SYSMEX CA-500 - Part No. Index

PART NO. INDEX
CA-500 Series S/M A-4-1 Revised February 2004
19 TB200408
PART NO. PART DESCRIPTION UNIT Q'TY PAGE NO.
A
--- CA-500 PRESSURE CHAMBER ASSY - A-1-5 28
- - - BOLT M8X10 1 A-1-36 5
021-0011-0 PRESSURE CHAMBER KIT CA-5H 1 A-1-39 1-
031-0171-4 CA-5H Z-AXIS POSITION ADJUSTMENT TOOL PM 1 A-1-33 1
228-3418-6 PHOTO SENSOR EE-SX670 1 A-1-3 6
228-3753-3 PHOTO-INTERRUPTER LG-217D-3 1 A-1-15 2
228-3753-3 PHOTO-INTERRUPTER LG-217D-3 1 A-1-23 2
228-3754-7 LCD LRHBJ3431A 1 A-1-3 8
228-3754-7 LCD LRHBJ3431A 1 A-1-25 1
228-4050-8 PHOTO-IC SENSOR PS-R11L 1 A-1-17 5
14
228-9153-2 INVERTER CXA-K05M-C 1 A-1-25 4
14
228-9153-2 INVERTER INV-5 1 A-1-25 4
264-0801-7 ADAPTOR ID-23/G 1 A-1-33 4
265-1241-4 WIRING CORD NO.2701 1 A-1-35 18
265-1242-8 WIRING CORD NO.2702 1 A-1-35 14
265-1243-1 WIRING CORD NO.2703 1 A-1-35 11
266-3533-5 FUSE HOLDER CAP 031-1663(EUROP 10 A-1-5 7#
266-3536-6 FUSE HOLDER CAP 031-1666(N.AME 10 A-1-5 7$¥
5
266-5045-0 FUSE 125V6A UL-TSC-6A-N1 1 A-1-5 5$¥
5
266-5106-0 FUSE 250V6.3A ST4-6.3A-N1(N.A. 1 A-1-5 5$¥
266-5293-0 FUSE 250V3.15A NO.19195(EUROP) 10 A-1-5 5#
266-5395-2 FUSE THERMAL 125V5A TYPE210 10 A-1-11 9
281-7226-1 PRINTER FTP-421MCL001 1 A-1-25 5
18
289-9169-1 BATTERY LITHIUM CR17450SE-2-CJ2 1 A-1-5 24
18
289-9170-6 BATTERY LITHIUM CR23500SE-CJ2 1 A-1-5 24
289-9170-6 BATTERY LITHIUM CR23500SE-CJ2 1 A-1-35 27
289-9376-9 SW REGULATOR LCA50S-5 1 A-1-9 9
289-9377-2 SW REGULATOR LCA150S-12 1 A-1-9 8
A
289-9378-6 SW REGULATOR LCA150S-24-XJCM 1 A-1-9 10
A
289-9379-0 SW REGULATOR LCA150S-24-H 1 A-1-9 10
322-9150-1 WIRING CORD COVER 1 A-1-5 8
322-9151-5 TRASH COVER CA-500 1 A-1-9 5
12
322-9152-9 ZSB REAR COVER 1 A-1-17 12
A
324-9075-3 COVER SENSOR SHUTTER-B DM1374 1 A-1-3 15
A
324-9076-7 CATCH HOLD PLATE DM1358 1 A-1-17 8
A
324-9077-1 VIBRATION ARM DM1163 1 A-1-19 4
A
324-9078-4 CATCH BOX DM1357 1 A-1-17 7
A
324-9079-8 STAY DM1102 1 A-1-3 14
3
324-9080-2 REAR PANEL DM0933 CA5H 1 A-1-37 4
3
324-9081-6 WIRING CORD HOLDER DM1220 1 A-1-19 6
3
324-9082-0 C ARM PLATE DM1221 1 A-1-19 5
3
324-9083-3 LOCK SPRING DM1298 1 A-1-38 1
6
324-9084-7 SS BASE PLATE DM1361 1 A-1-38 2
6
324-9085-1 SS ACTIARM DM1362 1 A-1-38 3
342-1517-1 PULLEY NO.185 1 A-1-23 3
A
342-1815-1 TIMING BELT B216MXL4.8 1 A-1-17 9
A
342-1816-4 TIMING BELT B488MXL9.5 1 A-1-15 12
342-2776-6 PULLEY NO.143 1 A-1-23 4
343-2466-0 O-RING NO.16 50 A-1-21 12
2
344-3529-8 HINGE R-45 N GREASE TOA 1 A-1-7 7
19
344-5471-7 FIXING SCREW TL-233 1 A-1-33 14
345-3767-8 SPRING PIN KSSC 2017 1 A-1-19 1
346-3909-0 O-RING P-8 (NITRIL) 1 A-1-36 6
346-3909-0 O-RING P- 8 (NITRIL) 10 A-1-39 9
346-3939-1 O-RING P-39 1 A-1-36 4
346-3939-1 O-RING P-39 10 A-1-39 8
