5.11.6 Service Setting Value
CA-510/520 CA-530/540 CA-550/560
Chromogenic OFF ON ON
Immunoassy OFF OFF ON
Wavelength (800) (800) 800
DFbg OFF OFF OFF
APTT Incubation Time 120 120 120
D-Dimer Default Value (DD) (DD) DD
TTO ON ON ON
HpT ON ON ON
TT OFF OFF OFF
PCc OFF OFF OFF
BXT OFF OFF OFF
LA1 OFF OFF OFF
LA2 OFF OFF OFF
APL OFF ON ON
Plg OFF ON ON
Hep OFF OFF OFF
SFDP OFF OFF ON
PFDP OFF OFF ON
Maintenance Rinse OFF OFF OFF
Fill Up Terralin 1 1 1
Water 5 5 5
5.11.7 Test Mode Value
Anl. Check Mode OFF
Rinse Wate Time 120 sec
Barcode Mod. 7 OFF
Wash Test Mode OFF
ADC BUFF OFF
Vlin interim OFF
5.11.8 Reagent Vial Setting Value 11
Ver.00-14 and later
Vial Name Std (mL)
Dead
(mL)
Area
(mm2) Offset
Vial
Name Std (mL)
Dead
(mL)
Area
(mm2) Offset
Cup 4.0 0.1 105.683 0 Cup 4.0 0.3 105.683 -60
4mL Vial 4.0 0.6 286.521 18 4mL Vial 4.0 1.0 286.521 -42
3mL Vial 3.0 0.6 201.062 48 3mL Vial 3.0 0.4 201.062 -7
PV-10 10.0 0.9 292.553 28 PV-10 10.0 0.9 292.553 -23
GW5 5.0 0.6 291.039 48 GW5 5.0 1.0 291.039 -23
SLD Vial 5.0 0.5 314.159 -4 SLD Vial 5.0 0.4 45.357 -31
5.11.9 LED Calibration Value
LED Calibration ON Total Volume (/tube) 250
Adjustment Cycle 31 Dispensing Volume (/tube) 200
Warning Limit (DA) 50 Aspiration Speed 650
Error Limit (DA) 30 Dispensing speed 650
CV Limit 5.0 CV Check 3
Reaction tube number 5 2
CA-500 Series S/M 5-26 Revised December 2001 8
