3.4 2.9 C302_0059 MB33 EZ702U 233 550 5.859 2584/441 16 15 3500 3100 4000 44 7.1 50
512 68 82 3.4 2.9 C302_0059 MB33 EZ702U 233 550 5.859 2584/441 24 15 3500 3100 4000 44 7.1 50
5.2 Selection tables 5 Chelical geared motors
