138 Description Of Specific Functions
V560 Series High Performance Closed-Loop Vector Inverter User Manual
24: Swing frequency running effective
If swing frequency running selects effective terminal (set F6.2.46 as ###2), the functional terminal can input
and cut off swing frequency running.
If terminal status is effective, frequency converter runs swing frequency. If terminal status is ineffective,
frequency inverter can accelerate and decelerate into swing frequency preset frequency [F6.2.47] for running
according to effective acceleration and deceleration time (regard acquiescent value as acceleration and
deceleration time 1).
25: Compensation PID effective
When the function of compensation PID is activated from external effective terminal selection (regard
F9.0.00 as _ _ _ 2), the functional terminal can input and cut off the function of compensation PID.
26: Simple PLC multi-stage running status (when stopping) resetting
Simple PLC multi-stage running status when stopping can select the automatic memorized ([F6.1.15] = _ 1_
_ / _ 2_ _). The functional terminal can reset the automatic memorized status forcefully.
27: Swing frequency status resetting (effective when stopping)
If the swing frequency's current running status is ([F6.2.46] = _ _ 0 _ ) when swing frequency operation
selects automatic memory stop, the functional terminal can reset the status of swing frequency forcefully.
28~30: Process PID multi-stage given terminals 1~3
Using ON/OFF status combinations of multi-stage process PID given terminals 1~3 can achieve multi-stage
process PID given terminals selection as following table.
Table 7-7 Contrast table of multi-stage process PID given terminals selection
Multi-stage process PID
given terminal 3
Multi-stage process
PID given terminal 2
Multi-stage process
PID given terminal 1
Process PID multi-stage given
selection
OFF OFF OFF
Ordinary process PID given
(determined by F7.0.01)
OFF OFF ON Process PID multi-stage given 1
OFF ON OFF Process PID multi-stage given 2
OFF ON ON Process PID multi-stage given 3
ON OFF OFF Process PID multi-stage given 4
ON OFF ON Process PID multi-stage given 5
ON ON OFF Process PID multi-stage given 6
ON ON ON Process PID multi-stage given 7
31: Process PID setting selection (switching)
The functional terminal is applied to switch process PID setting of frequency inverter between process PID
setting 1 and process PID setting 2. See process PID setting switching status as following table:
Table 7-8 Contrast table of process PID setting switching status
Terminal status Process PID setting of frequency inverter
ON Process PID setting 2
OFF Process PID setting 1
32: Process PID feedback selection (switching)
This functional terminal is applied to switch Process PID feedback of frequency inverter between process
PID setting 1 and process PID setting 2. See process PID switching status as following table:
