CA-500 MAIN UNIT CHASSIS ASSY (1/2)
Code No. Drawing No. Description Qty per Unit
663-0202-5 1 REAGENT STAGE ASSY 1
8
663-0203-9 2& SAMPLE STAGE ASSY 1
8
663-0400-9 2% SAMPLE STAGE ASSY 2 (IMMUNO) 1
663-0168-5 3 OPERATION PANEL ASSY 1
663-0174-8 4# SAMPLE TABLE ASSY (ID) 1
663-0173-4 4* SAMPLE TABLE ASSY (STANDARD) 1
662-2219-8 5 POWER SWITCH ASSY CA-500 1
228-3418-6 6 PHOTO SENSOR EE-SX670 1
663-0179-6 7 SAMPLE RACK SENSOR ASSY 1
228-3754-7 8 LCD LRHBJ3431A 1
663-0205-6 9 PRINTER COVER ASSY 1
2
663-0175-1 10 SAMPLE TABLE BASE ASSY 1
2
663-0177-9 10 ID ASSY 1
663-0176-5 11 ID MOTOR ASSY 1
662-8181-6 12 ID WIRING CORD 1
8
663-0204-2 13& LIGHT SHIELD COVER ASSY 1
8
663-0401-2 13% LIGHT SHIELD COVER ASSY (IMMUNO) 1
A
324-9079-8 14 STAY DM1102 1
A
324-9075-3 15 COVER SENSOR SHUTTER-B DM1374 1
363-2558-6
OPTION
HOLDER NO. 89 1
363-2559-0
OPTION
HOLDER NO. 90 (TTO) 1
913-1091-3
OPTION
STANDARD SCATTERING STICK SET 1
7
365-9200-4
OPTION
SPACER FOR RUBBER SHOE 1
CA-500 Series S/M A-1-3 Revised December 2001 8
