V560 Series High Performance Closed-Loop Vector Inverter User Manual
Pr---- power of brake resistance
D---- braking frequency (time proportion of regeneration process accounts for the whole
process), generally it is 10%. Please refer to table below:
Type Lift Winding &
unwinding
Centrifuge Accidental
braking load
Proportion 20%~30% 20%~30% 50%~60% 5%
Brake resistance selection table
If need braking function of the model upon V560-4T0220, please refer to the braking unit manual.
Model
Adaptive
motor
（KW）
Power of
brake
resistance
（KW）
Brake
resistance
value（Ω）
Brake
torque
（100%）
Brake unit
V560-4T0007 1.1 0.3
≥400
100
Standard
V560-4T0011 1.1 0.3
≥400
100
Standard
V560-4T0015 1.5 0.5
≥300
100
Standard
V560-4T0022 2.2 0.65
≥200
100
Standard
V560-4T0030 3.0 0.75
≥150
100
Standard
V560-4T0040 4.0 1.0
≥125
100
Standard
V560-4T0055 5.5 1.5
≥85
100
Standard
V560-4T0075 7.5 2.0
≥65
100
Standard
V560-4T0090 9.0 2.5
≥60
100
Standard
V560-4T0110 11 2.5
≥50
100
Standard
V560-4T0150 15 3.6
≥35
100
Standard
V560-4T0185
18.5
4.5
≥30
100
Standard
V560-4T0220
22
5.5
≥25
100
Standard
