SYSMEX CA-500 - 4.3 Mechanical System Adjustment; 4.3.1 Required Tools for Adjustment; 4.3.2 How to Enter the Mechanical System Position Adjustment Mode

CA-500 Series S/M 4-10 Revised May 2003
13 ECR 303C012
4.3 Mechanical System Adjustment
4.3.1 Required Tools for Adjustment
(1) Sample Cup (small)
(2) Reaction Tube
(3) Collection Tube (15 mm diameter)
(4) Dade 1 mL Reagent Bottle
(5) Push Vial Bottle
(6) Water (distilled water)
(7) Dispensing Pipette (50 and 60 µL)
(8) CA-5H
Z-axis Position Adjustment Tool PM (031-0171-4) 13
4.3.2 How to Enter the Mechanical System Position Adjustment Mode
(1) Start the service mode by pressing “ID No. Entry”, “C”, “9”, “-”, “0”, “Enter”, and “Quit”.
(2) The screen changes from “Main Menu” to “Mecha Position” by pressing keys of [Special Operate] Æ
[Service] Æ [Adjust] Æ [Mecha Position].
Select the unit to be adjusted on this screen and perform the position adjustment.
