(3) Move the sample probe unit by hand to a place where it is easy to operate.
Remove the sample probe retainer.
Sample Probe Retainer
Figure B-3: Removing the Sample Probe Retainer
CAUTION: • Unless the retainer is removed, the instrument cannot operate.
Catcher Retainer
(4) Raise the sample probe by hand to a place where it is easy to operate.
Remove the catcher retainer.
Figure B-4: Removing the Catch Retainer
CAUTION: • Unless the retainer is removed, the instrument cannot operate.
CA-500 Series S/M B-4 Revised December 2001 8
