Svantek SVAN 958A - Page 152

152
SVAN 958A User Manual
8
Result[6]
Lden value in the profile (*100 dB)
(depends on UnitFlags bits: b3, b4, b5)
9
Result[7]
LEQ value in the profile (*100 dB)
10
Result[8]
Ltm3 value in the profile (*100 dB)
11
Result[9]
Ltm5 value in the profile (*100 dB)
12
Result[10]
Lav value in the profile (*100dB), (the result enable only in dosimeter
function)
13
Result[11]
TLav value in the profile (*100dB), (the result enable only in
dosimeter function)
…
…
…
Table B.1.10_VLM. One-profile main results in the case of VLM mode
Word
number
Name / Value
Comment
0
0xnn0E
[0E, nn=sub-block_length]
1..2
MeasureTime
time of the measurement in the channel (if the 1
st
profile in channel)
overload time in the channel (if second profile in channel)
3
Result[1]
PEAK value in the profile (*100 dB)
4
Result[2]
P–P value in the profile (*100 dB)
5
Result[3]
reserved
6
Result[4]
reserved
7
Result[5]
MTVV (or MAX) value in the profile (*100 dB)
8
Result[6]
VDV value in the profile (if UnitFlags bit b2 is set to 0) (*100 dB)
9
Result[7]
RMS value in the profile (*100 dB)
10
Result[8]
reserved
11
Result[9]
reserved
12
Result[10]
reserved
13
Result[11]
reserved
…
…
…
Table B.1.11. Selected statistical levels in channels
Word
number
Name / Value
Comment
0
0xnn19
[19, nn=block_length]
1
0xccmm
[mm=channel_mask,cc= used_channels]
2
NStatLevs
number of statistical levels per channel = 10
3
N1
N1 value for the LN1 statistics (1  99)
4
N2
N2 value for the LN2 statistics (1  99)
5
N3
N3 value for the LN3 statistics (1  99)
6
N4
N4 value for the LN4 statistics (1  99)
7
N5
N5 value for the LN5 statistics (1  99)
8
N6
N6 value for the LN6 statistics (1  99)
9
N7
N7 value for the LN7 statistics (1  99)
