CA-500 Series S/M A-1-7 Revised June 2003
14 ECR303C033
CA-500 Main unit Chassis Assy (2/2)
Code No. Drawing
No.
Description Qty per Unit
663-0180-1 1 DRIVE ARM ASSY 1
662-0223-6 2*# PCB NO.2134 1
8
662-0286-1 2*#& PCB NO.2157 1
663-0181-4 3 X AXIS SLIDER ASSY 1
14
663-0374-9 4 BASE DM1197B 1
A 14
663-0371-8 5 SHAFT-B DM1090B 1
A B
663-0370-4 6 PULLEY 1329A 1
B
663-0392-6 6 PULLEY DM1329 1
2
344-3529-8 7 HINGE R-45 N GREASE TOA 1
: PCB used with CA-550/560 (upper compatible), and will be replaced with the old PCB (written
above) when the stock is depleted.
2 TB200049
8 TB200203
14 ECR303C033
To Next Page
