SVAN 958A User Manual
2
SampleRate
sampling rate:
0 - 3000 Hz
1 - 2400 Hz
2 - 1500 Hz
3 - 1200 Hz
4 - 750 Hz
5 - 600 Hz
6 - 375 Hz
7 - 300 Hz
8 - 187 Hz
9 - 150 Hz
3..4
BuffLength
logger length in bytes
5..6
RecsInBuff
records number in logger
7..8
RecsInObserv
records number in observation time equal:
records number in logger + records number not remember
…
…
…
Table B.1.36. Seat measurement
Word
number
Name / Value
Comment
0
0xnn2C
[2C, nn=block length]
1
SEATBaseChannel
base channel
2
SEATSeatChannel
seating channel
…
…
…
Table B.1.37. Maximum results of 1/3 OCTAVE analysis in one channel
Word
number
Name / Value
Comment
0
0xnn2D
[2D, nn=block length]
1
LowestFreq
the lowest 1/1 OCTAVE frequency (*100 Hz)
2
Noct
number of 1/1 OCTAVE values
3
NoctTot
number of TOTAL values = 3
…
…
…
4 - length
block
MaxOctave[i]
maximum result of the 1/1 octave analysis (*100 dB);
i = 1…NOct + NOctTot
…
…
…
Note: The TOTAL values, calculated in the case of sound measurements, correspond
to the A, C and LIN filters – respectively. The TOTAL values, calculated in the case of vibration
measurements, correspond to the HP, CH and CH filters – respectively, where CH denotes the filter used in
the channel for Level Meter measurement.
