CA-500 Series S/M 5-36 Added October 2003
17 ECR303G037
5.12 SETTINGS OF CA-500 WITH 800NM DETECTOR 17
When settings of CA-500 with 800nm detector are initialized, the settings of CA-500 with 575nm detector are
applied. Therefore following settings must be changed to recover it.
(1) Service setting
1) Press [Special Menu]-[Special Operate]-[Service]-[Service Setting].
Change parameters in Service Setting screen as follows.
Wavelength 800nm
D-Dimer Init. for LPIA DD
PFDP OFF
2) Press [Return]-[Fix] to save parameters.
3) Press [Service]-[Initial]-[Init. Entire Memory] to enable the setting.
(2) Gain calibration
1) Press [Special Menu]-[Special Operate]-[Service]-[Adjust]-[Detector Gain].
2) Press [Channel Change] and select Channel 6.
3) Press [GAIN CALI] and move the cursor to High Gain of 800nm and change the value 0.40.
4) Press [Enter]-[Quit]-[Fix] to save parameters.
(3) Reagent Holder setting
1) Press [Special Menu]-[Settings]-[Analysis Settings]-[Reagent Holder].
The Reagent Holder Setting screen will appear.
2) Press [Change Group] key, and select Group 3.
3) Move the cursor to Reagname/pos.1, and press [Select Reagent].
The screen for selecting a reagent will appear.
Move the cursor to AT3Reag, and press [Select].
4) Move the cursor to Reagname/pos.2, and press [Select Reagent].
The screen for selecting a reagent will appear.
Move the cursor to TestThr, and press [Select].
5) Move the cursor to Reagname/pos.5, and press [Select Reagent].
The screen for selecting a reagent will appear.
Move the cursor to DD.B, and press [Select].
6) Move the cursor to Reagname/pos.7, and press [Select Reagent].
The screen for selecting a reagent will appear.
Move the cursor to DD.L, and press [Select].
7) Press [Return]-[Fix] to save parameters.
