Sunfar V560 Series User Manual

Functional Parameter Table
V560 Series High Performance Closed-Loop Vector Inverter User Manual
94
Table 1: Comparison Table of Multifunctional Input Terminal (DI/EDI/SDI) Functions
S/N Function S/N Function
0 No function 1 Multi-speed control 1
2 Multi-speed control 2 3 Multi-speed control 3
4 Multi-speed control 4 5 FWD jog
6 REV jog 7 Forward (FWD) running command terminal
8 Reverse (REV)running command terminal 9 Acceleration and deceleration time selection 1
10
Acceleration and deceleration time selection
2
11 Running command switching
12 Frequency command switching 13 Fault resetting input (RESET)
14 Emergency stop (EMS) 15
Frequency or Process PID set value ascending
(UP)
16
Frequency or Process PID set value
descending (DW)
17 UP/DW set frequency clear
18 External equipment fault 19 Three-line running control
20 Stop DC braking command 21 Acceleration and deceleration forbidden
22 Process PID effective 23 Simple PLC multi-stage running effective
24 Swing frequency running effective 25 Compensation PID effective
26
Simple PLC multi-stage running status
(when stopping ) resetting
27
Swing frequency status resetting (effective
when stopping)
28 Multi-stage process PID giving terminal 1 29 Multi-stage Process PID giving terminal 2
30 Multi-stage process PID giving terminal 3 31 Process PID setting selection (switching)
32 Process PID feedback selection (switching) 33 Process PID sleep activation
34 Torque/speed control mode switching 35 Minimum torque limiting set value selection
36 Maximum torque limiting set value selection 37 Overvoltage suppression Input
38 Load dynamic balancing effective 39 Reserved
40
RS485 external/Standard operation panel
control switching
41 Load motor switching
42 Start permission 43 Running permitted
44 Counter 1 clock terminal 45 Counter 2 clock terminal
46 Counter 1 trigger signal 47 Counter 2 trigger signal
48 Counter 1 resetting terminal 49 Counter 2 resetting terminal
50 Counter 1 gated signal 51 Counter 2 gated signal
52 Timer 1 trigger signal 53 Timer 2 trigger signal
54 Timer 3 trigger signal 55 Timer 1 resetting
56 Timer 2 resetting 57 Timer 3 resetting
58 Timer 1 gated signal 59 Timer 2 gated signal
60 Timer 3 gated signal 61
Single pulse accumulative length value
resetting
62 Motor temperature detection contact input 63 Compensation PID parameter selection1
64 Compensation PID parameter selection 2 65 Magnetic flux brake
66
Position pulse counting (PG pulse counting
accumulation) resetting
67 Automatic shifting (Spindle shifting jog running)
68 Servo pulse command direction (Fin) 69 Servo control effective
70
Spindle positioning origin photoelectric
signal input
71 Spindle origin homing
