Table B.1.16. TOTALS description
[1A, nn=block_length = 1+(1 + Ntotal*4)*k (words)]
one-channel totals description block for the first channel
with TOTALS in user filters (Table B.1.15.)
one-channel totals description block for the last channel
with TOTALS in user filters (Table B.1.15.)
Note: This data block is created only in the case when the file was saved for 1/1 OCTAVE or
1/3 OCTAVE analysis and the TOTAL values were calculated for the filters selected by the user
(USER FILTERS). The TOTAL values corresponding to those filters are given in the TotValue positions and
the definitions of the proper filters are presented in the Table B.1.17.
Table B.1.17. Description of user-defined filter
[1D, nn=block_length = 5 + NTer (words)]
FilerNo as saved in one-channel description (Table B.1.15)
filter name (up to 5 letters, zero-ending string)
filter value (*10 dB) corresponding to the 1/3 octave[i] position;
i=1..NTer (1..45)
Note: Such data block is created for each filter with the logical number FilterNo greater or equal
to 3, expressed in the TOTALS DESCRIPTION block (cf. Tab. B.1.15 and Tab B.1.16).
The description of the filter with the logical number FilterNo is given only once, disregarding the number of
FilterNo repetition in Tab. B.1.15.
Table B.1.18. Statistics in channels header
[12, nn=block_length=2+4*used_channels ]
[mm=channels_mask, cc=used_channels]
[13, 04=sub-block_length]
number of classes in the 1
st
channel (100)
