SVAN 958A User Manual
9
rt20(FirstRT60Freq)
RT 20 result in ms
10
rt30(FirstRT60Freq)
RT 30 result in ms
11
rt_user[FirstRT60Freq]
RT USER result in ms
12
n_edt[FirstRT60Freq]
number of averaged EDT results
13
n_rt20[FirstRT60Freq]
number of averaged RT 20 results
14
n_rt30[FirstRT60Freq]
number of averaged RT 30 results
15
n_rt_user[FirstRT60Freq]
number of averaged RT USER results
…
…
…
BlockLen-9
Calc[LastRT60Freq+NTot]
flag indicates calculation results for LastRT60Freq+NTot
octave band
BlockLen-8
edt[LastRT60Freq+NTot]
EDT result in ms
BlockLen-7
rt20[LastRT60Freq+NTot]
RT 20 result in ms
BlockLen-6
rt30[LastRT60Freq+NTot]
RT 30 result in ms
BlockLen-5
rt_user[LastRT60Freq+NTot]
RT USER result in ms
BlockLen-4
cor_edt[LastRT60Freq+NTot]
number of averaged EDT results
BlockLen-3
cor_rt20[LastRT60Freq+NTot]
number of averaged RT 20 results
BlockLen-2
cor_rt30[LastRT60Freq+NTot]
number of averaged RT 30 results
BlockLen-1
cor_rt_user[LastRT60Freq+NTot]
number of averaged RT USER results
…
…
…
Table B.1.34. Results of rotation speed measurement
Word
number
Name / Value
Comment
0
0xnn2A
[2A, nn=block length]
1
rpm[0]
RPM[0]
2
rpm[1]
RPM[1]
3
rpm_max[0]
RPM MAX[0]
4
rpm_max[1]
RPM MAX[1]
5
rpm_min[0]
RPM MIN[0]
6
rpm_min[1]
RPM MIN[1]
…
…
…
Table B.1.35. Time-domain header of the file from the logger
Word
number
Name / Value
Comment
0
0xnn2B
[2B, nn=block length]
1
TimeSignalBuffer
flags (16 bit): b15…b3 b2 b1 b0
b0 - if set to 1: samples from channel 1 are saved
b1 - if set to 1: samples from channel 2 are saved
b2 - if set to 1: samples from channel 3 are saved
b3 - if set to 1: samples from channel 4 are saved
b4,…, b15 - reserved
