B.4 Attach Trap Chamber
(1) Attach the furnished trap chamber to the rear panel.
Connect the trap chamber tube (green) to the waste vacuum nipple (green) on the rear panel.
WARNING! • When draining the trap chamber, always wear rubber gloves.
• After completing the operation, be sure to wash hands in anti-septic
solution.
• If hands should be contaminated with blood or the like, there is a hazard of
being infected by pathogenic bacteria.
Trap Chamber Nipple
(Yellow)
Waste Vacuum Nipple
(Green)
Figure B-5: Attaching the Trap Chamber
CA-500 Series S/M B-5 Revised December 2001 8
