SVAN 958A User Manual
Octave[i] - the result of 1/1 OCTAVE analysis (*10 dB); i = 1..NOct+NOctTot (1..18)
• results of 1/1 OCTAVE analysis from the 3
rd
channel if 1/1 OCTAVE analysis was selected as the
measurement function and in the LOGGER (path: MENU / INPUT / 1/1 OCTAVE SETUP / CHANNEL 3
/ ENABLED[
 ]; LOGGER:RMS) other then None value was selected; the sequence of words is written:
<flags> <Octave[1]> <Octave[2]> ... <Octave[NOct+NOctTot]>
where:
flags = 1 - the overload detected, 0 - the overload not detected
Octave[i] - the result of 1/1 OCTAVE analysis (*10 dB); i = 1..NOct+NOctTot (1..18)
• results of 1/1 OCTAVE analysis from the 4
th
channel if 1/1 OCTAVE analysis was selected as the
measurement function and in the LOGGER (path: MENU / INPUT / 1/1 OCTAVE SETUP / CHANNEL 4
/ ENABLED[
 ]; LOGGER:RMS) other then None value was selected; the sequence of words is written:
<flags> <Octave[1]> <Octave[2]> ... <Octave[NOct+NOctTot]>
where:
flags = 1 - the overload detected, 0 - the overload not detected
Octave[i] - the result of 1/1 OCTAVE analysis (*10 dB); i = 1..NOct+NOctTot (1..18)
• results of 1/3 OCTAVE analysis from the 1
st
channel if 1/3 OCTAVE analysis was selected
as the measurement function and in the LOGGER (path MENU / INPUT / 1/3 OCTAVE SETUP /
CHANNEL 1 / ENABLED[
 ]; LOGGER:RMS) other then None value was selected; the sequence of
words is written:
<flags> <Terave[1]> <Terave [2]> ... <Terave[NT]>
where:
flags = 1 - the overload detected, 0 - the overload not detected
Terave[i] - the result of 1/3 OCTAVE analysis (*10 dB); i = 1..NT (1..48 or 1..33)
• results of 1/3 OCTAVE analysis from the 2
nd
channel if 1/3 OCTAVE analysis was selected
as the measurement function and in the LOGGER (path: MENU / INPUT / 1/3 OCTAVE SETUP /
CHANNEL 2 / ENABLED[
 ]; LOGGER:RMS) other then None value was selected; the sequence of
words is written:
<flags> <Terave[1]> <Terave [2]> ... <Terave[NT]>
where:
flags = 1 - the overload detected, 0 - the overload not detected
Terave[i] - the result of 1/3 OCTAVE analysis (*10 dB); i = 1..NT (1..48 or 1..33)
• results of 1/3 OCTAVE analysis from the 3
rd
channel if 1/3 OCTAVE analysis was selected
as the measurement function and in the LOGGER (path: MENU / INPUT / 1/3 OCTAVE SETUP /
CHANNEL 3 / ENABLED[
 ]; LOGGER:RMS) other then None value was selected; the sequence of
words is written:
<flags> <Terave[1]> <Terave [2]> ... <Terave[NT]>
where:
flags = 1 - the overload detected, 0 - the overload not detected
Terave[i] - the result of 1/3 OCTAVE analysis (*10 dB); i = 1..NT (1..48 or 1..33)
• results of 1/3 OCTAVE analysis from the 4
th
channel if 1/3 OCTAVE analysis was selected
as the measurement function and in the LOGGER (path: MENU / INPUT / 1/3 OCTAVE SETUP /
CHANNEL 4 / ENABLED[
 ]; LOGGER:RMS) other then None value was selected; the sequence of
words is written:
<flags> <Terave[1]> <Terave [2]> ... <Terave[NT]>
where:
