SVAN 958A User Manual
Execution of 1/1 OCTAVE,
1/3 OCTAVE or FFT analysis
in channel n
e
e0:n - Spectrum analysis in channel n disabled
e1:n - Spectrum analysis in channel n enabled
Range of channel n
R
R1:n - Low (SLM) or Low (VLM)
R2:n - High (SLM) or High (VLM)
Results displayed on the screen
P
P1 - CHANNEL 1, PROFILE 1 (read only)
P2 - CHANNEL 2, PROFILE 1 (read only)
P3 - CHANNEL 3, PROFILE 1 (read only)
P4 - CHANNEL 4, PROFILE 1 (read only)
P5 - CHANNEL 1, PROFILE 2 (read only)
P6 - CHANNEL 2, PROFILE 2 (read only)
P7 - CHANNEL 3, PROFILE 2 (read only)
P8 - CHANNEL 4, PROFILE 2 (read only)
P9 - CHANNEL 1, PROFILE 3 (read only)
P10- CHANNEL 2, PROFILE 3 (read only)
P11 - CHANNEL 3, PROFILE 3 (read only)
P12 - CHANNEL 4, PROFILE 3 (read only)
Filter type in profile for SLM
F
F1:m LIN filter for profile m
F2:m A filter for profile m
F3:m C filter for profile m
F4:m G filter for profile m
m = ChannelNo + 4 * (ProfileNo - 1)
Filter type in 1/1 OCTAVE or
1/3 OCTAVE analysis in channel n
for SLM
f
f0:n - HP filter in channel n
f1:n - LIN filter in channel n
f2:n - A filter in channel n
f3:n - C filter in channel n
Filter type in FFT analysis
in channel n for SLM
j
j0:n - HP filter in channel n
j1:n - LIN filter in channel n
j2:n - A filter in channel n
j3:n - C filter in channel n
Filter type in 1/1 OCTAVE or
1/3 OCTAVE analysis in channel n
for VLM
i
i0:n - HP filter in channel n (read only)
Filter type in FFT analysis in channel
n for VLM
k
k0:n - HP filter in channel n (read only)
