SVAN 958A User Manual
4
UnitFlags
flags word (16 bits): b15 ... b3 b2 b1 b0
b0 - if set to 1: calibration coefficient is used
b1 - if set to 1: overload occurred
b2 - if set to 1: "Human vibrations" excluded (0 - means "Human
vibrations" included and then VDV result is present)
b5,b4,b3: type of the result Result[p][7] (p = 1,2,3,4)
000 - Lden result is not available
001 - Ld result
010 - Le result
011 - Lde result
100 - Ln result
101 - Lnd result
110 - Len result
111 - Lden result
b6 - if set to 1: overload occurred in the 4
th
channel
b7 - if set to 1: overload occurred in the 3
rd
channel
b8 - if set to 1: overload occurred in the 2
nd
channel
b9 - if set to 1: overload occurred in the 1
st
channel
b10, ..., b15 - reserved
5
RepCycle
0 - infinity
nnnn - number of repetitions (1  1000)
6
StartDelay
start delay time specified in milliseconds (1  60000)
7..8
IntTimeSec
0 - infinity
integration time specified in seconds
9
MeasureTriggerChann
el
source channel of the triggering signal:
0 (the 1
st
channel) .. 3 (the 4
th
channel)
10
MeasureTriggerMode
trigger mode: 0 - OFF, 1 - SLOPE+, 2 - SLOPE– ,
3 - LEVEL+, 4 - LEVEL–, 6 - GRADIENT+, 7 - RTC
11
MeasureTriggerSource
source of the triggering signal:
0 - the VEC result
1 - the VEC result and RMS(1) result from selected channel
2 - the RMS(1) result from the selected channel
3 - the External trigger
in the case of 1/1 OCTAVE analyser:
nn - number of 1/1 OCTAVE filter (8  NOct)
in the case of 1/3 OCTAVE analyser
nn - number of 1/3 OCTAVE filter (23  NTer)
in the case of RT60 analyser:
nn - number of TOTAL LIN result (48)
12
MeasureTriggerLev
level of triggering:
24..136 dB in the case of source channel set in Sound Meter mode,
60..200 dB in the case of source channel in Vibration Meter mode
negative value [dB] in RT60 - DECAY mode
13
MeasureVecTriggerLe
v
level of triggering for VEC result: 60..200 dB
