Description Of Specific Functions 101
V560 Series High Performance Closed-Loop Vector Inverter User Manual
automatically increased by one function grade.
F0.0.01 Parameter display and
modification (H)
Setting range: 0000~9014 Factory default: 0001
_ _ _ X : Parameter display mode
0: Display all parameters
1: Display effective configuration parameters
To automatically hide the parameters irrelevant with current command or hardware according to different
parameter setting commands or different current hardware configuration (e.g. various expansion boards), so
as to simplify field commissioning.
2: Display parameters different from factory default
3: Display modified and stored parameters after power-on this time
4: Display modified and un-stored parameters after power-on this time
_ _ X _ : Parameter modification mode
The macro parameter F0.0.00 is also limited by this function.
0: Effective and permanently stored after modification
Parameters modified will be immediately stored in the memory and permanent saved, and will not lose after
power-off.
1: Effective after modification but not stored, and getting lost after power-off
Parameters modified are effective but are not saved in the memory. And parameters modified will
automatically restore to the values saved in the memory after completion of relevant operation or power-off.
This function is used for tentative modification of undetermined parameters for field commissioning; After
commissioning, all modified and unsaved parameters can be displayed for view separately (when the unit of
this parameter is set to 4), and batch recovery or batch storage will be conducted (when the kilobit of this
parameter is set to 2 or 5).
X _ _ _ : Batch recovery or batch storage of parameters
The macro parameter F0.0.00 is not subject to the influence of this function.
2: Abandon modifying all unsaved parameters (restoring to original value)
All unsaved parameters will be rapidly restored to the values stored in the memory with one key.
This function can only be used when the device is stopped. If this function is activated when the device is
running, the inverter will send alarm aL.058 and give up operation.
5: Batch storing all modified and unsaved parameters
All modified and unsaved parameters will be saved in the memory.
9: Resume all parameters to initial values at the last power-on
To restore all parameters to the initial values at the last power-on. Even after initialization, all parameters can
be restored to the preliminary power-on values with this function. This function is used to make correction
during field commissioning when the system works abnormally because no one knows which parameter is
¾ F0.0.00 and F0.0.01 are not limited by the parameter display mode, and will not be
concealed in any display mode. The panel displaying parameters concealed due to
parameter display mode will not influence the access to the concealed parameter via
communication port.
