5.11.2 Detector Block Adjustment Value
Activation Method (Detector well 1 - 4)
Offset Gain Target Value
High Sensitivity
Low Sensitivity
128
139
128
128
-
-
Chromogenic Method (Detector well 5)
Offset Gain Gain
128 128 4000
Immunoassy Method (Detector well 6)
Offset Gain Gain
128 128 4000
5.11.3 Temperature Adjustment Value
Unit Main Value Sub Value
Cooler Unit
Detector Block
Pipette Section
Room Temperature
128
128
128
128
128
128
128
128
NOTE: These are the displayed values when initialized.
For the Sub values, refer to the values on the labels attached on each temperature control PCB
in each unit. For the Main values, refer to the values labeled on the CPU board.
4
Refer to Section 4.4 Temperature Adjustment.
5.11.4 Transmitted Light LED Adjustment Value
Transmitted Light LED Calibration ON
Adjustment Limit (AD) 3800
Change Limit CH5 (DA) 103
Change Limit CH6 (DA) 60
5.11.5 Pressure Adjustment Value
Offset Gain
128 512
NOTE: These are the displayed values when initialized.
In case of initializing the EEPROM, refer to the values labeled on the CPU board.
Refer to Section 4.1 Pressure Adjustment.
CA-500 Series S/M 5-25 Revised December 2001 8
