SVAN 958A User Manual
10
N8
N8 value for the LN8 statistics (1  99)
11
N9
N9 value for the LN9 statistics (1  99)
12
N10
N10 value for the LN10 statistics (1  99)
13
LN1[1]
value of the LN1 statistics (*10 dB) for the 1
st
channel
14
LN2[1]
value of the LN2 statistics (*10 dB) for the 1
st
channel
…
…
…
22
LN10[1]
value of the LN10 statistics (*10 dB) for the 1
st
channel
23
LN1[2]
value of the LN1 statistics (*10 dB) for the 2
nd
channel
...
...
...
block_
length-1
LN10[used_channels]
value of the LN10 statistics (*10 dB) for the last channel
…
…
…
Table B.1.12. One-channel 1/1 OCTAVE analysis results
Word
number
Name / Value
Comment
0
0xnn0F
[0F, nn=block_length]
1
LowestFreq
the lowest 1/1 OCTAVE frequency (*100 Hz)
2
Noct
number of 1/1 OCTAVE values
3
NoctTot
number of TOTAL values = 3
4… block_
length
Octave[i]
1/1 octave[i] value (*100 dB); i=1..NOct+NOctTot
…
…
…
Note: The TOTAL values, calculated in the case of sound measurements, correspond
to the A, C and LIN filters – respectively. The TOTAL values, calculated in the case of vibration
measurements, correspond to the HP, CH and CH filters – respectively, where CH denotes the filter used in
the channel for Level Meter measurement.
Table B.1.13. One-channel 1/3 OCTAVE analysis results
Word
number
Name / Value
Comment
0
0xnn10
[10, nn=block_length]
1
LowestFreq
the lowest 1/3 OCTAVE frequency (*100 Hz)
2
Nter
number of 1/3 OCTAVE values
3
NterTot
number of TOTAL values = 3
4... block_
length
Tercje[I]
1/3 octave[i] value (*100 dB); i=1..NTer+NTerTot
…
…
…
