CA-500 Series S/M A-1-5 Revised December 2003
18 ECR303K033
CA-500 Main unit Chassis Assy (2/2)
Code No. Drawing No. Description Qty per Unit
442-5475-1 1 TUBE TOALONE 3MMID X 6MMOD 10
442-5315-1 2 TUBE SILICONE 2MMIDX5MMOD(CLR) 10
442-1403-8 3 CONNECTING TUBE NO. 3 10
442-5290-6 4 TUBE SILICONE 4MMID X 8MMOD 20
5
266-5045-0 5$¥ FUSE 125V6A UL-TSC-6A-N1 1
5
266-5106-0 5$¥ FUSE 250V6.3A ST4-6.3A-N1(N.A. 1
266-5293-0 5# FUSE 250V3.15A NO.19195(EUROP) 10
662-2209-1 6$¥ TRANSFORMER POWER ASSY (100V) 1
662-2208-7 6# TRANSFORMER POWER ASSY (200V) 1
266-3536-6 7$¥ FUSE HOLDER CAP 031-1666(N.AME 10
266-3533-5 7# FUSE HOLDER CAP 031-1663(EUROP 10
322-9150-1 8 WIRING CORD COVER 1
663-0197-3 9 VACUUM PUMP ASSY 1
442-5292-3 10 TUBE SILICONE 1.5MMID X 6MMOD 5
6
442-5452-5 11 TUBE TEFLON 1.5MMID X 2.5MMOD 10
6
442-5416-1 11 TUBE TEFLON 1.2MMID X 2.0MMOD 10
442-5280-9 12 TUBE SILICONE 2MMID X 3MMOD 10
442-5279-4 13 TUBE SILICONE 1/32"X3/32"F7391 1
663-0198-7 14 SOLENOID VALVE ASSY (VOLUMET.) 1
442-3433-7 15 HYDRAULIC CONNECTOR NO.23 10
442-3307-4 16 RUBBER TUBE NO. 7 5
442-5452-5 17 TUBE TEFLON 1.5MMID X 2.5MMOD 10
442-5295-4 18 TUBE SILICONE 6MMID X10MMOD 10
662-0221-9 19 PCB NO.6362 1
8
662-0287-4 19 PCB NO.6373 1
663-0195-6 20 AC INLET ASSY 1
663-0164-1 21 VOLUMETRIC PISTON ASSY 1
663-0191-1 22 PRESSURE PUMP ASSY 1
663-0196-0 23 MAIN UNIT FAN ASSY 1
18
289-9170-6 24 BATTERY LITHIUM CR23500SE-CJ2 1
18
289-9169-1 24 BATTERY LITHIUM CR17450SE-2-CJ2 1
662-0225-3 25 PCB NO.7015 1
8
662-0278-1 25 PCB NO.7015 (2)(FLASH MEMORY) 1
443-0823-8 26 CHAMBER NO. 4 1
365-1333-3 27 SUPPORT NO.247 1
A
--- 28 CA-500 PRESSURE CHAMBER ASSY -
5
662-0168-8 29 PCB NO. 6350 WITH ROM 1
5
662-0276-3 29 PCB NO. 6350 WITH ROM (FOR CA) 1
8
662-0288-8 29 PCB NO. 6375 ASSY 1
: PCB used with CA-550/560 (upper compatible), and will be replaced with the old PCB (written
above) when the stock is depleted.
: Flash Memory added with CA-550/560 (upper compatible) from program Ver. 00-13.
$: FOR 117 VAC
#: FOR 220 VAC
¥: FOR 100 VAC
New CPU board (PCB NO.6373)is mounted in following instruments. 19
CA-510 S/N: A1300 and thereafter
CA-520 S/N: A1018 and thereafter
CA-530 S/N: A1805 and thereafter
CA-540 S/N: A3405 and thereafter
CA-550 S/N: A1001 and thereafter
CA-560 S/N: A1001 and thereafter
To Next Page
