Svantek SVAN 958A - Page 156

156
SVAN 958A User Manual
4
BottomClass[1]
bottom class boundary (*10 dB) in the 1
st
channel
5
ClassWidth[1]
class width (*10 dB) in the 1
st
channel
…
…
…
block_
length-4
0x0413
[13, 04=sub-block_length]
block_
length-3
NofClasses[used_
channels]
number of classes in the last channel
block_
length-2
BottomClass[used_
channels]
bottom class boundary (*10 dB) in the last channel
block_
length-1
ClassWidth[used_
channels]
class width (*10 dB) in the last channel
…
…
…
Table B.1.19. Results of the statistical analysis in one channel
Word
number
Name / Value
Comment
0
0x0014
[14, 00=block length in next word]
1
SubblockLength
2 * number of classes in the channel + 3
2
ChannelNo
channel number minus 1
3..4
Histogram[1]
the 1
st
counter in the channel
5..6
Histogram[2]
the 2
nd
counter in the channel
...
...
...
Table B.1.20. Results of the statistical analysis performed in 1/1 OCTAVE or 1/3 OCTAVE mode
Word
number
Name / Value
Comment
0
0x0015
[15, 00=block length in the next word]
1
BlockLength
block length
2
0xccmm
[mm=spectrum_mask, cc=used_spectrum]
3..
OctStatRes[1]
results of the statistical analysis performed in the 1
st
channel (defined
in Table B.1.21.)
...
…
....
OctStatRes[used_
spectrum]
results of the statistical analysis performed in the last channel
(defined in Table B.1.21.)
…
…
…
