6.5.3 Insufficient Reagent (Holder No.)
Monitor Timing: At reagent aspiration
Monitor Method: The capacitance liquid level detection sensor monitors the insufficient reagent aspiration.
CA-500’s Action: In the case of a sample, the instrument stops. In the case of a reagent, the concerned
analysis will not be done. The related analysis parameter of reagent will not be done
thereafter. In the case of rinse reagent, however, emergency stop is made.
(1) Probable Cause
1. Reagent is not placed.
2. Reagent volume is insufficient.
3. Failure of sample probe
4. Failure of PCB No. 2134
5. Failure of Y-Z relay harness
6. Failure of PCB No. 9260
7. Failure of X axis wiring cord
8. Failure of wiring cord (flat cable)
9. Failure of PCB No. 6362
(2) Confirmation by the operator.
1. Place a reagent.
2. Check whether the reagent location (holder No.) matches its registration or not.
(3) Confirmation by Service Engineer.
1. Monitor the liquid sensor function in the Service mode. If it does not function, the followings are
conceivable. Since the liquid level detection is latched each time, reset it on the screen to check.
Suspect Part Test Points Expected Value
Liquid Sensor CN2 (PCB No. 2134) pin 1 is touched with
tweezers or the like
Indicator on LCD changes from
white circle to black circle
CN1 (PCB No. 2134) pin 16 (GND) and pin 5 5 V when probe touches liquid
surface
CN1 (PCB No. 9260) pin 16 (GND) and pin 5 5 V when probe touches liquid
surface
CN105 (PCB No. 6362) pin 13 (GND) and pin
2
5 V when probe touches liquid
surface
CA-500 Series S/M 6-16 Revised December 2001 8
