SVAN 958A User Manual
Filter type in profile for VLM
I
I1:m HP1 filter for profile m
I2:m HP3 filter for profile m
I3:m HP10 filter for profile m
I4:m Vel1 filter for profile m
I5:m Vel3 filter for profile m
I6:m Vel10 filter for profile m
I7:m VelMF filter for profile m
I8:m Dil1 filter for profile m
I9:m Dil3 filter for profile m
I10:m Dil10 filter for profile m
I11:m W–Bxy filter for profile m
I12:m W–Bz filter for profile m
I13:m H–A filter for profile m
I14:m W–Bc filter for profile m
I15:m KB filter for profile m
I16:m Wk filter for profile m
I17:m Wd filter for profile m
I18:m Wc filter for profile m
I19:m Wj filter for profile m
I20:m Wm filter for profile m
I21:m Wh filter for profile m
I22:m Wg filter for profile m
I23:m Wb filter for profile m
I25:m Wv filter for profile m
I28:m Wz filter for profile m
m = ChannelNo + 4 * (ProfileNo - 1)
(read only for 2nd and 3rd profile)
Detector type in profile for SLM
C
C0:m - IMPULSE detector in profile m
C1:m - FAST detector in profile m
C2:m - SLOW detector in profile m
m = ChannelNo + 4 * (ProfileNo - 1)
Detector type in profile for VLM
E
E0:m - 100 ms detector in profile m
E1:m - 125 ms detector in profile m
E2:m - 200 ms detector in profile m
E3:m - 500 ms detector in profile m
E4:m - 1 s detector in profile m
E5:m - 2 s detector in profile m
E6:m - 5 s detector in profile m
E7:m - 10 s detector in profile m
m = ChannelNo + 4 * (ProfileNo - 1)
(read only for 2nd and 3rd profile)
