SVAN 958A User Manual
2
ChannelMode[1]
mode of the 1
st
channel
0 - Vibration Level Meter / Analyser
1 - Sound Level Meter / Analyser
3
CalibrFactor[1]
calibration factor (*10 dB) in the 1
st
channel
4
Range[1]
range in the 1
st
channel
in the case of SLM: 1 - Low, 2 - High
in the case of VLM: 1 - Low, 2 - High
5
MicComp
microphone noise compensation: 1-enabled in the case of SLM
6
MicFieldCorr[1]
field correction: 0 - FREE, 1 - DIFFUSE in the case of SLM
7
MicOutdoorType[1]
outdoor microphone kit correction in the case of SLM:
0 - disabled
1 - SA203
2 - SA277C
3 - SA277D
8
MicOutdoorDir[1]
outdoor correction of direction:
0 - airport
1 - environment
9
0x0706
[06, 08=sub-block_length]
10
ChannelMode[2]
mode of the 2
nd
channel:
0 - Vibration Level Meter / Analyser
1 - Sound Level Meter / Analyser
11
CalibrFactor[2]
calibration factor (*10 dB) in the 2
nd
channel
12
Range[2]
range in the 2
nd
channel:
in the case of SLM: 1 - Low, 2 - High
in the case of VLM: 1 - Low, 2 - High
13
MicComp
microphone noise compensation: 1-enabled in the case of SLM
14
MicFieldCorr[2]
field correction: 0 - FREE, 1 - DIFFUSE in the case of SLM
15
MicOutdoorType[2]
outdoor microphone kit correction in the case of SLM:
0 - disabled
1 - SA203
2 - SA277C
3 - SA277D
16
MicOutdoorDir[2]
outdoor correction of direction:
0 - airport
1 - environment
17
0x0706
[06, 08=subblock_length]
18
ChannelMode[3]
mode of the 3
rd
channel:
0 - Vibration Level Meter / Analyser
1 - Sound Level Meter / Analyser
19
CalibrFactor[3]
calibration factor (*10 dB) in the 3
rd
channel
20
Range[3]
range in the 3
rd
channel:
in the case of SLM: 1 - Low, 2 - High
in the case of VLM: 1 - Low, 2 - High
21
MicComp
microphone noise compensation: 1-enabled in the case of SLM
22
MicFieldCorr[3]
field correction: 0 - FREE, 1 - DIFFUSE in the case of SLM
23
MicOutdoorType[3]
outdoor microphone kit correction in the case of SLM:
0 - disabled
1 - SA203
2 - SA277C
3 - SA277D
