B.10 Set Tube Trash Drawer
Set the furnished tube trash drawer.
Tube Trash Drawer
Reagent Rack
Reaction Tube Rack
Figure B-18: Setting the Tube Trash Drawer
B.11 Set Reagent Rack and Reaction Tube Rack
Set the furnished reagent rack and reaction tube rack.
Figure B-19: Setting the Reagent Rack and Reaction Tube Rack
Affix Indication Mark No. 954 on the reagent rack.
CA-500 Series S/M B-13 Revised December 2001 8
