SYSMEX CA-500 - Tubing Diagram

CA-500 TUBING DIAGRAM
Code No. Drawing
No.
Description Qty per
Unit
662-2207-3 1 THERMAL SENSOR ASSY 1
662-2206-0 2 COOLER THERMAL ASSY 1
663-0163-7 3 COOLING FAN ASSY 1
663-0162-3 4 COOLER ASSY 1
663-0200-8 5 SOLENOID ASSY 1
663-0179-6 6 SAMPLE RACK SENSOR ASSY 1
662-8181-6 7 ID WIRING CORD 1
663-0176-5 8 ID MOTOR ASSY 1
663-0177-9 9 ID ASSY 1
663-0196-0 10 MAIN UNIT FAN ASSY 1
265-1243-1 11 WIRING CORD NO.2703 1
662-8182-0 12 X AXIS WIRING CORD 1
663-0201-1 13 X AXIS MOTOR ASSY 1
265-1242-8 14 WIRING CORD NO.2702 1
663-0185-9 15 Y AXIS MOTOR ASSY 1
663-0186-2 16 Z AXIS MOTOR ASSY 1
663-0190-8 17 PIPETTE ASSY CA-500 1
265-1241-4 18 WIRING CORD NO.2701 1
663-0187-6 19 MIXER MOTOR ASSY 1
662-2203-9 20 DETECTOR THERMAL ASSY 1
663-0160-6 21 HEATER ASSY 1
662-2204-2 22 CHROMOGENIC LED ASSY 1
662-2205-6 23 COAGULATION LED ASSY 1
663-0210-5 24 WASTE BOTTLE ASSY 1
663-0169-9 25 VR ASSY 1
663-0171-7 26 EMERGENCY STOP SW ASSY 1
289-9170-6 27 BATTERY LITHIUM CR23500SE-CJ2 1
663-0165-4 28 SYRINGE MOTOR ASSY 1
663-0191-1 29 PRESSURE PUMP ASSY 1
663-0198-7 30 SOLENOID VALVE ASSY (VOLUMET.) 1
941-0131-3 31 SOLENOID VALVE NO.14D (PM) 1
663-0197-3 32 VACUUM PUMP ASSY 1
663-0209-1 33 RINSE BOTTLE ASSY CA-500 1
8
662-8222-1 34 WIRING CORD PD SIGNAL DW0590 1
CA-500 Series S/M A-1-35 Revised December 2001 8
