Svantek SVAN 958A - Page 166

166
SVAN 958A User Manual
Table B.1.41. Trigger settings
Word
number
Name / Value
Comment
0
0x0031
[31, 00=block length in the next word]
1
BlockLen
block length
2
NProfileTriggers
number of trigger conditions per profile
3
NSpectTriggers
number of trigger conditions per spectrum channel
4
VectorCondidtion
vector trigger block (table B.1.42)
...
ProfTriggCond1
trigger condition block for the 1
st
profile (table B.1.42)
…
…
…
ProfTrigCondN
trigger condition block for the last profile (table B.1.42)
SpectTrigCond1
trigger condition block for the 1
st
spectrum (table B.1.42)
...
SpectTrigCondN
trigger condition block for the last spectrum (table B.1.42)
…
…
…
Table B.1.42. Trigger condition block
Word
number
Name / Value
Comment
0
0xnn32
[32, nn=block length]
1..2
Flags
b0 - active flag
b1 - logger integration step
b2 - 100ms integration step
b3 - 1s integration step
b4 - current time integration step
b9 - trigger action: alarm
b12 - trigger action: logger
b17 - trigger action: wave
b19 - trigger action: SMS
b21 - trigger action: E-MAIL
b23 - integration period step
3
Mode
0 - OFF, 1 - LEVEL -, 2 - LEVEL +, 3 - SLOPE -, 4 - SLOPE +,
5 - GRADIENT -, 6 - GRADIENT +, 7 - DECAY
4
Source
0 - VECTOR, 1 - PEAK, 2 - P-P, 3 - MAX, 4 - MIN, 5 - RMS,
6 - VDV, 7 - PEAK, 8 - MAX, 9 - MIN, 10 - RMS, 11..59 - spectrum
frequency
5
primaryLevel
triggering level in dB*100
6
secondaryLevel
in the case of GRADIENT mode:
gradient level in dB*100
in the case of DECAY mode:
signal drop level in dB*100
…
…
…
