Functional Parameter Table
V560 Series High Performance Closed-Loop Vector Inverter User Manual
69
Function
Code
Name Setting Range and Description
Minimum
Unit
Factory
Default
Change
Limit
F7.0.06
Analog input quantity
corresponding to 0%
setting (Channel 2)
0.0V~[F7.0.07]/ AI2: 0.0mA~[F7.0.07] 0.01 0.0
F7.0.07
Analog input quantity
corresponding to
100% setting
(Channel 2)
[F7.0.06]~10.00/AI2: [F7.0.06]~20.00mA 0.01 10.00
F7.0.08
Process PID internal
digital preset
-100.0~100.0(%) 0.1 0.0
F7.0.09
Process PID feedback
value selection
0: PID Actual Value 1
1: PID Actual Value 2
2: Select Via Remote Input (Function No.
32)
3: Actual Value 1+ Actual Value 2
4: Actual Value 1- Actual Value 2
5: Actual Value 1* Actual Value 2/100.0
6: 100.0* Actual Value 1/ Actual Value 2
7: Min. { Actual Value 1, Actual Value 2}
8: Max. { Actual Value 1, Actual Value 2}
9: √ (|Actual Value 1- Actual Value 2|)
10: √ (|Actual Value 1|) + √ (|Actual Value
2|)
1 0
F7.0.10
Process PID feedback
channel 1
0: Analog input AI1
1: Analog input AI2
2: Analog input AI3
3: Analog input AI3 dual polarity PID
feedback
4: Fin pulse input
1 0
F7.0.11
Process PID feedback
channel 2
1 0
F7.0.12
Analog feedback
quantity corresponding
to 0% feedback
(feedback channel 1)
0.0~[F7.0.13] /AI2: 0.0mA~[F7.0.13] 0.01 0.0
F7.0.13
Analog feedback
quantity corresponding
to 100% feedback
(feedback channel 1)
[F7.0.12]~10.00V /AI2: [F7.0.12]~20.00mA 0.01 5.00
F7.0.14
Analog feedback
quantity corresponding
to 0% feedback
(feedback channel 2)
0.0~[F7.0.15]/AI2: 0.0mA~[F7.0.15] 0.01 0.0
F7.0.15
Analog feedback
quantity corresponding
to 100% feedback
( feedback channel 2)
[F7.0.14]~10.00V /AI2: [F7.0.14]~20.00mA 0.01 5.00
F7.0.16
Feedback
multiplication factor
(e.g. differential
voltage calculate flow
rate with differential
voltage)
0.01~100.00 0.01 1.00
F7.0.17 Proportional gain 0.0~100.00 0.01 2.00
F7.0.18 Integration time 0.0, 0.1~1000.0Sec. 0.1 20.0
F7.0.19 Differential coefficient 0.0, 0.01~10.00 0.01 0.0
