Svantek SVAN 958A - Page 151

151
SVAN 958A User Manual
2..15
MainResults[1]
main results from the 1
st
profile of the 1
st
channel, defined
in the case of SLM mode - in Table B.1.10_SLM and
in the case of VLM mode - in Table B.1.10_VLM
16..29
MainResults[2]
main results from the 1
st
profile of the 2
nd
channel, defined
in the case of SLM mode - in Table B.1.10_SLM and
in the case of VLM mode - in Table B.1.10_VLM
30..43
MainResults[3]
main results from the 1
st
profile of the 3
rd
channel, defined
in the case of SLM mode - in Table B.1.10_SLM and
in the case of VLM mode - in Table B.1.10_VLM
44..57
MainResults[4]
main results from the 1
st
profile of the 4
th
channel, defined
in the case of SLM mode - in Table B.1.10_SLM and
in the case of VLM mode - in Table B.1.10_VLM
58..71
MainResults[5]
main results from the 2
nd
profile of the 1
st
channel, defined
in the case of SLM mode - in Table B.1.10_SLM and
in the case of VLM mode - in Table B.1.10_VLM
72..85
MainResults[6]
main results from the 2
nd
profile of the 2
nd
channel, defined
in the case of SLM mode - in Table B.1.10_SLM and
in the case of VLM mode - in Table B.1.10_VLM
86..99
MainResults[7]
main results from the 2
nd
profile of the 3
rd
channel, defined
in the case of SLM mode - in Table B.1.10_SLM and
in the case of VLM mode - in Table B.1.10_VLM
100..113
MainResults[8]
main results from the 2
nd
profile of the 4
th
channel, defined
in the case of SLM mode - in Table B.1.10_SLM and
in the case of VLM mode - in Table B.1.10_VLM
114..127
MainResults[9]
main results from the 3
rd
profile of the 1
st
channel, defined
in the case of SLM mode - in Table B.1.10_SLM and
in the case of VLM mode - in Table B.1.10_VLM
128..141
MainResults[10]
main results from the 3
rd
profile of the 2
nd
channel, defined
in the case of SLM mode - in Table B.1.10_SLM and
in the case of VLM mode - in Table B.1.10_VLM
142..155
MainResults[11]
main results from the 3
rd
profile of the 3
rd
channel, defined
in the case of SLM mode - in Table B.1.10_SLM and
in the case of VLM mode - in Table B.1.10_VLM
156..169
MainResults[12]
main results from the 3
rd
profile of the 4
th
channel, defined
in the case of SLM mode - in Table B.1.10_SLM and
in the case of VLM mode - in Table B.1.10_VLM
…
…
…
Table B.1.10_SLM. One-profile main results in the case of SLM mode
Word
number
Name / Value
Comment
0
0xnn0E
[0E, nn=sub-block_length]
1..2
MeasureTime
time of the measurement in the channel (if the channel’s 1
st
profile)
overload time in the channel (if the 2
nd
profile in a channel)
3
Result[1]
PEAK value in the profile (*100 dB)
4
Result[2]
reserved
5
Result[3]
minimal value (MIN) in the profile (*100 dB)
6
Result[4]
SPL value in the profile (*100 dB)
7
Result[5]
maximal value (MAX) in the profile (*100 dB)
