SVAN 958A User Manual
Logger type in profile in the case
of SLM
B
B0:m - None logger in profile m
Bxx:m - xx - sum of values for profile m:
1 – logger with PEAK values
2 – logger with MAX values
4 – logger with MIN values
8 – logger with RMS values
m = ChannelNo + 4 * (ProfileNo - 1)
Storing the results of 1/1 OCTAVE
or 1/3 OCTAVE analysis in channel
n in logger file in the case of SLM
b
b0:n - switched off (None) in channel n
b4:n - switched on (RMS/LEQ) in channel n
Storing the results of FFT analysis in
channel n in logger file
v
v0:n - switched off (none) in channel n
v4:n - switched on (RMS) in channel n (read only)
Logger type in profile in the case of
VLM
G
G0:m - None logger in profile
Gxx:m - xx - sum of values for profile m:
1 – logger with PEAK values
2 – logger with P–P values
4 – logger with MAX values
8 – logger with RMS values
16 – logger with VDV values
m = ChannelNo + 4 * (ProfileNo - 1)
Storing the results of 1/1 OCTAVE
or 1/3 OCTAVE analysis in channel
n in logger file
g
g0:n - switched off (none) in channel n
g4:n - switched on (RMS) in channel n
Logger time step
d
dnnnn - nnnn number in milliseconds (10, 20, 50,
100, 200, 500, 1000)
dnns - nn number in seconds (1 ÷ 60)
dnnm - nn number in minutes (1 ÷ 60)
Integration time
D
D0 “infinite” number
Dnns nn number in seconds
Dnnm nn number in minutes
Dnnh nn number in hours
Repetition cycle
K
K0 - infinity (measurement stopped when the
STOP button is pressed or when remote
setting S0 is received)
Knnnn - nnnn number of repetitions (1 ÷ 1000)
Detector type in the LEQ (for SLM)
and/or RMS (for VLM) function
L
L0 - LINEAR
L1 - EXPONENTIAL
Band of the FFT analysis
in channel n
r
r1:n - 22.4 kHz band of FFT analysis in channel n
r2:n - 11.2 kHz band of FFT analysis in channel n
r3:n - 5.6 kHz band of FFT analysis in channel n
r4:n - 2.8 kHz band of FFT analysis in channel n
r5:n - 1.4 kHz band of FFT analysis in channel n
r6:n - 700 Hz band of FFT analysis in channel n
r7:n - 350 Hz band of FFT analysis in channel n
r8:n - 175 Hz band of FFT analysis in channel n
r9:n - 87.5 Hz band of FFT analysis in channel n
