Functional Parameter Table
V560 Series High Performance Closed-Loop Vector Inverter User Manual
95
S/N Function S/N Function
72 Spindle positioning selection 1 73 Spindle positioning selection 2
74 Spindle positioning selection 3 75 Position gain selection
76 Reserved 77 Servo command pulse value clear
78 Servo torque compensation at low speed 79~96 Reserved
97
0.1Hz~100.00KHz pulse input(DI9/Fin
Effective)
98 Pulse input(DI9/Fin Effective)
Table 2: Comparison Table of Multifunctional Output Terminal (DO/EDO/SDO)
Variables
S/N Function S/N Function
0 No definition 1
Inverter running ready (normal voltage, no
emergency stop input)
2 Inverter is running 3 Equipment normal (fault-free running)
4 Equipment fault (trip) 5 Equipment alarm
6 Equipment fault or alarm 7 REV running
8
Running command input (irrelevant with start
or running signal)
9 Running at zero speed
10 Speed not at zero 11 Inverter under voltage stop
12 Terminal control effective 13 In the process of acceleration running
14 In the process of deceleration running 15 Braking power generation running status
16 Determined by standard MODBUS Fieldbus 17
Determined by Extended communication
module
18 Reserved 19
Completion of current stage of multi-stage
running (0.5s pulse )
20 Multi-stage running completed (0.5s pulse ) 21
Multi-stage running completed (continuous level
output)
22
Multi-stage running cycle completed (0.5s
pulse )
23 Swing frequency upper and lower limit
24
Encoder direction positive (A pulse
surpassing B pulse )
25 Encoder direction negative (A behind B)
26
Monitor 1 input variable below the lower limit
(Void when above the upper limit)
27
Monitor 1 input variable above the upper
limit(void when below the lower limit)
28
Monitor 1 input variable between the upper
limit and the lower limit
29
Monitor 2 variable below the lower limit (void
when above the upper limit)
30
Monitor 2 input variable above the upper
limit(void when below the lower limit)
31
Monitor 2 input variable between the upper limit
and the lower limit
32
Monitor 3 input variable below the lower
limit(void when above the upper limit)
33
Monitor 3 input variable above the upper limit
(void when below the lower limit)
34
Monitor 3 input variable between the upper
limit and the lower limit
35 Position reached (Servo or spindle control)
36
Analog input AI1 wire breakage detection
effective
37
Analog input AI2 wire breakage detection
effective
38
Analog input AI3 wire breakage detection
effective
39 Reserved
