ALPHABETICAL INDEX
CA-500 Series S/M A-3-6 Revised February 2004
19 TB200408
PARTS DESCRIPTION PART NO. UNIT Q'TY PAGE NO.
WIRING CORD NO.2703 265-1243-1 1 A-1-35 11
WIRING CORD PD DW0458 662-8214-1 1 A-1-11 10
8
WIRING CORD PD SIGNAL DW0590 662-8222-1 1 A-1-35 34
X AXIS MOTOR ASSY 663-0201-1 1 A-1-9 6
X AXIS MOTOR ASSY 663-0201-1 1 A-1-35 13
X AXIS SLIDER ASSY 663-0181-4 1 A-1-7 3
X AXIS SLIDER ASSY 663-0181-4 1 A-1-15 11-
X AXIS WIRING CORD 662-8182-0 1 A-1-9 11
X AXIS WIRING CORD 662-8182-0 1 A-1-35 12
Y AXIS MOTOR ASSY 663-0185-9 1 A-1-15 11
Y AXIS MOTOR ASSY 663-0185-9 1 A-1-35 15
Z AXIS BASE ASSY 663-0182-8 1 A-1-17 1-
Z AXIS MOTOR ASSY 663-0186-2 1 A-1-17 3
Z AXIS MOTOR ASSY 663-0186-2 1 A-1-35 16
2
Z1 SLIDER-C ASSY DU1469 663-0393-0 1 A-1-17 10
2
Z2 SLIDER-C ASSY DU1468 663-0394-3 1 A-1-17 11
12
ZSB REAR COVER 322-9152-9 1 A-1-17 12
